- Page 1 Operation Manual 1400 Series Covering Models: 1420BR, 1421BR, 1430BR, 1431BR, 1423PH & 1433PH...
-
Page 2: Table Of Contents
We recommend you read this entire manual carefully before setting up and using the instrument. 1400 Series Compound Microscopes The 1400 Series Compound Microscopes are the flagship of the Table of Contents VanGuard Microscope Line. Combining top performance with highly-advanced features and optics, the 1400 Series models produce images of the utmost in clarity. -
Page 3: Parts & Accessories
Parts & Accessories Included Parts: Model 1420BR Model 1421BR Model 1430BR Binocular Head (1 ea.) Binocular Head (1 ea.) Trinocular Head (1 ea.) Stand (1 ea.) Stand (1 ea.) Stand (1 ea.) Brightfield Condenser (1 ea.) Brightfield Condenser (1 ea.) Brightfield Condenser (1 ea.) 10X Eyepiece (2 ea.) 10X Eyepiece (2 ea.) -
Page 4: Optional Accessories
Parts & Accessories Optional Accessories: 35mm, Video, and Digital Camera Systems: Part Number: Description: 1400-CDPC-10 USB Digital Camera Kit with Adapaters and Microscopy Software, 10 Megapixels 1400-CDPC-5 USB Digital Camera Kit with Adapaters and Microscopy Software, 5 Megapixels 1400-CDPC-3 USB Digital Camera Kit with Adapaters and Microscopy Software, 3 Megapixels Other Accessories: Part Number: Description:... -
Page 5: Microscope Diagrams
1400 Series Parts Camera Port Dust Cap Diopter Adjustment Mechanism Eyepieces Head Assembly Camera Port Prism Slider Head Set Screw Interpupillary Adjustment Mechanism Nosepiece Objectives Stand Slide Holder Slide Holder Mechanical Stage Knobs X-Y Mechanical Condenser Centering Stage Controls Knobs... - Page 6 1400 Series Parts 1400 Series Lower Left View Substage Adjustment Knob Up-Stop Mechanism Variable Lighting Control Power Switch 1400 Series Rear View Carrying Handle Power Cord Jack...
-
Page 7: Setup
Setup Assembly All Models All part names in italics are illustrated on pages 5 or 6. After removing the microscope parts from the protective foam packaging and checking it over for all components and accessories (a list is provided on page 3), you can begin assembly. - Page 8 Setup Assembly All Models (continued) After removing the objectives from their storage containers, individually install each one into the nosepiece by twisting them counterclockwise into the threaded holes of the nosepiece (see figure 4). Figure 4 If not already in place, install the condenser assembly into the condenser mount. Raise the substage and stage to their maximum height (see figure 5).
-
Page 9: Centering The Condenser
Note: If you purchased a 1420BR, 1421BR, 1430BR or a 1431BR this step completes the setup. Skip ahead to page 11, “Using Your 1400 Series Microscope.” If you purchased a 1423PH or a 1433PH, continue on to the next page,... -
Page 10: Aligning The Phase Contrast Annulus Rings
Setup Aligning the Phase Contrast Annulus Rings 1400PH Phase Contrast Models Phase contrast is a system which involves a series of light baffling annular rings. Proper alignment of these rings is absolutely necessary to achieve optimum phase contrast. Begin by turning on the substage illuminator with the power switch located on the lower left side of the instrument. -
Page 11: Using Your 1400 Series Microscope
Using Your 1400 Series Microscope Focusing and Mechanical Stage Mechanisms All Models Focusing adjustment is achieved by turning the coarse/fine focus controls (see figures 9 and 10). The large knob is used for coarse adjustment, the smaller knob for fine adjustment. The coaxial arrangement allows for easy, precise adjustment without stage drift. -
Page 12: Interpupillary & Diopter Adjustments
Using Your 1400 Series Microscope Interpupillary and Diopter Adjustments All Models Interpupillary adjustment (the distance between eyepieces) is made through a “folding” action. The Seidentopf design allows for a folding adjustment which is quickly and easily done for each user (see figure 11). Diopter adjustment allows for proper optical correction based on each individual’s eyesight. -
Page 13: Using The Camera Port
(see figure 13). Note: The 1400 Series Microscopes utilize a 70/30 split sliding prism. This split prism diverts 70% of the light to the camera port and the remaining 30% to the eyepieces. This allows the eyepieces to be used while the prism slider is pulled out, although the image seen through the eyepieces will be dim when compared to normal use. -
Page 14: Maintenance
Maintenance Replacing the Lamp All Models Before attempting to replace or remove the lamp, UNPLUG THE MICROSCOPE FROM ANY POWER SOURCE AND ALLOW SUFFICIENT TIME FOR THE LAMP TO COOL. Lamp replacement is done by laying the microscope on its back and opening the trap door located on the bottom of the base by pulling on the release knob (see figure 15). -
Page 15: Specifications
Specifications 1400BR and 1400PH Microscopes Viewing Head: Binocular or Trinocular Viewing Head Type: Seidentopf Head Rotation: 360° Head Inclination: 30° Sliding Prism: 70/30 Split [Trinocular Models] Interpupillary Adjustment: 55-75mm Dioptric Adjustment: -5 to +5 Eyepiece Magnification: 10X Widefield Eyepiece Field Diameter: 18mm Nosepiece: Quadruple/Reversed [1400BR]... -
Page 16: Warranty
Warranty & Service 5 Year Limited Warranty If you experience problems setting up your microscope or have service related questions VanGuard microscopes are warranted by VEE GEE Scientific LLC please contact your dealer or VanGuard to be free from defects in material and workmanship for a period Microscopes directly at 1-800-423-8842. - Page 17 Printed in the USA No. VGMNL081919-1400BR/PH...
