Classic cast iron stove 6910125

Advertisement

Quick Links

Classic Cast Iron Stove
RICHMOND
PART NO:6910125
USER GUIDE
06/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RICHMOND and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke RICHMOND

  • Page 1 Classic Cast Iron Stove RICHMOND PART NO:6910125 USER GUIDE 06/08...
  • Page 2: Specifications

    INTRODUCTION Thank you for purchasing this CLARKE classic cast iron stove. Please read this manual thoroughly and follow the instructions carefully. Before attempting to use the stove, thoroughly familiarise yourself with this unit & its operation. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the stove giving you long and satisfactory service.
  • Page 3: General Safety Rules

    CONTENTS IMPORTANT Before commencing please check contents and advise immediately of any shortages. 1 x Free-standing multi-fuel stove 4 x Legs c/w 4 hex headed bolts, 4 x large washers & 4 nuts, 3 countersunk screws 1 x 150mm flue blanking plate 1 x 150mm round flue exit withfireproof gasket c/w 3 x countersunk machine screws 1 x Deflector plate 1 x Grate...
  • Page 4: Unpacking And Assembly

    UNPACKING & ASSEMBLY TOOLS REQUIRED Phillips screwdriver 13mm spanner WARNING: Due to the weight of the stove it is recommended that at least two people perform the un-packing and assembly. Unpack the stove and remove packing materials. Open the doors and remove the 4 legs, grate ashpan, handle and flue outlet.
  • Page 5: Placement & Installation

    PLACEMENT & INSTALLATION WARNING: IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. FOR YOUR SAFETY, CONTACT THE LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION REQUIREMENTS IN YOUR AREA. POSITIONING The stove should only be placed on a wooden floor if it has been covered by a metal plate or other non-inflammable material at least 5mm thick.
  • Page 6 fig 5.
  • Page 7: Using Your Stove

    Any offset between bends should be minimised and the flue should be equipped with suitable access doors for inspection & cleaning. A range of suitable flue pipes, cowls and fire cement are available from your Clarke dealer. USING YOUR STOVE...
  • Page 8: Fire-Lighting With Wood

    Keep the fire burning for three hours or so, gradually increasing the intensity during this period. It should be remembered that this procedure should be carried out at the begining of each season of use in order to remove the moisture retained by the metal during the period of non- use. When used for the first time the fireplace may smell a little, due to gas being given off.
  • Page 9: Parts And Service

    Keep the grate free from a heavy buildup of ashes. The Richmond stove is equipped with a grate riddling device which is used to shake ashes off the grate & into the ashpan. If the stove is burning without life and the lower controls are open, use the riddling lever to clear the grate of ash.
  • Page 10: Troubleshooting

    TROUBLESHOOTING c i f t l u . l e i l a . y t g i l i t h , l l t i l o i t . s l c i f . t h l f t .
  • Page 11: Parts Diagram

    Secondary Air Chamber Blanking Plate Clamp Baseplate Knob for Ridding Device Secondary Air Chamber Sideplate Ridding Device Baffle Plate IMPORTANT: The use of parts other than CLARKE replacement parts may result in safety hazards, decreased appliance performance and may invalidate your warranty.
