- Page 1 WENTWORTH CAST IRON STOVE PART NO: 6910136 USER GUIDE GC0214...
-
Page 2: Technical Specifications
INTRODUCTION Thank you for purchasing this CLARKE Stove which is DEFRA approved for use in a smoke-controlled area. Before attempting to operate the stove, it is essential that you read this manual thoroughly and carefully follow all instructions given. In doing so you will ensure the safety of yourself and that of others around you, and you can also look forward to the product giving you long and satisfactory service. -
Page 3: Installation Of This Product
INSTALLATION OF THIS PRODUCT WARNING: AN ACCREDITED HEATING ENGINEER MUST CARRY OUT THE INSTALLATION OF THIS STOVE. ALTERNATIVELY, SHOULD A NON- ACCREDITED ENGINEER UNDERTAKE THE INSTALLATION, YOUR LOCAL BUILDING CONTROL OFFICER WILL BE REQUIRED TO APPROVE THE COMPLETED INSTALLATION UNDER BUILDING REGULATION “J”. IT IS AN OFFENCE UNDER UK LAW, NOT TO COMPLY WITH THIS MANDATORY REQUIREMENT.IF THE STOVE IS NOT FITTED CORRECTLY BY AN APPROVED PERSON, IT COULD RESULT IN A HOUSE FIRE OR CARBON MONOXIDE... -
Page 4: Safety Warnings For Your Guidance
SAFETY WARNINGS FOR YOUR GUIDANCE WARNING: THIS STOVE WILL BE HOT WHEN IN OPERATION AND DUE CARE SHOULD BE TAKEN. THICK GLOVES SHOULD BE USED TO OPERATE THE PRIMARY/SECONDARY CONTROLS OR REACHING INSIDE THE STOVE TO POSITION FUEL OR REMOVE ASH. CAUTION: FIRES CAN BE DANGEROUS - Always use a fireguard in the presence of children, the elderly or the infirm. -
Page 5: General Safety Rules
GENERAL SAFETY RULES 1. Always read and understand the manual before installing and commissioning the stove. 2. Always ensure the stove is installed in accordance with local regulations. 3. Always ensure that the stove is correctly installed and positioned as described under POSITIONING AND INSTALLATION, and that the immediate area is kept clear. -
Page 6: Unpacking And Assembly
• Clarke Fire Cement • 14mm spanner • 12 mm spanner • x-head screwdriver A full range of flue pipes and fire cement is available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 7 1. Lay the stove down on a soft surface such as the packing materials from the crate. 2. Attach the legs using the studs, nuts and washers supplied as shown in Fig 1. Tighten the studs using the spanner. 3. Sit the stove upright and attach the flue adaptor as shown in Fig 2 using the screws supplied.
-
Page 8: Positioning And Installation
POSITIONING AND INSTALLATION REGULATORY COMPLIANCE In England and Wales, there are only two routes to legally install a domestic solid fuel or wood burning appliance. In other parts of the UK there are variations in legislation and processes. You can either: •... -
Page 9: Material Clearances
When the stove is positioned near a wall constructed of flammable material, the distances shown on Fig 4 must be adhered to. Alternatively, a heat shield may be used, mounted according to the position of the fireplace. A firewall must be at least 100mm thick and typically made of brick, or concrete/stone. MATERIAL CLEARANCES The stove must have a minimum clearance of 1200 mm to a combustible ceiling above. -
Page 10: Flue Height
“J”. A range of suitable flue pipes, cowls and fire cement are available from your Clarke dealer. Special methods are required when passing through a wall or ceiling. Please refer to your local building regulations and/or fire department. Refer to Building Regulations Document “J”. - Page 11 FIG 5 External flue pipes should be “twin wall”. These retain the heat, enabling it to rise and disperse from the chimney. As an alternative approach, the calculation procedure within BS EN 13384-1 (2005) can be used as the basis for deciding whether a chimney design will provide sufficient draught.
-
Page 12: Inspection And Cleaning
INSPECTION & CLEANING Check that the chimney is in good condition, dry and free from cracks and obstructions. The diameter of the chimney should not be less than 150mm and not more than 230mm. If any of these requirements are not met, the chimney should be lined by a suitable method. -
Page 13: Connection To The Chimney
Stove Air Supplies Stove with flue draught Permanently open vents as below: stabiliser If design air permeability>5.0m /(h.m ) then 300mm /kW for first 5kW of appliance rated output 850mm /kW for balance of appliance rated output If design air permeability<5.0m3/(h.m ) then 850 /kW for balance of appliance rated output Stove with no flue draught... - Page 14 FIG 6 A non-combustible register plate minimum 1.5 mm thick should be fitted to all installations between the flue and the building structure. It’s suitability and fit should be checked by a qualified stove installation engineer against the current Building Regulations App”J”.
