Create | Advanced
DJ Create
So you want to impress your friends with a roaming,
robotic DJ at your next party, but that speaker that you
glued on top of your Create
off. Follow along here and see how you can build your
own DJ Create.
Get ready to rock with a roaming, robotic DJ! We will
show you how put two speakers and a Bluetooth module
into your Create 2 bin for less than $15 in parts.
Overview
Preparing your electronics
1)
Remove all of your electronics from their packaging
and lay them out on your work surface.
2)
Choose which speaker will be the left and which will
be the right and label them accordingly.
Wiring the audio amplifier board
1)
Connect each speaker to the corresponding screw-
down terminals on the amplifier board. Be careful to
observe the correct speaker polarities, but getting
them wrong won't blow anything up.
2)
Connect the battery holder to the corresponding
power connections on the amplifier board. Be careful
to observe the correct polarities—positive voltage to
the "+" terminal (usually a red wire), negative to the
"-" terminal (usually a black wire). Getting this wrong
will likely damage the amplifier.
(See diagram on the next page.)
2 keeps getting knocked
®
STEM Skills:
•
Mechanical
•
Electrical
Experience Level:
Advanced
Supplies:
•
iRobot Create 2
•
Screwdrivers (#1 Phillips
& Small Flathead)
•
Hot Glue Gun
•
Soldering Equipment
•
Wire Cutters/Strippers
•
Heat Shrink Tubing or
Electrical Tape
•
Flexible Wire
•
Rotary Cutting Tool
•
Hook and Loop Fastener
•
Battery Holder with
Cover and Switch for
4 AA Batteries (ex.
SparkFun PRT-12083)
•
2 Thin .5W Speaker (ex.
SparkFun COM-15350)
•
Stereo Bluetooth
Amplifier Board (ex.
SparkFun DEV-17224)
Additional Resources
•
Getting Started
with Create 2
Advertisement
Related Manuals for iRobot DJ Create
Summary of Contents for iRobot DJ Create
- Page 1 • Electrical ® off. Follow along here and see how you can build your own DJ Create. Experience Level: Get ready to rock with a roaming, robotic DJ! We will Advanced show you how put two speakers and a Bluetooth module into your Create 2 bin for less than $15 in parts.
- Page 2 SPK2+ SPK2– SPK1– SPK1+ POWER– POWER+ POWER Testing your electronics Install 4x AA batteries into the battery holder and slide the power switch to ON. A blue LED on the Bluetooth module should start flashing and the speakers should beep to indicate pairing mode.
- Page 3 Separate the upper and lower bin housings. Remove the screws holding the vacuum fan in place and slide it out of the bin. Use a flathead screwdriver to release the four snap clips holding the top cover on. Remove the cover and pull the vacuum impeller off of the motor shaft. This can be achieved by twisting and pulling or by prying from underneath with a flathead screwdriver.
- Page 4 Use a rotary cutting tool to trim the vacuum housing pieces in half to create space in the bin for the speakers. Reinstall the smaller plastic piece and the latch spring into the top bin housing and screw it into place. Make sure you have the plastic latch seated properly too. Turn on your hot glue gun and apply glue to the two pivot arms on the latch at the back edge of the bin.
- Page 5 This will prevent the components from rattling around in the bin and possibly shorting against each other. Install your new DJ Create 2 bin into the robot, turn on the power, and enjoy the music! Optional Upgrade #1: Upgrade your battery pack Replace your 4xAA battery holder with a portable USB power bank.
- Page 6 Optional Upgrade #2: Power your electronics using Create’s internal battery Connect a 5V UBEC (Buck) Converter to the dust bin electrical contacts and use power from your Create 2 internal battery to power your electronics. Shopping List: • UBEC DC/ DC Step-Down (Buck) Converter – 5V @ 3A Output (Ex. Adafruit 1385) •...
- Page 7 So What’s Next? Start your party! Your DJ Create can roam the house, wake you up to your favorite tunes, or just be your best buddy singing along with you. Don’t worry, there’s no camera so dance like no one is watching! Share your project with Create@irobot.com...
