- Page 1 ATOM 1 PERSONAL TOWER CIRCULATOR OWNER’S GUIDE READ AND SAVE THESE INSTRUCTIONS vornado.com...
- Page 2 We expect this If it is not, we product to be will make it perfect. right. vornado.com 800.234.0604 help@vornado.com English...
- Page 3 CONTENTS Important Safety Instructions ..................4 Features ........................9 How to Use ......................... 10 Cleaning ........................13 Storage ........................14 Troubleshooting ......................15 Warranty ........................16 English...
- Page 4 Please keep all documents for future reference and pass these documents on, together with the product, to any future owner. See www.vornado.com/circulators-manuals to view, download and print the most current version of these instructions. INTENDED USE: This product is intended to circulate the air in indoor living spaces only in the United States.
- Page 5 - Place this product away from curtains, draperies, tablecloths and other fabrics, since they may be drawn into the product, damage the motor and/ or cause a fire. - No part of this product (the appliance, power cord, plug, packaging, etc.) should be placed near furnaces, fireplaces, stoves or other high temperature heat sources.
- Page 6 If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons in order to avoid a hazard. Contact Vornado Consumer Service at 1-800-234-0604 (phone) or consumerservice@vornado.com (email) for further instructions about replacement and repair.
- Page 7 Refer to the CLEANING instructions provided. - Do not open appliance housing while product is plugged in. To avoid risk of shock, all service and/or repairs must be done by a Vornado Authorized Service Center. - Risk of fire. Do not replace attachment plug.
- Page 8 - Connect the product into an outlet on a circuit different from that to which the receiver is connected. - Contact Vornado Consumer Service or dealer or an experienced radio/TV technician for help. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the...
- Page 9 FEATURES FINGER FRIENDLY DESIGN Resists curious fingers. GESTURAL TOUCH-SENSITIVE CONTROLS Simple controls with a sleek aesthetic. MULTIPLE SPEEDS 4 speed settings for every comfort level. ADJUSTABLE OSCILLATION 90°/180°/270°/360° or infinite oscillating airflow. DC MOTOR Quiet and energy efficient. AUTO DIMMING DISPLAY Reduces light pollution.
- Page 10 HOW TO USE 1. Insert power cord plug into port that extends from the bottom of the product. Plug the power cord into a power outlet. 2. Touch ( ) to power ON or OFF. Your circulator returns to last saved memory setting.
- Page 11 4. Swipe any area along the control panel perimeter to turn ON oscillation and select desired oscillation angle and direction of airflow. Select 90°/180°/270°/360° or infinite 360° oscillating airflow in either direction. The oscillation angle and direction of airflow is indicated by the blue LEDS as shown on the display.
- Page 12 5. Press and hold any LED along the control panel perimeter for 2 seconds to turn OFF oscillation. 6. Double tap at any area along the control panel perimeter for targeted airflow. The airflow will then point where directed. Note: The display will dim after 3 seconds of inactivity and reawaken with any touch to the control panel.
- Page 13 CLEANING Because your ATOM 1 moves a substantial amount of air, it will need regular cleaning. The fan has no user serviceable parts inside and cannot be opened for cleaning. Never clean the product in any manner other than instructed in this owner's guide. WARNING: To reduce the risk of electrical shock and injury to persons, unplug the unit before cleaning.
- Page 14 STORAGE During the off-season or after extended periods of non-use, you may choose to store your circulator. To ensure long life of the product, it is recommended to store your circulator by following these instructions: Cleaning is recommended before storage. 1.
- Page 15 Under certain conditions, it is possible for a reset GFCI (Ground Fault Circuit Interrupter) outlet to trip when the user is changing speeds on a Vornado circulator. In this event, change to an outlet that is not connected to a GFCI device. It could also indicate a weak or defective GFCI outlet.
- Page 16 Vornado for warranty service. After receiving the RA form, ship your Product to: Vornado Air LLC Attn: Warranty & Repair 415 East 13th Street Andover, KS 67002. For your convenience, please have your model number and serial number when contacting Vornado with service inquiries.
- Page 17 God. Improper product use, which includes using an external device that alters or converts the voltage or frequency of electricity, or shipping a Vornado product to a country not intended for use will void all warranties. Any unauthorized product modification,...
- Page 18 Vornado Air, LLC 415 East 13th Street, Andover, Kansas 67002 800.234.0604 | vornado.com CL3-0768 RA, V00...
