QUICK START GUIDE
Hose Reel
Unloader Valve
Control Valve
ASSEMBLY INSTRUCTIONS/PRESSURE WASHER
1
Remove jetter nozzle from
High pressure hose.
Attach hose using teflon tape.
5
Open
valve
to
eliminate
trapped air.
1.107-536.0 - HD 3.3/25 J JETTER
Pulse Valve
2
Attach wand to spray gun.
6
Connect garden hose to cold
water source.
Engine
Pump
3
Pull spring-loaded to insert
your choice of pressure nuzzle.
7
Close pulse valve.
Anti-Siphon
Valve
4
Pull tenozzle to make sure it
is forward until secure.
9.808-474.0_A
Advertisement
Related Manuals for Kärcher HD 3.3/25 J JETTER
Summary of Contents for Kärcher HD 3.3/25 J JETTER
- Page 1 Attach wand to spray gun. Attach hose using teflon tape. your choice of pressure nuzzle. is forward until secure. Open valve eliminate Connect garden hose to cold trapped air. water source. Close pulse valve. 1.107-536.0 - HD 3.3/25 J JETTER 9.808-474.0_A...
- Page 2 Always leave The pulse control valve is located on ball valve in open position when the front of the pump, turn valve on Pull the starter grippo. turning off engine. to engage the pulse. 1.107-536.0 - HD 3.3/25 J JETTER 9.808-474.0_A...
