  • Page 1 User’s manual FLIR Si2 series...
  • Page 2 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
  • Page 3 Table of contents Safety information ................1 Radio ..................1 Handling and operation .............. 1 Battery and charging ..............1 Declaration of conformity ............2 Notice to user ...................3 Register your camera..............3 Online documentation..............3 About this manual ..............3 Support ..................
  • Page 4 12.7 Device info ................29 FLIR Acoustic Camera Viewer ............30 13.1 Setup ................... 30 13.2 Create a FLIR Acoustic Camera Viewer account......30 13.3 Connect the camera to the internet ..........30 13.4 Pairing.................. 31 13.5 Automatic upload..............31 13.6...
  • Page 5 Table of contents 15.3 Calibration................34 Updating the camera................ 35 16.1 Update the camera wireless (Wi-Fi) ..........35 16.2 Update the camera via USB memory stick ........35 16.3 Update the camera from Device ..........36 Disposal of electronic waste ............. 37 17.1 Battery removal ..............
  • Page 6 Keep the USB port covered to prevent water ingress. • Do not look directly at the LED lights placed on the microphone panel. • Only use the accessories and spare parts that FLIR provides. • Do not disassemble the camera. •...
  • Page 7 Safety information 1.4 Declaration of conformity The full text of the Declaration of conformity is available at the following internet address: http://support.flir.com/resources/f34f. #T810637; r. AG/105330/105330; en-US...
  • Page 8 To register the camera, go to http://support.flir.com/camreg. To access the registration form, you must log in to your FLIR account or sign up for a new account. You will also need the serial number of your camera. A label with the serial number is available at the bottom of the camera.
  • Page 9 Distance (FLIR Si2-LD and FLIR Si2 Pro), and Advanced AI for optimal performance and data accuracy (all models). For enterprise-level customers the FLIR Si2 series also provides easy data export for re- porting and worksheets, Fleet Management tools, automatic data upload and online stor- age, and API Data Integration for a seamless asset health data transfer into your preferred Asset Management software.
  • Page 10 To enable upload, you must connect the camera to the internet and pair the camera with the FLIR Acoustic Camera Viewer cloud service. Use a computer or other device with internet access and follow the in- structions on the camera screen.
  • Page 11 Camera parts 5.1 View from the front 1. Microphones 2. LED lamps 3. Digital camera #T810637; r. AG/105330/105330; en-US...
  • Page 12 Camera parts 5.2 View from the rear 1. LCD screen 2. Neck strap attachment points 3. Battery cover #T810637; r. AG/105330/105330; en-US...
  • Page 13 Camera parts 5.3 View from the top 1. USB port 2. On/Off button 3. Heat sinks 4. Power LED 5.4 E-label The e-label is the primary identification plate for the camera. It contains certification and compliance information and other relevant product details. The e-label is available in the camera settings: 1.
  • Page 14 User interface 6.1 General 1. Acoustic image 2. Frequency view 3. Zoom button 4. Quick menu button 5. Analysis results (mode specific) 6. Settings button 7. Archive button 8. Snapshot button 9. Record button 10. Selected mode 11. Wi-Fi indicator 12.
  • Page 15 An animated upload progress spinner in the circled area indicates that files are being up- loaded to the FLIR Acoustic Camera Viewer cloud service. Snapshots are automatically removed from the camera, after they have been uploaded to the FLIR Acoustic Camera Viewer cloud service or exported to a USB memory stick.
  • Page 16 Basic operation 7.1 Safety information Before operating the camera, you must read, understand, and follow the warnings and cautions in section 1 Safety information. 7.2 Battery 7.2.1 Battery cover To remove the battery cover, push the ends of the cover. Then lift the cover off the camera.
  • Page 17 Basic operation 7.2.5 Low battery warning The battery indicator in the camera live view UI turns red to indicate insufficient battery charge. The color code in the UI displayed in the battery changes from green (full bat- tery), orange to red (low battery). 7.3 Battery charging CAUTION When you connect the power supply to a mains socket, select a socket that is easy to access.
  • Page 18 Note • Snapshots and videos are automatically removed from the camera, after they have been uploaded to the FLIR Acoustic Camera Viewer cloud service or exported to a USB memory stick. • The number of files in the archive is displayed next to the Archive button.
  • Page 19 Tap the Zoom button to cycle through the available zoom options: 1x, 2x, and 8x. 7.9 File transfer Snapshot and video files from the camera can be imported to the FLIR Acoustic Camera Viewer or opened in FLIR Thermal Studio for further analysis and reporting.
  • Page 20 • It is easier to find the location of the sound source if you move the camera around and look at the source from different angles. • Analyzing snapshots and videos in the FLIR Acoustic Camera Viewer or in FLIR Ther- mal Studio can help you find the exact location of a sound source.
  • Page 21 Locating sound sources Filters according to setting manually the lower and upper frequency limits, use in case for further inspections, enable the Frequency view by toggling the Frequency View button, see section 8.2.4 Frequency view. 8.2.3 Change the filter setting To change the filter setting, tap the Filter button repeatedly and cycle through the filter options.
  • Page 22 Locating sound sources 3. Adjusting frequency limits. • Using handles. Drag the handles at the extremes to set the frequency detection limits, the frequency range is shown at the bottom as reference and represented in kHz. The selected frequency region will appear highlighted as a rectangular area.
