SS304 Built-in Argentine Charcoal and wood BBQ Grill
Model Number: AGCG304-BI-S
SS304 ARGENTINE CHARCOAL AND WOOD BBQ GRILL
Model Number: ARCG304-S
EUROPEAN LEDGE ARGENTINE BBQ ISLAND GRILL
Model Number: ARISG304-S
US Customer Assistance
support@1800acs.com/ contact@zhprokan.com
Canada: (888) 848-1663/ contactca@zhprokan.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
!
WARNING
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
(spare/replacement parts)
!
: 1-877-419-2598 or Email:
Manual #PK000722025AE- Date: 2025/04
1 |
P a g e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS304 and is the answer not in the manual?

Questions and answers

Related Manuals for Prokan SS304

Summary of Contents for Prokan SS304

  • Page 1 SS304 Built-in Argentine Charcoal and wood BBQ Grill Model Number: AGCG304-BI-S SS304 ARGENTINE CHARCOAL AND WOOD BBQ GRILL Model Number: ARCG304-S EUROPEAN LEDGE ARGENTINE BBQ ISLAND GRILL Model Number: ARISG304-S US Customer Assistance : 1-877-419-2598 or Email: (spare/replacement parts) support@1800acs.com/ contact@zhprokan.com Canada: (888) 848-1663/ contactca@zhprokan.com...

  • Page 2: Table Of Contents

    Table of Contents Quality Statement ............................. 3 Important Safety Information ......................4-6 Full System Features..........................7 Product Information ..........................8-9 Components .............................10 Tools ................................11 Assembly Instructions ..........................12-24 Part Diagrams and Lists ........................25-30 Warranty Information ..........................31 P a g e...

  • Page 3: Quality Statement

    Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
  • Page 4 Important Safety Information WARNING: FOR YOUR SAFETY DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. DO NOT store an LP cylinder that is not connected for use in the vicinity of this or any other appliance.
  • Page 5 • Keep all electrical cords away from the hot surfaces of the appliance. • Ensure proper installation and servicing by following all instructions in this manual and any other instructions or markings provided with this product. • Do not heat unopened food containers on the appliance. The buildup of pressure resulting from the heat may cause the container to burst.

  • Page 6: Choosing A Location

    Before You Cook- Positioning Your Argentinian Grill CHOOSING A LOCATION Important considerations for all grill placements include exposure to wind, proximity to foot traffic or areas where people congregate. • DO NOT place the grill in a location that is likely to be exposed to a strong wind. A strong enough wind might blow hot embers towards combustible materials or structures.

  • Page 7: Full System Features

    Full System Features-ARCG304-S Adjustable lifting system firebox Angled V-shaped grate Side table Caster for Easy Mobility Full System Features-ARISG304-S Adjustable lifting system firebox Angled V-shaped grate Weather Resistant Countertop Casters for easy Storage compartment mobility P a g e...

  • Page 8: Product Information

    Product Information Top View 49.4" 22.45" ARCG304-S Front View Right Side View Top View 32.9" 65.04" Front View ARISG304-S Right Side View P a g e...
  • Page 9 Product Information Top View 21.3" 34.6" Front View Right Side View ARCG304-S (Built-in model) P a g e...

  • Page 10: Components

    Sprocket handle Wheel assembly No.S0243-30 No. S0243-47 No. S0243-31 Qty 1 Qty 1 Qty 1 Tool hook Grease tray V-shaped grate No. S0172-45-SS304 No.S0243-03 No. S0243-17Z1 Qty 2 Qty 2 Qty 1 Door handle Handle Locking Bracket S-hook No.S0243-78 S0243-79 No.

  • Page 11: Tools

    Tools Phillips Screwdriver (Not Wrench Included) P a g e...

