Summary of Contents for Van Guard 1400-CDCK
- Page 3 Operation Manual image through the eyepieces while also Figure 6 using the camera port. Model 1400-CDCK Parfocality can be set by loosening the two set screws (figure 6a; 1300 & 1400 Series only) or the knurled knob (figure 8a; 1490 Series only) located on the camera port, then threading the silver tube (figure 6b;...
- Page 4 Included Parts Remove the camera body dust cap A. DSLR Camera Adapter (1 ea) (figure 2a) by rotating counter- B. 30mm Reduction Adapter (1 ea) C. T-Ring Adapter (1 ea) clockwise and pulling it free (figure 2). Not Pictured - Camera and Accessories Figure 2 Line up the red alignment dots on the camera adapter to the dot on the...