  • Page 23 When capturing several snapshots from different angles, use the one that displays the highest SPL levels. This will facilitate further analysis. By adjusting the dynamic range in FLIR Acoustic Camera Viewer or FLIR Thermal Studio. Move the slide bar to increase or decrease the SPL value. This will make it possible to make the sound sources more or less prominent for reporting and representation.
  • Page 24 9. You can take snapshots and videos of the detected leak for further inspection and re- porting in the FLIR Acoustic Camera Viewer or FLIR Thermal Studio. 9.2 Leak analysis results The camera displays the following analysis results on the screen: •...
  • Page 25 When you take a snapshot of a detected leak, the camera saves also the current leak analysis parameters settings. This means you can edit the parameters later using the FLIR Acoustic Camera Viewer or FLIR Thermal Studio. • Leak unit The unit to use for the displayed leak size.
  • Page 26 • Leak type FLIR Si2 supports leak size estimation for different gas leaks, considering the energy, volume, or mass cost parameters to estimate the leak cost. Select "Other" from the leak type drop-down menu in the leak mode settings to disable leak size and cost estimations.
  • Page 27 Partial discharge detection Note The availability of the partial discharge detection feature depends on the camera model. When an electric component begins to fail, one of the first indicators is sound. This sound is caused by partial discharges, that signal the harmful flow of electricity and dete- riorate components over time.
  • Page 28 8. You can take snapshots and videos of the detected partial discharge for further in- spection and reporting in the FLIR Acoustic Camera Viewer or FLIR Thermal Studio. 9. To retrieve a PD analysis from your snapshot, tap the Archive button, select the de- sired PD snapshot, and then tap the PD Analysis button.
  • Page 29 Partial discharge detection 10.4.1 PRPD pattern The Phase-Resolved Partial Discharge pattern – or PRPD – is a widely used tool for anal- ysis and diagnosis of partial discharge activity. Partial discharge activity occurs due to defects in electrical components. Each “dot” in the PRPD pattern corresponds to an event caused by a discharging defect.
  • Page 30 7. You can take snapshots and videos of the detected faults for further inspection and reporting in the FLIR Acoustic Camera Viewer or FLIR Thermal Studio. 11.2 Mechanical Severity Indication (MSI)
  • Page 31 Mechanical fault detection • Once the acoustic map stabilizes, the device will indicate whether a potential mechan- ical failure is detected. The MSI detects unevenness or friction in sounds, which may indicate faults in some components but could be normal in others. Always compare results with a similar compo- nent in good condition.
  • Page 32 Mechanical fault detection The following measures typically indicate potential issues with bearings: • Sound Level Pressure - very high, especially combined with a low Crest factor • Crest factor - 6 or above • Kurtosis - 2 or above #T810637; r. AG/105330/105330; en-US...
  • Page 33 Connect the camera to a Wi-Fi network. For more information, see section 13.3 Connect the camera to the internet. Pair the camera with the FLIR Acoustic Camera Viewer. For more information, see sec- tion 13.4 Pairing. When the camera is connected to Wi-Fi, the IP address and SSID of the network is displayed.
  • Page 34 To obtain more accurate results, it is recommended to specify the rela- tive humidity. 12.6 Advanced settings • Calibration mode: This function is used together with the FLIR Acoustic Tester to check the accuracy of the camera. For more information, refer to the FLIR Acoustic Tester user manual.
  • Page 35 With the FLIR Acoustic Camera Viewer you can perform further analysis of detected leaks, partial discharges, and mechanical faults, and also generate inspection reports. To use the cloud service, you must create a FLIR Acoustic Camera Viewer account and pair the camera with the account.
  • Page 36 SSID or passkey. 13.4 Pairing To pair the camera with the FLIR Acoustic Camera Viewer, you need the serial number of your camera and also a secret code. These details are available in the camera settings.
  • Page 37 (.nlz) to the FLIR Acoustic Camera Viewer. Note Before importing the files, ensure that the camera used for capturing the snap- shots and videos is paired with your FLIR Acoustic Camera Viewer account and that the snapshots are not opened or modified in Thermal Studio.
  • Page 38 FLIR thermography cameras, as well as snapshots and videos from the FLIR acoustic imaging cameras. You can open files (.nlz) that you have uploaded to the FLIR Acoustic Camera Viewer or exported to a USB memory stick in FLIR Thermal Studio. To open camera snapshots in FLIR Thermal Studio, activate the Acoustic Plug-in.
  • Page 39 The camera undergoes calibration during production. No further re-calibration is necessary. The FLIR Acoustic Tester can be used to check the accuracy of the camera. For more in- formation, refer to the FLIR Acoustic Tester user manual. #T810637; r. AG/105330/105330; en-US...
  • Page 40 To access available updates, go to the "Update" option in the camera's Advanced set- tings or the FLIR Acoustic Camera Viewer. Log in to your account, or create one if you haven't yet, and ensure your camera is paired. For more information, see section 13 FLIR Acoustic Camera Viewer.
  • Page 41 Updating the camera 10. Follow the instructions on the camera screen. Note Do not remove the USB memory stick while the update is being copied. 11. When the update has been copied, remove the USB memory stick and put the USB port cover back in place.
  • Page 42 Disposal of electronic waste Waste of Electrical and Electronic Equipment (WEEE) poses a risk to human health and the environment when not disposed of properly. This product should not be discarded as unsorted waste but must be sent to separate collection facilities for recovery and recy- cling.
  • Page 43 18.7 Copyright © 2025 FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in- cluding source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, opti- cal, manual or otherwise, without the prior written permission of FLIR Systems.
  • Page 44 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T810637...