  • Page 12: Assembly Instructions

    ASSEMBGLY ARCG304-S Step 1: Place all fire bricks onto the coal pan. Ensure bricks are oriented as shown. Evenly space all bricks. Step 2: Attach the firebox onto the coal pan assembly. Flat Head Screw 1/4"x3/8" Qty.3 P a g e...
  • Page 13 Step 3: Install the upright assembly as shown. Flat Head Screw 1/4"x3/8" Flat Head Screw 3/16"x6MM Qty.2 Qty.2 place the fire brciks in place Flat Head Screw 3/16"x3/8" Qty.2 Step 4: Slide the grate tray onto the upright assembly. 13 | P a g e...
  • Page 14 Step 5：Install spindle assembly as shown. Step 6: Attach the spindle and top rail. Flat Head Screw 3/16"x3/8" Qty.2 Flat Head Screw 1/4"x3/8" Qty.1 14 | P a g e...
  • Page 15 Step 7: Place the looped ends of the cables onto the bracket tabs as shown. Step 8： Install the sprocket handle Step 9： Install wheel assembly Flat Head Screw 1/4"x3/8" Please pay close attention to the orientation of Qty.1 the sprocket during installation. The sprocket Washer x 1/4"...
  • Page 16 Step 10： Place the grease tray Step 11： Place grates into the grate tray Note: please note that the rear side is higher than the front to channel the fat to the grease tray. 16 | P a g e...
  • Page 17 Step 12： Install the door handle. Loosen the pre-installed screws, and use them to attach the handle. Step 13： Meat hooks . 17 | P a g e...
  • Page 18 Step 14： Lift the sprocket handle to release the handle to lower the cooking grate system To raise the grilling surface, pull the wheel forward in a counterclockwise rotation to the desired height. To lower the grilling surface, grasp the wheel firmly with one hand so that it cannot rotate freely.
  • Page 19 Grill cart assembly Step 1: Install the legs onto the bottom shelf. Flat Head Screw 1/4"x3/8" Qty.4 Step 2: Install the leg reinforced tube. Flat Head Screw 1/4"x3/8" Qty.4 P a g e...
  • Page 20 Step 3: Install the casters. Step 4: Install the grill onto the cart assembly. Flat Head Screw 3/16"x3/8" Qty.6 Flange Nut : 3/16"x Qty.2 Note: you should obtain assistance from another person to lift the grill. 20 | P a g e...
  • Page 21 Step 5: Install the side shelf and tool hooks. Flat Head Screw 3/16"x3/8" Qty.4 Step 6: Install tool hooks. Hinge:Φ7x25+M6x10 Flange Nut : M6 Qty.2 Qty.2 21 | P a g e...
  • Page 22 Step 7: Install the reinforced leg braces. . Flat Head Screw 3/16"x3/8" Flange Nut : 3/16" Qty.4 Qty.4 Flat Head Screw 1/4"x3/8" Qty.4 Begin by attaching the top screws first to secure the leg brace in place, then proceed to install the bottom two screws for full stability.
  • Page 23 ASSEMBGLY ARISG304-S Step 1: Place the grill onto the grill cabinet. Step 2: Install accessory holder. Flat Head Screw 1/4"x3/8" Qty.4 P a g e...
  • Page 24 Assembly AGCG304-BI-S (Built-in model) Step 1: Install the built-in brackets. Note: Slightly loosen the screws on the grill head, slide the brackets into position, and then tighten the screws securely. P a g e...

  • Page 25: Part Diagrams And Lists

    Part Diagrams and Lists-AGCG304-BI-S Built-in model only 25 | P a g e...
  • Page 26 Part Diagrams and Lists-AGCG304-BI-S DESCRIPTION PART# S0243-01Z1 Door S0243-17Z1 V-shaped grate Wheel Assembly S0243-47 Hinge S0174-11-SS304 Door handle S0243-78 Handle Locking Bracket S0243-79 S-hook S0243-61 S0243-29 Accessory holder Tool hook S0172-45-SS304 S0243-34 Fire brick S0243-27Z1 Shovel S0243-03 Grease tray S0243-32...
  • Page 27 Part Diagrams and Lists-ARCG304-S 27 | P a g e...
  • Page 28 Part Diagrams and Lists-ARCG304-S DESCRIPTION PART# S0243-01Z1 Door S0243-17Z1 V-shaped grate Wheel Assembly S0243-47 Hinge S0174-11-SS304 Door handle S0243-78 S0243-79 Handle Locking Bracket S-hook S0243-61 S0243-29 Accessory holder Tool hook S0172-45-SS304 S0243-34 Fire brick S0243-27Z1 Shovel S0243-03 Grease tray S0243-32...
  • Page 29 Part Diagrams and Lists-ARISG304-S 29 | P a g e...
  • Page 30 Part Diagrams and Lists-ARISG304-S DESCRIPTION PART# S0243-01Z1 Door V-shaped grate S0243-17Z1 Wheel Assembly S0243-47 Hinge S0174-11-SS304 Door handle S0243-78 S0243-79 Handle Locking Bracket S0243-61 S-hook S0243-29 Accessory holder Tool hook S0172-45-SS304 S0243-34 Fire brick S0243-27Z1 Shovel S0243-03 Grease tray Poker...

  • Page 31: Warranty Information

    Warranty Information Should you encounter any problem, Please contact us first. DON’T Return the product to the store. We can help. US Customer Assistance (spare/replacement parts): 1-877-419-2598 or Email: support@1800acs.com/ contact@zhprokan.com Canada: (888) 848-1663/ contactca@zhprokan.com Please note that the limited warranty is given to and covers the Original purchaser only and such coverage is not transferable.

This manual is also suitable for:

Agcg304-bi-sArcg304-sArisg304-s
