Summary of Contents for Conquip Drag Box
- Page 1 User Guide Drag Box...
-
Page 2: Specification
TL100-00011 Product Information Overview The Conquip Drag Box is a simple to assemble, edge-supported trench lining system intended to be installed by an excavator using the excavate and drag technique. They are designed to provide local support for trenches as transportable ‘shields’... -
Page 3: Parts Diagram
Drag Box Extension Box NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries. NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries. -
Page 4: Usage Instructions
3. The plate hole aligns with a slot in the bottom of the extension panel. Once (flat face up) and lift into position above the struts. aligned, insert the 45mm pin from the inside of the drag box so the pin hides within the depth of the box. - Page 5 1. Excavate initial section of the trench to the dimensions of the Drag Box base box. 2. Using an excavator or crane lift and lower the Drag Box into the trench, with a suitably rated 4 leg chain. If an extension box is to be used, lift and lower into the trench and connect to the Base Box.
-
Page 6: Safety Instructions
Your risk assessment will determine the correct Personal Protective Equipment (PPE) for the task you are doing. You must use it. Conquip recommends that you should wear: •... - Page 7 If any third-party modifications or alterations, involving drilling, welding, cutting or distortion of materials in any form, are to be carried out on the product, Conquip Engineering Group must provide full written approval •...
-
Page 8: Ec Declaration Of Conformity
In accordance with EN ISO 17050-1:2004 Declaration: As defined by the Machinery Directive 2006/42/EC and subsequent amendments We, CONQUIP ENGINEERING GROUP, herewith declare that the following indicated equipment meets the fundamental health and safety requirements concerning the EU guide line(s), due to their design and manufacture. -
Page 9: Important Notes
Important Notes • This User Guide is for this Conquip product only. • Any movements of the product must be thoroughly planned before the work commences to identify potential hazards and assess risk. • All personnel involved in lifting and transportation of this product must have read this User Guide and must be properly briefed.
