DORCHESTER

CAST IRON STOVE

PART NO: 6909954

USER GUIDE

ORIGINAL INSTRUCTIONS

21 Mar 23 GC Rev 1

Need help?

Do you have a question about the DORCHESTER and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke DORCHESTER

Page 1 DORCHESTER CAST IRON STOVE PART NO: 6909954 USER GUIDE ORIGINAL INSTRUCTIONS 21 Mar 23 GC Rev 1...
Page 2 INTRODUCTION Thank you for purchasing this CLARKE Stove which is approved for use in smoke-controlled zones. It is designed and produced according to the standard EN13240+Amendment A2:2004. The stove is supplied with various loose components including the lining panels, baffle plate, log retainer, ash pan and tool which require checking for correct fitting.
Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 & ERP COMPLIANCE Item Symbol Value Unit Fuel Dry wood/logs Space Heating Emission(*) Indirect heating fuctionality: [yes/no] Heat Output At nominal heat output Pnom At minimum heat output (indicative) Pnom At maximum heat output Pmax Auxiliary electricity consumption At nominal heat output...
Page 4 GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
Page 5 CLEAN AIR ACT 1993 & SMOKE CONTROL AREAS Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed boiler if located in a designated smoke control area.
Page 6 OPERATION WITH DOOR LEFT OPEN Operation with the door open can cause excess smoke. DO NOT operate the stove with the door open except when re-fuelling. DAMPERS LEFT OPEN Operation with the air controls or appliance dampers open can cause excess smoke.
Page 7 GENERAL SAFETY RULES WARNING: THIS STOVE WILL BE HOT WHEN IN OPERATION AND DUE CARE SHOULD BE TAKEN. THICK GLOVES SHOULD BE USED TO OPERATE THE PRIMARY/SECONDARY CONTROLS OR REACHING INSIDE THE STOVE TO POSITION FUEL OR REMOVE ASH. 1. ALWAYS read and understand the manual before installing and commissioning the stove.
Page 8 • CLARKE Fire Cement (Part No 691000) • 13mm spanner • Hex key (supplied) A full range of flue pipes and fire cement is available from your CLARKE dealer. See pages 25- 26. 8 of 32 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
Page 9 6. If there are any gaps between the components, these should be filled with CLARKE fire cement to prevent smoke emissions. 9 of 32 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
Page 10 POSITIONING AND INSTALLATION REGULATORY COMPLIANCE In England and Wales, there are only two routes to legally install a domestic solid fuel or wood burning appliance. In other parts of the UK there are variations in legislation and processes. You can either: •...
Page 11 When the stove is positioned near a wall constructed of flammable material, the distances shown on Fig 3 must be adhered to. Alternatively, a heat shield may be used, mounted according to the position of the fireplace. A firewall must be at least 100mm thick and typically made of brick, or concrete/stone. MATERIAL CLEARANCES The stove must have a minimum clearance of 400mm to a combustible ceiling above.
Page 12 Flue pipes with a smaller cross-sectional area than that of the stove outlet should never be used and must not project into the chimney connector, such as to cause a restriction to the gas flow. Sizes of flues in chimneys are stipulated in Table 2 of the Building Regulations 2000 Approved Document “J”...
Page 13 FIG 4 External flue pipes should be “twin wall”. These retain the heat, enabling it to rise and disperse from the chimney. As an alternative approach, the calculation procedure within BS EN 13384-1 (2005) can be used as the basis for deciding whether a chimney design will provide sufficient draught.
Page 14 FLUE PIPE COMPONENTS REQUIRED FIG 5 A wide selection of flue pipes, connectors and other components as shown above is available from your CLARKE stockist. See page 25. 14 of 32 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
Page 15 INSPECTION & CLEANING Check that the chimney is in good condition, dry and free from cracks and obstructions. The diameter of the chimney should not be less than 150mm and not more than 230mm. If any of these requirements are not met, the chimney should be lined by a suitable method.
Page 16 Stove Air Supplies Stove with flue draught Permanently open vents as below: stabiliser If design air permeability>5.0m /(h.m ) then 300mm /kW for first 5kW of appliance rated output 850mm /kW for balance of appliance rated output If design air permeability<5.0m /(h.m ) then 850 /kW for balance of appliance rated output...
