- Page 1 ENRICH YOUR DRIVING LIFE User Manual Jump Starter TITAN 3000A SERIES JUMP STARTE GP3000 SUPERSAFE is a safety protection technology by GOOLOO Model No.: Epower-136...
- Page 2 Charge It First ! While reading through the manual, you can begin to charge up your GP3000 with your mobile phone charger and the type-c cable attached.
- Page 3 Parts and Functional Description Indicator Power Switch LED Flashlight Jumper Cable Socket Quick Charge In/Out Output Port Type-C 15W 5V/2.1A Output Port DC Output 15V/10A...
- Page 4 All indicators will be turned off automatically when the charging process has finished. How to Charge the GP3000 This unit can be charged with a type-c cable attached and a 5V wall charger(phone charger) or car charger.
- Page 5 How to Start a Vehicle Make sure this unit is over 50% charged (check the How to Use the Smart Cable 1.First, plug the blue connector of the intelligent battery clamp into the main unit, ensuring that the clamp's indicator light is off.
- Page 6 Solid red light: This indicates that the positive and negative terminals are incorrectly connected. Please reconnect them correctly, and once the green light turns solid, proceed with the emergency jump-start. Flashing green light: This indicates that the battery voltage is too low. Press the BOOST button, and once the green light turns solid, complete the jump-start within 30 seconds.
- Page 7 Protection Mode Short Circuit /Overload Protection: If the 15V/10A DC port is short circuit or overload (load power>150W), this unit will shut off automatically for self-protection. Resolve short circuit or overload problems and recharge this unit to reset from protection mode. How to Charge Your Phone or Tablet 1.
-
Page 8: Package Content
Package Content Part Name Quan ty Host Cloth bag USB to Type-C Cable Type-C to Type-C Cable Smart Jumper Cable User Manual Technical Specification Input: Type-C 15W(5V/3A) Type-C 15W(5V/3A), Quick Charge (5V/2.4A,9V/2A, Output: 12V/1. 5A),5V/2.1A,15/10A Capacity： 59.2Wh Star�ng Current： 600A(3s) Peak Current: 3000A Size:... -
Page 9: Troubleshooting
Please contact us This unit is over discharged or fiona@gooloo.com heated or swelled. defective If there is any other problem with this unit, please contact us directly at fiona@gooloo.com, we will do our best to solve the problem within 24 hours. -
Page 10: Toxic And Harmful Substances
Toxic and Harmful Substances Composition and amount of toxic or harmful substance in this product Cr(Vi) PBDE Indicate that the content of harmful substances in all 0： homogeneous materials is all lower than the prescribed limit of MCV (the standard 2002/95/EC/RoHs) Q1: What is the operating temperature of this unit and how to store it? A: This unit is lithium polymer battery, operating temp... - Page 11 GREEN LIGHT on and solid , then start the vehicle within 30s. If it still does not work, contact us at: fiona@gooloo.com ( Attach your order ID). Q5: What should I do if this unit can’t be charged? A: Charge it with a USB-C cable and 5V wall charger to activate it.
- Page 12 Q8: Can this unit charge other devices while it is being charged? A: Yes. Q9: Can this unit charge other devices while starting a vehicle? A: No. Q10: How often does this unit need to recharge? A: It would be best to be recharged every 3 months. Q11: Why it shuts off in 30s when charging for other devices? A: This product may not be able to charge for the devices...
- Page 13 Warning 1. Read this instruction manual carefully before using this unit. 2. Use caution while using this unit. Injury to self, or damage to the unit or the vehicle battery if precautions are not followed. 3. Do Not allow to use by persons who do not have proper knowledge or ability to operate the device without supervision.
- Page 14 11. Make sure the blue plug of the jumper cable is plugged fully into the jumper socket; otherwise, the blue plug could melt. 12. Make sure the battery terminal are clean before starting, and make sure the battery clamps are well connected. If the battery terminals on the vehicle are dirty or corroded, the output power of the unit will be lessened.
- Page 15 22. Do Not drop or crush the unit. If the unit has received a sharp blow or is damaged in any other way, a qualified battery technician should check it. 23. Do Not store in locations where the temperature may exceed 60ºC/ 140ºF.
- Page 16 C. We are not liable for any incidental or consequential damage that arises from incorrect use or misuse of this product. D. All warranty claims are limited to repair or replacement of the defective product and at the sole discretion of GOOLOO.
- Page 17 Attention Do Not Submerge In Water Do Not Disassemble Do Not Drop Avoid Extreme Temperatures Do Not Place Near or Into Fire...
-
Page 18: Customer Service
Customer Service 18 Months Limited Warranty Service； Lifetime Technical Service Feel Free to Contact Us fiona@gooloo.com(US Recommend) Support.eu@gooloo.com(EU Recommend) For FAQ and More Information www.gooloo.com 1-888-886-1805 Mon.-Fri. PST 9:00a.m.-5:00p.m. - Page 19 Made in China...
