iRobot Create Open Interface
Sensor Packets
Create sends back one of 43 different sensor data packets,
depending on the value of the packet data byte, when
responding to a Sensors command, Query List command,
or Stream command's request for a packet of sensor data
bytes. Some packets contain groups of other packets.
Some of the sensor data values are 16 bit values.
Most of the packets (numbers 7 – 42) contain the value of
a single sensor or variable, which can be either 1 byte or 2
bytes. Two-byte packets correspond to 16-bit values, sent
high byte first.
Some of the packets (0-6) contain groups of the single-
value packets.
Wait Event: Unsigned Equivalent of Inverse
Group Packet ID
Packet Size
0
26 bytes
1
10 bytes
2
6 bytes
3
10 bytes
4
14 bytes
5
12 bytes
6
52 bytes
Bumps and Wheel Drops
Packet ID: 7
The state of the bumper (0 = no bump, 1 = bump) and wheel
drop sensors (0 = wheel raised, 1 = wheel dropped) are sent
as individual bits.
Range: 0 - 31
Bit
7
6
5
4
Wheeldrop
Sensor n/a n/a n/a
Caster
Wall
Packet ID: 8
The state of the wall sensor is sent as a 1 bit value
(0 = no wall, 1 = wall seen).
Range: 0 – 1
Cliff Left
Packet ID: 9
The state of the cliff sensor on the left side of Create is
sent as a 1 bit value (0 = no cliff, 1 = cliff).
Range: 0 – 1
iRobot Create Open Interface (OI) Specification
Contains packets
7 - 26
7 - 16
17 - 20
21 - 26
27 - 34
35 - 42
7 - 42
Data Bytes: 1
unsigned
3
2
1
Wheeldrop
Wheeldrop
Bump
Left
Right
Left
Data Bytes: 1
unsigned
Data Bytes: 1
unsigned
Cliff Front Left
The state of the cliff sensor on the front left of Create is
sent as a 1 bit value (0 = no cliff, 1 = cliff).
Range: 0 – 1
Cliff Front Right
The state of the cliff sensor on the front right of Create is
sent as a 1 bit value (0 = no cliff, 1 = cliff)
Range: 0 – 1
Cliff Right
The state of the cliff sensor on the right side of Create is
sent as a 1 bit value (0 = no cliff, 1 = cliff)
Range: 0 – 1
Virtual Wall
The state of the virtual wall detector is sent as a 1 bit value
(0 = no virtual wall detected, 1 = virtual wall detected).
Note that the force field on top of the Home Base also trips
this sensor.
Range: 0 – 1
0
Low Side Driver and
Wheel Overcurrents
Bump
Right
The state of the three Low Side driver and two wheel
overcurrent sensors are sent as individual bits (0 = no
overcurrent, 1 = overcurrent).
Driver
LD0
LD1
LD2
Wheels
Range: 0 - 31
Bit
7
6
Motor
n/a n/a n/a Left Wheel Right Wheel LD-2
Packet ID: 10
Packet ID: 11
Packet ID: 1
Packet ID: 13
Packet ID: 14
Current Limit
0.5A
0.5A
1.6A
1.0A
5
4
3
2
Data Bytes: 1
unsigned
Data Bytes: 1
unsigned
Data Bytes: 1
unsigned
Data Bytes: 1
unsigned
Data Bytes: 1
unsigned
1
0
LD-0
LD-1
17
