Congratulations, and welcome to the fabulous world of RX6640/7340 ownership, where serious work is made fun again!

This versatile tractor is a culmination of the entire tractor and diesel knowledge gained by the Daedong IND. Co., LTD

over the years since 1947 and has been designed with the finest materials, under rigid quality control standards.

Knowledge of tractor operation is essential for many years of dependable service and reliability. To help new owner's

familiarize themselves with the KIOTI RX6640/7340, an owner's manual with helpful information regarding safe operation

and maintenance has been provided with your purchase. If the information you seek is not found in this manual, please

contact your authorized KIOTI dealer for assistance.

Please feel free to contact KIOTI with your questions/concerns.

< NOTE >

Read this manual carefully and keep it handy for future reference.



When leasing or transferring this tractor, deliver this manual together with the tractor.



The specifications in this manual are subject to change without notice.