-
Page 15: Cleaning The Flue
(e.g. a soot door or access through a register plate). Purpose-made soot doors and inspection lengths are available from the Clarke range. Ensure that the whole length of the flue can be reached from the soot door. -
Page 16: Carbon Monoxide Alarms
CARBON MONOXIDE ALARMS Due consideration should be given to the dangers of carbon monoxide poisoning following incomplete combustion of solid fuels in an enclosed space. Carbon monoxide detectors to BS EN 50291 are available for use in domestic premises and details are available in the official HETAS guide that can be viewed on their website at www.hetas.co.uk. -
Page 17: Using Your Stove
USING YOUR STOVE THE CONTROLS WARNING: THE TEMPERATURE REACHED BY THESE ITEMS DURING OPERATION MAY CAUSE AN INJURY TO AN END-USER. AS THESE ARE INTENDED TO BE ADJUSTED DURING OPERATION, IT IS RECOMMENDED THAT A PROTECTIVE MITT IS WORN WHEN HANDING THESE PARTS. The amount of heat emitted by the stove is regulated using the air control (A) built into the door and to a lesser... - Page 18 The control knob (D) near the side of the stove is for riddling the grate section, causing loose ash to fall into the ashpan. SUITABLE FUELS This stove can be used in smoke controlled zones to burn wood/logs will function with wood or coal, but in general all fuel should be dry and timber should be well seasoned so as to have a moisture content below 20%.
-
Page 19: Initial Seasoning
INITIAL SEASONING Follow installation, and before regular use, the stove must be seasoned to prevent cracking of the metal casting. This procedure should also be followed if the stove has not been used for prolonged periods (during the summer months for example) and is carried out as follows: CAUTION: THIS STOVE MUST BE SEASONED BEFORE USE. -
Page 20: Fire-Lighting With Wood
6. The burn rate can be reduced by partially closing the air control. FIRE-LIGHTING WITH WOOD 1. Open the air control. 2. Lay firelighters or rolled up newspapers on the grate with a reasonable quantity of dry kindling wood. Place 2 or 3 small logs on top. 3. -
Page 21: General Maintenance
Be sure to remove the ash when the fire is at its lowest point, such as first thing in the morning. The Clarke Ash Can Filter is ideal for use in conjunction with the Clarke range of vacuum cleaners, for collecting hot ash and debris from stoves. - Page 22 FIRE ROPE Check the rope around the door and glass. If rope is becoming detached, replace with rope approved for this purpose. Inspect the fireproof door seal where fitted, to ensure there is an effective seal around the door and re-fix it if loose using stove rope adhesive.
- Page 23 Association of Chimney Sweeps or the Guild of Master Sweeps, details of which can be found on the HETAS website, www.hetas.co.uk. ACCESSORIES Refer to the Clarke website www.clarkeinternational.com for a full range of Flue Pipes & Cowls for use with this classic cast iron stove. See also the following accessories;...
-
Page 24: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Fire difficult to Wood green, too damp Use recommended fuel. start. or poor quality. Logs are too large. When lighting, use small, dry Fire goes out. kindling. To maintain the fire use split logs. Air starvation Open air control. -
Page 25: Component Parts Diagram
COMPONENT PARTS DIAGRAM If disposing of this product or any damaged components, do not dispose of with general waste. Metal products should be taken to your local civic amenity site for recycling of metal products. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 26: Component Parts List
COMPONENT PARTS LIST DESCRIPTION DESCRIPTION Base Panel Front Panel Main Door Frame Washer 8x30mm Hinge Pin Hex Leg Securing Bolt 8x25mm Fire Rope Gasket (large) Rear Air Inlet Linkage System Fire Rope Gasket (glass) Stainless Steel Knob Glass Panel Ash Pan Tab Retaining Socket Hd Bolt Ash Pan Handle Glass Securing Tab... -
Page 27: Declaration Of Performance
DECLARATION OF PERFORMANCE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
