Summary of Contents for Renault Megane Scenic
- Page 1 How to change track rod end on Renault Megane Scenic – replacement guide...
- Page 2 RENAULT Megane I Hatchback (BA) 1.9 dT, RENAULT Megane I Coach (DA) 1.6 e, RENAULT Megane I Coach (DA) 2.0 i, RENAULT Megane I Coach (DA) 2.0 16V, (+ 43) The steps may slightly vary depending on the car design.
- Page 3 REPLACEMENT: TRACK ROD END – RENAULT MEGANE SCENIC. LIST OF THE TOOLS YOU'LL NEED: Wire brush Drive socket # 16 WD-40 spray Drive socket # 17 Brake cleaner Wheel impact socket #19 Copper grease Ratchet wrench Torque wrench Tap wrench...
- Page 4 Replace tie rod ends in pairs. The replacement procedure is identical for the right and left tie rod ends. Please note: all work on the car – Renault Megane Scenic – should be done with the engine switched off. CARRY OUT REPLACEMENT IN THE FOLLOWING ORDER: Secure the wheels with chocks.
- Page 5 Replacement: track rod end – Renault Megane Scenic. Tip from AUTODOC: If you are using a jack, make sure it rests on a flat surface without any unevenness. Be sure to additionally secure the car with jack stands. Unscrew the wheel bolts.
- Page 6 Clean all tie rod end connections. Use a wire brush. Use WD-40 spray. When deinstalling, mark or measure the precise position of the ball joint on the track rod, or count the number of turns in order to prevent misalignment afterward. Use a vernier caliper. Loosen the lock nut securing the tie rod end to the tie rod.
- Page 7 Treat the mounting seats of the tie rod end. Use copper grease. Screw on a new tie rod end. Use a vernier caliper. Replacement: track rod end – Renault Megane Scenic. Tip from AUTODOC: While installing the steering rod end remember to make the same number of turns or to leave the same length of thread showing as per your measurements.
- Page 8 Screw on the tie rod end jam nut. Use a combination spanner #19. Use a combination spanner #22. Connect the tie rod end to the steering knuckle. Screw on the fastening nut that connects the tie rod end to the steering knuckle. Use a drive socket #17. Use a ratchet wrench.
- Page 9 Tighten the fastening nut connecting the tie rod end to the steering knuckle. Use a drive socket #17. Use a torque wrench. Tighten it to 35 nm torque. Treat the fastener connecting the tie rod end to the steering knuckle. Use copper grease. Clean the wheel rim mounting seat.
- Page 10 AUTODOC recommends: After applying the spray, wait a few minutes. Install the wheel. AUTODOC recommends: Important! Hold the wheel while screwing in the fastening bolts. Renault Megane Scenic Screw in the wheel bolts. Use wheel impact socket #19. 9–12 CLUB.AUTODOC.CO.UK...
- Page 11 Lower the car and working in a cross order, tighten the wheel bolts. Use wheel impact socket #19. Use a torque wrench. Tighten it to 90 Nm torque. Remove the jacks and chocks. Replacement: track rod end – Renault Megane Scenic. AUTODOC experts recommend: After replacing the component, it is advisable to realign the wheels using a wheel aligner.
- Page 12 AUTODOC — TOP QUALITY AND AFFORDABLE CAR PARTS ONLINE AUTODOC MOBILE APP: GREAT DEALS AND CONVENIENT SHOPPING A GREAT SELECTION OF SPARE PARTS FOR YOUR CAR BUY SPARE PARTS FOR RENAULT TRACK ROD END: A WIDE SELECTION 11–12 CLUB.AUTODOC.CO.UK...
- Page 13 CHOOSE CAR PARTS FOR RENAULT MEGANE SCENIC TRACK ROD END FOR RENAULT: BUY NOW TRACK ROD END FOR RENAULT MEGANE SCENIC: THE BEST DEALS & OFFERS DISCLAIMER: The document contains only general recommendations that may be useful for you when you perform repair or replacement work. AUTODOC shall not be liable for any loss, injury, damage of property occurring in the repair or replacement process due to incorrect use or misinterpretation of the provided information.
