Summary of Contents for COOSPO AP-B1
- Page 1 USER MANUAL AP-B1 Bicycle Tire Inflator SCAN for more Nach mehr SUCHEN SCANNEZ pour plus ESCANEAR para más Cerca altro A L L A B O U T P A S S I O N...
- Page 2 Bicycle Tire Inflator Thank you for purchasing portable bicycle Tire Inflator. Please read this user manual carefully before using the product and keep it properly for reference in the future. [a] Unit Display [b] Battery Indicator [c] Actual Pressure [d] Preset Pressure [e] Preset+ [f] Preset - [g] Power switch/work start/stop...
-
Page 3: Packing List
1 x Type-C Cable 1 x User Manual 1 x Storage Bag 1 x Wrist Lanyard 1 x Schrader and Presta Combo Hose Specification Bicycle Tire Inflator Product Name AP-B1 Product Model 74×48×34 mm Product Dimensions 129g Product Net Weigh 2~120PSI Inflation Pressure -10~45℃... - Page 4 User Guide 1.Power on and off Power on Power off Power on： Press and hold the power button for 3 seconds to turn on the air pump. Power off： Press and hold the power button for 3 seconds to turn off the air pump. 2.Battery Indicator Battery indicator lights for different levels: Three Bars::...
- Page 5 4.Charging Method Connect the charging cable to the pump and the power adapter (to be purchased separately) to charge the pump Charging Status: Indicator bar flashing. Fully Charged Status: Indicator bar steady green light. Note: Do not use the pump during charging. 5.Connect the air nozzle to the air nozzle Schrader Valve Schrader Valve Nozzle...
- Page 6 Ball Needle Use a ball needle when inflating basketball, Nozzle Inflation Type connector football and other balls. Inflation Steps: Tightly screw the ball needle onto the valve interface and insert the needle into the ball’s inflation hole to inflate. Schrader and Presta Combo Hose When using a bent valve or when you need to inflate a lot, use an extension hose to connect before inflating to reduce air...
- Page 7 Using the Air Hose for Connection Attach the air hose, choose the appropriate nozzle for the item you're inflating, and then connect it to the valve. Schrader valve Presta Valve Adapter Ball needle 6. Check the Air Pressure Actual Pressure When the pump is turned on and the valve is connected to the item for pressure detection, the number...
- Page 8 8. Pressure Reset After turning on the pump, if the nozzle is not connected to any object and the measured pressure is not 0.0, press and hold the "+" and "-" buttons simultaneously for 2 seconds. The display will fully light up and then return to normal.
- Page 9 High Temperature Safety Precautions When unscrewing the air valve, be aware that the air valve and connector can become hot due to prolonged use. Avoid prolonged contact with your hands. If the product temperature is too high, a warning will display: “Caution Hot.” Please take a 10-minute break before continuing use.
-
Page 10: Troubleshooting
Troubleshooting Fault Troubleshooting Methods Check if the battery is sufficiently charged. Check for air leaks between the nozzle and tire valve. Slow Inflation Speed Ensure the nozzle connection is tight. Check if the inflated item has leaks. Check if the battery is sufficiently charged. Cannot Inflate After Check if the current tire pressure is above Powering On... -
Page 11: Fcc Statement
FCC statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 12 Do not disassemble or attempt to service this product. This product is safe under normal and reasonably foreseeable operating conditions. If product is operating improperly, call COOSPO support. Product must be returned to the manufacturer for any service or repair.
