H PD 3 0 0 W a t t Se r ie s

Pr ogr a m m a ble D C

Pow e r Su pply

www.valuetronics.com

H PD 1 5 - 2 0

H PD 3 0 - 1 0

H PD 6 0 - 5

Ope r a t in g M a n u a l

www.programmablepower.com

Need help?

Do you have a question about the HPD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Xantrex HPD Series

Page 1 H PD 1 5 - 2 0 H PD 3 0 - 1 0 H PD 6 0 - 5 Ope r a t in g M a n u a l H PD 3 0 0 W a t t Se r ie s Pr ogr a m m a ble D C Pow e r Su pply www.programmablepower.com...
Page 2 www.valuetronics.com...
Page 3 Ope r a t in g M a n u a l for H PD Se r ie s Pr ogr a m m a ble D C Pow e r Supply www.valuetronics.com...
Page 4 What will Xantrex do? Xantrex will, at its option, repair or replace the defective product free of charge, provided that you notify Xantrex of the product defect within the Warranty Period, and provided that Xantrex through inspection establishes the existence of such a defect and that it is covered by this Limited Warranty.
Page 5 Xantrex or its authorized service centers (hereafter “ASCs”);...
Page 6 TO THE PERI OD STI PULATED UNDER THI S LI MI TED WARRANTY. I N NO EVENT WI LL XANTREX BE LI ABLE FOR ANY SPECI AL, DI RECT, I NDI RECT, I NCI DENTAL OR CONSEQUENTI AL DAMAGES, LOSSES, COSTS OR EXPENSES...
Page 7 WI THOUT LI MI TI NG THE GENERALI TY OF THE FOREGOI NG, UNLESS SPECI FI CALLY AGREED TO BY I T I N WRI TI NG, XANTREX MAKES NO WARRANTY AS TO THE ACCURACY, SUFFI CI ENCY OR SUI TABI LI TY...
Page 8 DC voltage of the battery, will provide adequate reverse polarity current protection. Where several power supplies are in parallel, it is best to fuse each one, rather than one large fuse for all. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 9 About This Manual This Operating Manual contains operating instructions for the Series of high performance, switching, laboratory power supplies, available in several voltage models at 300 watts. It provides information on features and specifications, installation procedures, and basic functions testing, as well as operating procedures for using both standard and multiple supply configurations.
Page 10 About This Manual Power Supply Safety Markings Alternating Current Off (Supply) Earth (Ground) Terminal Caution (Hot Surface) Protective Conductor Terminal Caution (Check manual additional information.) On (Supply) viii Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 11 Contents About This Manual ........... vii Section 1.
Page 12 Split Supply Operation..........38 Operating Manual for HPD Series Power Supply...
Page 13 Section 1. Features and Specifications Introduction Series of DC power supplies provides highly stable, variable output voltage and current for a broad range of development and system requirements. These units employ high frequency switching regulator technology to achieve high power density and small package size, as well as a linear post-regulator circuit for low output noise and fast response.
Page 14 SENSE (10-turn standard) POWER Connection (Banana Jack) AC Power Switch Safety Ground Binding Post (Green) Positive (+) Output Binding Post (Red) Return (−) Output Binding Post (Black) Figure 1.1 Front Panel Controls Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 15 Section 1. Features and Specifications Rear Panel Connectors and Outputs Figure 1.2 shows the programming interface indicators for units that have a digital programming interface installed. Remote Programming LED (REM) Shutdown LED (SRQ) OVP Adjust Potentiometer (OVP ADJ) OVP Shutdown (OVP) Figure 1.2 Remote Programming Interface Indicators Rear Panel Connectors and Outputs Figure 1.3...
Page 16 4. Maximum drift over 60 minutes with constant line, load, and temperature, after 60-minute warm-up. 5. Maximum drift over 8 hours with constant line, load, and temperature, after 60-minute warm-up. 6. Change in output per °C change in ambient temperature, with constant line and load. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 17 Section 1. Features and Specifications Additional Electrical Specifications Additional Electrical Specifications <500 μs Voltage Mode Transient Response (Time for the output voltage to recover to ±50 mV band for 50% load change in the range of 25% to 100% of the rated load.) Time delay from power on until 1.5 s maximum output stable...
Page 18 Up to 6,500 feet (2000 m) Storage Altitude Up to 50,000 feet (15 000 m) Installation Category Intended for use in installation category (overvoltage category) II (IEC 1010-1 standard) Pollution Degree Category 2 (IEC 1010-1 standard) Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 19 Section 1. Features and Specifications Mechanical Specifications Mechanical Specifications Front Panel Voltage and Current 10-turn voltage and 1-turn current Control potentiometers (10-turn current control optional) Front Panel Voltage Control 0.02% of maximum voltage Resolution Front Panel AC Input Power Switch Push ON/push OFF switch Front Panel Voltage and Current Independent 3-digit green numeric LED Meters...
Page 20 11.7 in. 297 mm Weight 7.7 lb. 3.5 kg Dual Output Unit Height 5.25 in. 132 mm 8.5 in. Width 216 mm Depth 11.7 in. 297 mm 14.2 lb. Weight 6.5 kg Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 21 Section 2. Installation Introduction This section provides recommendations and procedures for inspecting, installing, and testing the power supply. Basic Setup Procedure Table 2.1 Basic Setup Procedure Step# Description Action Reference “Initial Inspection” on page 19 Inspection Perform an initial physical inspection of the supply.
Page 22 Section 2. Installation Returning Power Supplies to the Manufacturer Returning Power Supplies to the Manufacturer Return Before returning a product directly to Xantrex you must obtain a Return Material Material Authorization (RMA) number and the correct factory “Ship To” address. Products Authorization must also be shipped prepaid.