Page 17 FIG 6 A non-combustible register plate minimum 1.5 mm thick should be fitted to all installations between the flue and the building structure. It’s suitability and fit should be checked by a qualified stove installation engineer against the current Building Regulations App”J”.
Page 18 (e.g. a soot door or access through a register plate). Purpose-made soot doors and inspection lengths are available from the CLARKE range. Ensure that the whole length of the flue can be reached from the soot door.
Page 19 CARBON MONOXIDE ALARMS Due consideration should be given to the dangers of carbon monoxide poisoning following incomplete combustion of solid fuels in an enclosed space. Carbon monoxide detectors to BS EN 50291 are available for use in domestic premises and details are available in the official HETAS guide that can be viewed on their website at www.hetas.co.uk.
Page 20 USING YOUR STOVE STOVE CONTROLS WARNING: THE TEMPERATURE REACHED BY THESE ITEMS DURING OPERATION MAY CAUSE AN INJURY TO AN END-USER. AS THESE ARE INTENDED TO BE ADJUSTED DURING OPERATION, IT IS RECOMMENDED THAT A PROTECTIVE MITT IS WORN WHEN HANDING THESE PARTS. The amount of heat emitted by the stove is regulated using the air...
Page 21 • The use of damp wood will result in more soot and tar deposits being left in the chimney, flue and stove, and will not release heat if thermal energy is being used to drive out moisture from the fuel. The smoke control website includes details of fuels authorised for use in Smoke Control Areas but does not provide locations of Smoke Control Areas - the user should check with the Local Authority to determine if they are in a Smoke...
Page 22 4. After a couple of days burning at this level, increase the brightness & intensity of the fire gradually over the next 10 days. Full strength fires should not be used until completion of approx 20 days of mild use. Only from this time will the stove have been properly seasoned. It should be remembered that this procedure should be carried out at the beginning of each season of use in order to remove the moisture retained by the metal during the period of non-use.
Page 23 Be sure to remove the ash when the fire is at its lowest point, such as first thing in the morning. The CLARKE ASHVAC1200 Vacuum Cleaner is ideal for collecting ash and debris from stoves. See page 26.
Page 24 If the stove is purely ornamental, painting will provide a durable, attractive finish. If the stove is used for heating, a high temperature heat resistant paint (available from your CLARKE dealer) must be used, in either aerosol or brush applied form. Should rust become apparent, clean thoroughly with a wire brush and apply a suitable anti-rust treatment.
Page 25 FIRE ROPE Check the rope around the door and glass. If rope is in poor condition, replace with rope approved for this purpose. Inspect the fireproof door seal where fitted, to ensure there is an effective seal around the door and re-fix it if loose using stove rope adhesive.
Page 26 HETAS website, www.hetas.co.uk. ACCESSORIES Refer to the CLARKE website www.clarkeinternational.com for a full range of Flue Pipes & Cowls (both Vitreous Enamel or Stainless Steel) for use with this classic cast iron stove. See also the following accessories on page 26.
Page 27 Part No 6471130: 1200W Ash Vacuum Cleaner An extensive range of flue components is also available from your CLARKE stockist. ENVIRONMENTAL PROTECTION Recycle unwanted materials instead of disposing of them as waste. All unwanted accessories and packaging should be sorted and taken to a recycling centre for disposal in a manner which is compatible with the environment.
Page 28 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Fire difficult to Wood green, too damp Use recommended fuel. See start. or poor quality. pages 19-20. Logs are too large. When lighting, use small, dry Fire goes out. kindling. To maintain the fire use split logs. Air starvation Open air control.
Page 29 COMPONENT PARTS 29 of 32 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
Page 30 COMPONENT PARTS Flue collar Ashpan Fire rope gasket Ashpan handle Top panel Bottom vermiculite plate C/s screw 6x25 & Base panel Top air inlet tube Air inlet control bar holder Bolts Bolts Baffle plate 1 Log retainer Bolts Air inlet control bar 1 Baffle plate 2 Air inlet control bar 2 Grill...
Page 31 DECLARATION OF PERFORMANCE - UK 31 of 32 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
