Summary of Contents for Conquip Trench Box
- Page 1 User Guide Trench Box...
- Page 2 Product Information Overview A trench lining system for trench ground support. The Conquip Trench Box is a two sided, simple to assemble, trench lining support system designed to be installed by simply lowering the box into the excavation via a crane.
- Page 3 Height (Min - Max) (Min - Max) Base Box TL101-00009 1500mm 1050-2960mm 110mm 11100N Base Box TL101-00009 4000mm 1270-3170mm 2400mm 2995-3200kg Extension Box TL101-00010 1500mm 1050-2960mm 110mm 11100N Extension Box TL101-00010 4000mm 1270-3170mm 1920mm 1995-2200kg User Guide - Trench Box...
- Page 4 Extension Box TL101-00010 4000mm 1920mm 900kg 3560mm Two Section 1060-2260mm 1270-2470mm 76.9kg 308kg Three Section 1760-2960mm 1970-3170mm 99.6kg 400kg Base and extension boxes require 4 strut assemblies per box. These weights includes rockers and pins. User Guide - Trench Box...
- Page 5 Product Information Parts Diagram Parts Diagram Trench Base Box Trench Extension Box NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries. Item Number Part Number Description Quantity NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries.
- Page 6 Fig 1.1 Fig 1.2 Important Usage Instructions • No personnel should be in the trench when the Trench Box is being installed or removed. • The Trench Base Box is craned into the trench first at the required width. •...
- Page 7 40mm Ø pin and R-clip. possible. However, if the ground is too hard, or if using the High Clearance Adaptor, lower the Trench Box into the trench with lifting chains. Installation Instructions 1. Excavate the ground to approximately one metre or deeper, as ground conditions permit.
- Page 8 Usage Instructions Extraction Instructions 12. Remove the R-clips, pins and the connectors from the base box. 1. Backfill the trench around the Trench Box. 2. Attach a certified lifting chain to one of the top lifting points on the extension box.
- Page 9 Your risk assessment will determine the correct Personal Protective Equipment (PPE) for the task you are doing. You must use it. Conquip recommends that you should wear: • This equipment weighs more than 25kg. Do not lift or manhandle without machine assistance.
- Page 10 Modifications If any third-party modifications or alterations, involving drilling, welding, cutting or distortion of materials in any form, are to be carried out on the product, Conquip Engineering Group must provide full written approval Product prior to the work being carried out.
- Page 11 Important Notes • This User Guide is for this Conquip product only. • Any movements of the product must be thoroughly planned before the work commences to identify potential hazards and assess risk. • All personnel involved in lifting and transportation of this product must have read this User Guide and must be properly briefed.
