Summary of Contents for Hunter Tropic View
- Page 1 Tropic View Installation Manual Model: 52999 Matte White 53013 Matte Black Fan weight ±2 lbs: 22.5 lbs (10.2 kg) ©2024 Hunter Fan Co. PG4212 r122024...
- Page 2 - All wiring must be in accordance with national and local electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualified electrician. c.2 - Use only Hunter replacement parts. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 We recommend that you pull everything out of the box and lay it out. We have grouped the drawn components below with the hardware you’ll need for Hunter Pro Tip: those parts. The screws below are drawn to scale to make it easier to identify what piece of hardware is needed to install each component.
- Page 4 A little more information on Angled Mounting: For optimum performance and appearance, a longer downrod should be used with your Hunter ceiling fan when installing on high or angled ceiling. If your ceiling is angled greater than 34° you will also need an Angled Mounting Kit.
- Page 5 Installing the Ceiling Bracket You have two options for installation. Pick which one works best for your location. Re- move any existing bracket prior to installation. Only use the provided Hunter ceiling bracket that came in your fan’s box. Hunter Pro Tip:...
- Page 6 1886 Installing the Downrod Follow below if you are using the downrod that came pre-assembled in your box. Need to install a longer or shorter downrod? Check out the guide at the end of this manual. DO NOT REMOVE NOTICE SETSCREW COMPLETELY To prevent damage to fan,...
- Page 7 1886 Making Connections for the Receiver and the Fan From receiver From receiver From fan From fan Connect wiring harness from ceiling Connect both wiring harnesses from fan Connect the grounding wire plug from bracket to the wiring harness from the to the wiring harness from the receiver.
- Page 8 1886 Installing the Blades: Attach each blade to a blade iron using the blade washers, found in the hardware bag, and the blade assembly screws, found in the hardware bag. Repeat x5 Blade Washer Blade Screw Remember the screws that you kept after removing the shipping blocks? You need them here.
- Page 9 1886 Assembling the Light Kit 1 of 3 2 of 3 Light Kit Screw Light Kit Screw Feed the wire plugs through the center hole of the upper switch housing, Insert the third screw, found in the then wrap keyhole slots hardware bag, into place and Partially install two light kit screws, found in the around the screws and twist...
- Page 10 1886 Preparing the Wall Control Turning off the power KEY PRESS FUNCTION Ensure the power is OFF at the outlet box and wall switch location before proceeding LIGHT FUNCTIONS with installation. Light On/Off Light Dimming Control Long Light High Press Installing the battery Long Battery...
- Page 11 Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,...
- Page 12 This design saves electricity and allows the fan to operate much quieter than standard AC motor fans. Hunter Pro Tip: Cleaning the Fan Use soft brushes or cloths to prevent scratching.
