- Page 1 Refrigerated Topping Rails Models RS-CN-0009-PSS, 0006-PSS, 0004-PSS Items 46497, 46657, 46658 Instruction Manual Revised - 11/01/2024 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...
- Page 2 Table of Contents Model RS-CN-0009-PSS / Model RS-CN-0006-PSS Model RS-CN-0004-PSS Section Page Disclaimer ----------------------------------------------------------------------------------------------------- 3 General Information --------------------------------------------------------------------------------- 4 - 5 Safety and Warranty --------------------------------------------------------------------------------- 5 - 7 Technical Specifications ------------------------------------------------------------------------------- 8 Installation ----------------------------------------------------------------------------------------------- 8 - 9 Operation ------------------------------------------------------------------------------------------------ 9 - 13...
- Page 3 Disclaimer OMCAN IS NOT RESPONSIBLE FOR ANY DAMAGES DUE TO WATER LEAKS. WARRANTY FOR WATER LEAKS IS VOID IF THE AMBIENT ROOM TEMPERATURE EXCEEDS 75°F AND 55% RELATIVE HUMIDITY, AND THE APPLIANCE DRAIN IS NOT CONNECTED DIRECTLY TO A FLOOR DRAIN.
- Page 4 If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.
- Page 5 Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
- Page 6 Safety and Warranty • After unplugging the unit, wait at least 10 minutes before plugging it back in. Failure to do so could cause damage to the compressor. UNPLUG CORD • To minimize shock and fire hazards, please do not plug or unplug the cord with wet hands. •...
- Page 7 1 YEAR PART AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.
- Page 8 Adjustable feet x 4. We pride itself on quality and service, ensuring that at the time of packaging the contents are supplied fully functional and free of damage. Should you find any damage as a result of transit, please contact Omcan immediately.
- Page 9 Installation Note: before using the appliance for the first time, clean Interior with soapy water. 3. Level the appliance by adjusting the screw feet. Operation TEMPERATURE CONTROLLER COMMAND LIST To display target set point, in programming mode it selects a parameter or confirm an operation. To start a manual defrost.
- Page 10 Operation Measurement unit. Flashing Programming mode. HOW TO SEE THE SET POINT 1. Push and immediately release the SET key, the set point will be showed. 2. Push and immediately release the SET key or wait about 5s to return to normal visualisation. HOW TO CHANGE THE SETPOINT 1.
- Page 11 Operation pressing . In HIDDEN MENU when a parameter is present in First Level the decimal point is on. TO LOCK THE KEYBOARD 1. Keep pressed for more than 3s the keys. 2. The “OF” message will be displayed and the keyboard will be locked. If a key is pressed more than 3s the “OF”...
- Page 12 Operation length for defrost. dF - Display during defrost: (rt / it / St / dF) rt= real temperature; it= start defrost temperature; St=SET-POINT; dF= label dF. ALARMS AU - Maximum temperature alarm: (AL÷99°C) when this temperature is reached the alarm is enabled, after the “Ad”...
- Page 13 Operation TO MANUALLY DEFROST THE APPLIANCE: 1. Press and hold the DEFROST button for 5 seconds. 2. The defrost cycle will start immediately and the Defrost LED illuminates. The defrost will last a maximum of 30 minutes. Note: starting a manual defrost also resets the automatic defrost timer. The next automatic defrost will start six hours after the manual defrost has finished.
- Page 14 Troubleshooting If your appliance develops a fault, please check the following table before call Omcan. Fault Probable Cause Action Compressor not Fuse blown or circuit breaker tripped. Replace fuse or reset circuit breaker. running. Power cord unplugged. Plug in power cord.
- Page 15 Parts Breakdown Model RS-CN-0009-PSS 46497 Model RS-CN-0006-PSS 46657 Model RS-CN-0004-PSS 46658...
- Page 16 Parts Breakdown Model RS-CN-0009-PSS 46497 Item No. Description Position Item No. Description Position Item No. Description Position AD812 Body for 46497 AD819 Power Cord for 46497 AD826 Sensor for 46497 Stainless Steel Pan Cover for AD813 Cover Hinge Left for 46497...
- Page 17 Electrical Schematics Model RS-CN-0009-PSS 46497 Model RS-CN-0006-PSS 46657 Model RS-CN-0004-PSS 46658...
- Page 18 Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...
- Page 19 Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
- Page 20 à plus de 6500 produits provenant du monde entier. Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir a nuestro compromiso de fortalecer y desarrollar nuevas relaciones...
