- Page 1 USER MANUAL A l l A b o u t P a s s i o n...
- Page 2 Button function Time Temperature & Battery level During the cycling, Long press to turn on press it to mark the lap /off back light Down Back Cycling Table Bike During the cycling, Long press to turn off press it to pause the device Short press to turn on the device User...
- Page 3 Icons Icon Description Icon Description Power meter: The icon is on when GPS signal status/Icon flashing connected / The icon is flashing means acquiring satellite signals when the sensor is disconnected Satellite signals available or under searching No satellite signal Heart rate monitor: The icon is on when connected / The icon is Battery level...
- Page 4 Standard Accessories 28 C Cycling Table Bike User Sensor History Sync Setting Main Device x1 Charging Cable x1 User Manual x1 Out Front Bike Mount x1 Rubber Pad Standard Rubber Pad Rubber Ring Screw for Out Front Bike for Standard (Big x 2, Small x 2) Wrench x1 Mount x2...
- Page 5 How to Install Standard Mount Installation Install the rubber pad Tie the mount onto the bar Tie up the mount onto the mount with the rubber rings Install the main device Rotate the main device for Installation completed onto the mount 90 degrees - 5 -...
- Page 6 Out front mount installation Install the mount onto the Install the rubber pad Unscrew the screw in handle bar on the rubber onto the handle bar the mount pad, tighten up the screw Install the main device Rotate the main device Installation completed onto the mount for 90 degrees...
- Page 7 Charging Please charge the device before first time use. Please use DC 5V power adapter for charging. During the charging, the battery icon will flash until fully charged. Open the rubber cover, connect the device with usb cable to charge USB DC 5V power adaptor / Computer - 7 -...
- Page 8 Initial Setup For the 1st time use, please select the language before use. Language English 简体中文 User Profile Setting (To make the exercise calculation more accurate, please set the user profile correctly) 28 C User Info User Info Gender Male Gender Male Cycling...
- Page 9 Bike Profile Setting. 28 C Bike 1 Bike Bike 1 Activate Bike 2 Weight 12.5kg Cycling Table Bike Bike 3 Wheel 2096mm Total Distance Spd Source Spd&Cad User Sensor History Sync Setting Total Distance: Select and confirm to reset the total distance Spd Source: Set the priority for the source of the speed - 9 -...
- Page 10 Common wheel size and circumference(Wheel Size L (mm)) 12 × 1.75 935mm 24 × 1.75 1890mm 26 × 1-3/8 2068mm 650× 35A 2090mm 14 × 1.5 1020mm 24 × 2.00 1925mm 26 × 1-1/2 2100mm 650 × 38A 2125mm 14 × 1.75 1055mm 24 ×...
- Page 11 Zone: Other Settings Set the value for each heart rate zones, power zones, and cadence zones Alarm: Set the alarm for heart rate, power and cadence. The device will 28 C beep if it reached to the preset value, and a warning message will pop up during the cycling.
- Page 12 Unit: Set the unit to Metric System or Imperial System. Page Setting Set the display content in page setting. 28 C Data Page Switch/Sec Display Manual Data Page 1 Cycling Table Bike Manual Data Page 2 10 Sec Data Page 3 15 Sec 20 Sec Data Page 4...
- Page 13 The content to be displayed in self-defined page. Number of parameters to be displayed Data Page 1 Data Fields Data Fields Data Page Speed Speed Heart Rate Heart Rate Data Fields Data Fields Time Avg.HR Time Avg.HR Distance Distance Max.HR Max.HR Speed %Max.HR...
- Page 14 Connecting the Sensors Please make sure the sensors are in wake-up mode( for example the heart rate monitor should be worn properly, for cadence, speed, and power sensor, rotate the crank or the wheel to wake it up). 28 C Sensor Manage Bike 1 Search...
- Page 15 Add New Sensor and Turn off Old Sensor Select the desired sensor, and then select to connect new sensor or turn off the old sensor in the popped up window Connection completed Bike 1 Bike 1 Activate Activate HeartRate HeartRate Speed Speed Connect New...
- Page 16 Power Calibration Select Power, and then select Calibrate in the popped up window Bike 1 Power Calibrate Current Value Activate HeartRate Calibrating Speed Cadence ID 1234567 Connect New Spd&Cad Turn On Power ID 1234567 Calibrate Power calibration only works in ANT+ power meter, the Bluetooth power meter doesn't support this function...
- Page 17 Starting a Ride 28 C Speed Cycling Table Bike Connect with Distance Time.Move Locating for 00:23:43 phone the first time sync time first Heart Rate Cadence User Sensor History Power Altitude Once the device is turned on, it will automatically Calorie Temp search for satellite signals,...
- Page 18 Display and Button Accessories Connection Status. (The icon will blink when the accessory is disconnected, and it will be on when the accessory is connected) During the cycling, Press Speed it to mark the lap Scroll up and down in the Distance Time.Move During the cycling, Press...
- Page 19 View History Press the button to scroll up and down 28 C History 2019/10/21 16:35 2019/01/06 14:36 Page 1/2 2019/10/21 16:35 Datails 00:02： 36 Move Time 2019/10/21 16:35 Lap Data 98.5 km Distance Cycling Table Bike 2019/10/21 16:35 Avg 125 bpm Delete Heart Rate Max 185 bpm...
- Page 20 Sync Data USB connection Turn on the device's sync function "USB connection". Connect the device to the computer with USB cable. Computer will recognize the device as a new disk, find the folder "fit activity" , and copy the files in the folder to the computer. Sync Upload the USB Connect...
- Page 21 Bluetooth Connection Download CoospoRide in Google Play or App Store Applicable Smart Phones IOS 7.0 or above, iPhone 4s model or above Android 4.3 or above with Bluetooth 4.0 - 21 -...
- Page 22 ‘ ’ ‘ ’ ‘ ’ Select BC200 to enter searching status Click BC200-xxxxxxx to connect Bind your bike computer Bind your bike computer Searching Latest Activities More BC200 xxxx No Record Connecting xxxx BC200-xxxxxxx - 22 -...
- Page 23 Specifications Display LCD, 2.4 in Backlight Parameters File Transfer USB/Bluetooth(APP) Diaplayed Each Page Spainish/Russian German/Portuguese Wireless Bluetooth & ANT+ Language French/Turkish/English Battery Type 1300 mAh GPS & BDS & Glonass Self-Defined Parameter 5 pages Display Diaplayed Size 60 x 88 x 20 mm Laps Count Waterproof IP67...
- Page 24 Attentions The information contained in this manual is for reference only. The product described above may be subject to alteration owing to the manufacturer's continuing research and development plans without prior notice. Disclaimer The information contained in this manual just for reference. The product described above may be subject to alteration owing to the manufacturer's continuing research and development plans, without making an announcement in advance.
