Assembly Instructions & User's Manual for
MAXIM 4B BUILT-IN GRILL
Item Number: K04000344A
Model Number: GT04-RBI01-LP
Customer Assistance
or Email: support@1800acs.com/ contact@zhprokan.com
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
DANGER
!
If you smell gas:
1.
Shut off gas to the appliance.
Extinguish any open flame.
2.
3.
Open lid.
If odor continues, keep away from
4.
the appliance and immediately call
your gas supplier or your fire
department.
(spare/ replacement parts)
!
: 1-877-419-2598
WARNING
!
Do not store or use gasoline or other
1.
flammable liquids or vapors in the
vicinity of this or any other appli-
ances.
An LP cylinder not connected for
2.
use shall not be stored in the vicinity
of this or any other appliance.
Manual # PK000522022AE- Date: 2022/10
OPERATOR'S MANUAL
801480
!
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Prokan GT04-RBI01-LP
Summary of Contents for Prokan GT04-RBI01-LP
- Page 1 OPERATOR'S MANUAL Assembly Instructions & User’s Manual for MAXIM 4B BUILT-IN GRILL Item Number: K04000344A Model Number: GT04-RBI01-LP Customer Assistance : 1-877-419-2598 (spare/ replacement parts) or Email: support@1800acs.com/ contact@zhprokan.com 801480 THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 4 Package Contents ............................5 Product Information ..........................6 Components .............................7 Tools ................................8 Assembly Instructions ..........................9-11 Part Diagrams and Lists ........................12-13 Warning ............................14 Danger ............................15 Troubleshooting ............................16-18 Care & Use Instructions ........................19-26 Storage Instructions ..........................27 Technical Data ............................ -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Important Safety Information
Important Safety Information PRE-ASSEMBLY CAUTION Read and perform the following pre-assembly instruc- tions: Tools Required for Assembly Failure to comply with these instructions may result in a hazardous situation which, if not avoided, may • protective work gloves result in injury. •... -
Page 5: Package Contents
Package Contents Quantity Component Description Cooking Grid Grill Hotplate Warming Rack P a g e... -
Page 6: Product Information
Product Information 34.5" 34.5" 25.8" 33" 23.9" GT04-RBI01-LP P a g e... -
Page 7: Components
Components Components Cooking Grid Hotplate Warming Rack Part No.S0146-57C Part No.S0146-183 Part No.S0147-56B-S430 Qty 3 Qty 1 Qty 1 lame amer Part No.S0221-02 Qty 3 P a g e... -
Page 8: Tools
Tools Phillips Screwdriver (Not Included) P a g e... -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS Step 1：Install the Trim brackets Left and Right & Rear Phillips Head Screw 3/16" 3/8" Phillips Head Screw 1/4" 3/8" Qty. 4 Qty. 2 Step 2：Regulator and Install the grill onto the housing. P a g e... - Page 10 Install Ignitor Battery Step 3： Remove Ignitor Cap from Control Panel. Place supplied AA battery into the Ignitor Slot with positive pole facing you. Position the Cap and Spring over the AA battery and tighten onto Control Panel. Step 4： Main Burner Electrode check With the assistance of another person, perform this Electrode Check before proceeding.
- Page 11 Install Cooking Components Step 6： Place the Flame Tamers above the Burners. Place the Cooking Grids on the ledge above the Flame Tamer. Place the Secondary Cooking Rack onto the Warming rack holder. Maxim G4IB Cooking Grid Please do not cook always with just 2 burners with hood closed.
-
Page 12: Part Diagrams And Lists
Part Diagrams and Lists 12 | P a g e... - Page 13 Part Diagrams and Lists S0209-01Z-SPP08 S0214-26 S0202-19 Name plate Lid Rubber Pad, Front S0128-35 Lid Rubber Pad, Rear S0146-158 S0220-16 S0228-09 , Left S0211-25A S0211-25B , Right Heat Shield Panel 211-33 S0147-107 S0146-57C Cooking Grid S0221-04 S0146-81 S0147-59B S0221-15 S0211-30 S0211-01-S30406 Upper control Panel S0228-04...
