- Page 1 2.4GHz FHSS DIGITAL PROPORTIONAL R/CSYSTEM C7-MINI VERSIONNUMBER： V1.0.0 PRODUCT MANUAL Please read the manual before use www.microzone.cn...
- Page 2 Charging Lamp Signal/fixed speed switch light Fixed speed switch Pusher2 POWER LAMP Engine switch Car speed/Emergency brake switch Pusher1 Throttle Car light switch Rocker Rocker Menu / OK Previous one Next Exit Key locking Power switch Type-c charging port www.microzone.cn...
- Page 3 2.4GHz FHSS DIGITAL PROPORTIONAL R/CSYSTEM REMOTE CONTROL SPECIFICATIONS AND PARAMETERS Model C7-MINI PRO Color Orange-black/Blue-black/Red-black Display color Black and white 128*64 px Language Chinese/English Remote control lawn mowers / Applications Remote control agricultural machinery / Transport tank vehicles / Photovoltaic cleaning robots...
- Page 4 10 to 15 metres away, and then toggle the remote control rocker, to observe whether the device is controlled by the remote control, if controlled that the remote control and the receiver is working properly. www.microzone.cn...
- Page 5 LOW VOLTAGE ALARM: When the voltage of the remote control is lower than 6.8V, it will tick and the battery icon will flash,prompting you that the power is low, please charge it as soon as possible. www.microzone.cn...
- Page 6 Then toggle the lever to the center position as shown below,finally toggle the car speed/emergency brake switch,the sound will stop and the power indicator and signal/fixed speed switch indicator will stop flashing alternately,calibration is complete. Car speed/Emergency brake switch www.microzone.cn...
- Page 7 <MENU> key, <EXIT> key, < > key, < > key are ineffective, and the lock symbol will appear on the page, then long press <Key locking> key for 2 seconds to unlock the key. Key locking www.microzone.cn...
- Page 8 <⇧> key or <⇩> key to modify the fine-tuning value, then press <MENU> key to finish. REVERSE: The operation direction of channels 1-4 can be reversed; Press <⇧> key or <⇩> key to select the corresponding channel and press <MENU> key to finish. www.microzone.cn...
- Page 9 When there is no menu selection in the main page, press <MENU> key, then press <⇧> key or <⇩> key to select “SYS SET”, and then press <MENU> key to enter the SYS SET, you can press <⇧> key or <⇩> key to select the corresponding option, and then press <MENU> key to enter. www.microzone.cn...
- Page 10 Left joystick controls forward, backward, left turn and right turn, right joystick is invalid; Press <⇧> key or <⇩> key to select the corresponding option, then press <MENU> key to confirm. LANGUAGE: Support Chinese/English Press <⇧> key or <⇩> key to select the corresponding option, then press <MENU> key to confirm. www.microzone.cn...
- Page 11 Pause working, the screen will blink and make a sound, toggle the car speed/emergency brake switch backward to turn off the emergency brake; Press <⇧> key or <⇩> key to select the corresponding option, then press <MENU> key to confirm. Car speed/Emergency brake switch www.microzone.cn...
- Page 12 Press <⇧> key or <⇩> key to select “YES”, then press <MENU> key to confirm. MIX SET: Bind the two channels of the receiver together accept one channel control of the remote control for linkage; Press <⇧> key or <⇩> key to select the corresponding option, then press <MENU> key to confirm. www.microzone.cn...
- Page 13 Read this guide and follow the instructions. 11. The remote control and receiver required for our company's 2.4G wireless transmission system are used in pairs, while other company products cannot be connected to our company's products The product is of great value. www.microzone.cn...
