Basic Information
Model no
Range
Type
Finishing
Product Information
Communication
Highlights
Norminal Voltage
Operational Voltage
Load
70E838TY
i7 smart
Smart Switch
White
ZigBee
Remote Control
Timer Control
Schedule Control
Voice Control
250V~50/60Hz
176VAC-264VAC
>4W,200W/Gang
i7 smart
1 Gang Smart Switch Module
.
Advertisement
Related Manuals for Simon i7 smart
Summary of Contents for Simon i7 smart
- Page 1 i7 smart 1 Gang Smart Switch Module Basic Information 70E838TY Model no i7 smart Range Smart Switch Type White Finishing Product Information ZigBee Communication Remote Control Highlights Timer Control...
-
Page 2: Additional Information
Installation and maintenance IP20 IP protection PC (polycarbonate) Material -10°C~40°C Operatingtemperaturerange wall mounted Installationtype Additional information Quantity per box 375*95*105 Boxsize(mm) Quantity per carton 495*385*220 Carton size(mm) -
Page 3: Network Environment
Simon-Smart Installation Manual 1 Network Environment 1.1 Basic Requirement for Network Wi-Fi — Home Router Support 2.4GHz Wi-Fi, select 2.4GHz Wi-Fi signal 2.4G/5G combination Wi-Fi is not supported Can check the Wi-Fi type on the mobile phone or PC... - Page 4 Simon-Smart Installation Manual ZigBee — Smart Gateway Need to be connected with home router via network cable or Wi-Fi Connect ZigBee devices to internet Tips: Change network environment of Smart Gateway (LAN) Change the Wi-Fi password/ Wi-Fi Name: Smart Gateway (LAN) and ...
-
Page 5: Smart Switch
between any ZigBee devices: ＜2 walls, ＜100m in open area) Network Configuration: Download and open Simon Smart APP After connecting the power, long press the left bottom button of switch until the configuration indicator flashes... - Page 6 If not flashes, remove the cover and insert the pin into the reset hole until the configuration indicator flashes Open Simon Smart APP, enter the “Gateway” interface and click “Add Subdevice” Confirm that indicator is blinking, then click “LED already blink”...
- Page 7 Simon-Smart Installation Manual Configuration Indicator Status: Waiting pairing 4 quick flashes per second Pairing success 2 flashes per second for 2s Pairing failure 1 flash per second for 10s Initial power on ON for 1s Reset success 2 flashes per second for 2s...