Page 23 Section 2. Installation Returning Power Supplies to the Manufacturer Packaging for Follow these instructions to prepare the unit for shipping or storage. Shipping or 1. When returning the unit or sending it to the service center, attach a tag to the unit Storage stating its model number (available from the front panel label) and its serial number (available from the rear panel label).
Page 24 “Environmental Specifications” on page 16, for the operating altitude specification and the operating ambient temperature range measured at the unit case. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 25 Section 2. Installation AC Input Power Connection AC Input Power Connection WARNING There is a potential shock hazard if the power supply chassis and cover are not connected to an electrical ground via the safety ground in the AC input connector. Ensure that the power supply is connected to a grounded AC outlet with the recommended AC input connector configured for the available line voltage as described in this section.
Page 26 Also check that the current bar graph meter follows the rise in current and that the current mode indicator light is ON. 7. Set the power switch to OFF. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 27 Section 3. Load Connection and Sensing Introduction This section covers single and multiple load connection, constant voltage and constant current operating modes, and alternate power supply configurations such as series and parallel connections. Load Connection WARNING There is a potential shock hazard at the load when using a power supply with an output greater than 40 V.
Page 28 Table 3.1 Current Carrying Capacity for Load Wiring Wire Size Maximum Current Wire Size Maximum Current (AWG) (AWG) Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 29 Section 3. Load Connection and Sensing Load Connection Load Wiring Length for Operation With Sense Lines For applications using remote sensing, you must limit the voltage drop across each load line. See Figure 3.1 for some maximum allowable lengths for a given load current and wire size. We recommend that you use the larger load wiring to ensure a smaller voltage drop (0.1 V typical maximum), although units can compensate for up to 0.5 V drop in each line...
Page 30 DC ground loops develop. Except for low current applications, we recommend that you do not use this method. Table 3.1, “Current Carrying Capacity for Load Wiring,” on page 26 for the correct wire gauge. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 31 Section 3. Load Connection and Sensing Grounding Grounding Make proper ground connections to avoid developing paths between separate ground points. To avoid ground loops, there must be only one ground return point in a power system. If the load itself is not grounded, ground the positive or negative output to the supply’s chassis using a rear panel screw or the front panel ground binding post.
Page 32 If your application requires precisely regulated output voltage at the rear output terminals, install the jumpers by inserting the jumper wires into the jumper terminals as shown. See Figure 3.3. Wire Jumper Figure 3.3 Output Terminal Block With Jumpers Installed Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 33 Section 3. Load Connection and Sensing Remote Sensing Remote Sensing WARNING There is a potential shock hazard at the sense points when using a power supply with a rated output greater than 40 V. Ensure that connections at the load end are shielded to prevent contact with hazardous voltages.
Page 34 Section 3. Load Connection and Sensing Remote Sensing Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 35 Section 4. Operation Introduction Once you have installed the power supply and have connected both the AC input power and the load as covered in Section 2, “Installation”, the power supply is ready to operate. • “Operating Modes”, below, offers a brief explanation of Constant Voltage and Constant Current Mode operation.
Page 36 2. Set the voltage control fully clockwise or to the compliance voltage of the Mode circuit. As soon as the supply starts operating in current mode, the red current mode LED will turn on. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 37 Section 4. Operation Operating Modes Automatic The automatic crossover system allows the power supply to automatically switch Mode operating modes in response to changing load requirements. For example, if the load current attempts to increase above the setting of the current adjust control, the unit Crossover switches automatically from CV to CI mode.
Page 38 Diodes CR1 and CR2 protect sense circuits during transient events such as momentary current limit events which may cause supply outputs to collapse. Use general purpose 1A rectifiers, such as IN1004 or equivalent. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 39 Section 4. Operation Using Multiple Supplies Connecting Multiple Supplies in CAUTION For parallel operation with OVP-equipped supplies, set all OVP trip points higher Parallel than the maximum output voltage. To prevent the internal OVP fuse from blowing during OVP trip events, add external blocking diodes as illustrated in Figure 4.3 Use diodes rated to handle the maximum current for the supply.
Page 40 The current limits can be set independently of each other. The maximum current available in split operation is equal to the rated output of the supplies. Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 41 Section 4. Operation Using Multiple Supplies Load Lines Postive Sense Use the largest gauge and Positive Output shortest length possible Terminal Negative Output Terminal Return Sense Positive Load Terminal Power Supply 1 Common Load Terminal Negative Load Postive Sense Terminal Positive Output Terminal Load...
Page 42 Section 4. Operation Using Multiple Supplies Operating Manual for HPD Series Power Supply www.valuetronics.com...
Page 43 www.valuetronics.com...
Page 44 Xa n t r e x Te ch n ology I n c. Xant rex Technology, I nc. 9250 Brown Deer Road San Diego, CA USA 92121 858 450 0085 Tel 858 678 4482 Fax 800 733 5427 Toll Free Nort h Am erica prg.info@xant rex.com www.xant rex.com TM-30OP-01XN...