-
Page 14: Warning
WARNING WARNING WARNING • This appliance, when installed, must be electri- cally grounded in accordance with local codes • LPG models must be used with Liquid Propane or, in the absence of local codes, with the Gas and the regulator assembly supplied. Natural National Electrical Code, ANSI/NFPA 70, or the Gas models must be used with Natural Gas only. -
Page 15: Danger
Danger DANGER Do not use an open flame to check for gas leaks. Be sure there are no sparks or open flames in the area while you check for gas leaks. This will result in a fire or explosion which can cause serious bodily injury or death, and damage to property. -
Page 16: Troubleshooting
Troubleshooting Troubleshooting To purge air from your gas line and/or reset If the grill fails to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait Turn Control Knobs to the OFF position. at least 5 minutes for gas to clear, then retry. - Page 17 Troubleshooting Answer: Question: The humming sound is gas flowing through the regulator. Can I convert my grill from LPG to NG? A low volume of sound is normal and will not interfere with the operation of your grill. Loud or excessive regulator Answer: humming and/or low flow and intermittent lighting may No, your gas grill is manufactured to exact specifications and is...
- Page 18 Troubleshooting Question: After every use (after your grill has cooled down), wipe The Regulator and Hose supplied with my gas grill stainless surfaces with a soft, soapy cloth or sponge does not fit the older LP Gas tank I’ve used for years. then rinse with water.
-
Page 19: Care & Use Instructions
Care & Use Instructions LP Gas Model only: NOTE about LP Gas Tank Exchange Programs To Secure a 20lb LP Gas Tank to the tank Many retailers who sell grills offer you the option of re- storage placing your empty LP Gas tank through an exchange service. - Page 20 Care & Use Instructions CORRECT LP GAS TANK USE Keep fire extinguisher readily accessible. In the event LP Gas grill models are designed for use with a standard of a oil/grease fire, do not attempt to extinguish with 20 lb. Liquid Propane Gas (LP Gas) tank (sold sepa- water.
- Page 21 Care & Use Instructions LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.
- Page 22 Care & Use Instructions Main Burner Lighting Instructions Repeat steps to light each burner individually. Note: When Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do lighting all main burners, start with the burner furthest from fuel source location, then light remaining burners in se- not use your grill before replacing the hose with an quence moving toward fuel source.
- Page 23 Care & Use Instructions Cleaning Exterior Stainless Steel Surfaces: Proper care and maintenance will keep your grill in top operating condition and prolong its life. Follow these cleaning procedures Routine care and maintenance is required to preserve on a timely basis and your grill will stay clean and operate with the appearance and corrosion resistance of stainless minimum effort.
- Page 24 Care & Use Instructions Manually Lighting Your Grill By Paper Match CAUTION To light your gas grill by match, insert a match into the Lighting Stick and follow steps 1 through 5 of the Grill Lighting Instructions. Then, light the match and place Never lean over the grill cooking area while lighting Lighting Stick through the Cooking Grids on the grill (See your gas grill.
- Page 25 Care & Use Instructions CORRECT ROTISSERIE USE ELECTRICAL EQUIPMENT USE Read all instructions before initial use. To protect against electric shock, do not immerse cord or IMPORTANT: When using electrical appliances, basic safety plugs in water or other liquid. precautions should always be used. The Rotisserie Motor is set for 120V, 60Hz AC current.
- Page 26 Care & Use Instructions Cleaning the burner tubes and burner ports. To reduce the chance of FLASHBACK FIRE you must clean Regardless of which Burner cleaning procedure you use, we recommend that you also complete the follow- the Burner Tubes as follows at least once a month in summer and fall or whenever spiders are active in your ing cleaning regimens to help prolong Burner life.
-
Page 27: Storage Instructions
2. Disconnect the tank and store it in an upright position in an outdoor space away from dryer and furnace vents and play areas. Item Maxim GT04-RBI01-LP 3. Coat the burners and other metal parts with cooking oil to repel moisture that can build up over the winter and to prevent rust. -
Page 28: Technical Data
Technical Data SPECIFICATIONS Maxim GT04-RBI01-LP Models/Finish Main Burners 4x10,000 BTU/ HR Rotisserie Burner 12,000 BTU/ HR Dimensions (L × W × H) 34.5 × 8 ×19.7 in. Warranty 1-year limited 28 | P a g e... -
Page 29: Limited Warranty
Limited Warranty Should you encounter any problem, Please contact us first. DON’T Return the product to the store. We can help. For assistance, contact customer service at support@1800acs.com; prokansupport@1800acs.com or call 1-877-419-2598 Monday through Friday from 8:00 a.m. to 8:00 p.m. EST. Please note that the limited warranty is given to and covers the Original purchaser only and such coverage is not transferable. - Page 30 onta t Information 30 | P a g e...
