Service Manual

CTS 710 SONET Test Set &

CTS 750 SDH Test Set

070-8853-02

Warning

The servicing instructions are for use by qualified

personnel only. To avoid personal injury, do not

perform any servicing unless you are qualified to

do so. Refer to the Safety Summary prior to

performing service.
