INSTALLATION MANUAL

IRONERS

IB4 2310 - IB4 2314 - IB4 2316

05405004GB

2007-16

Need help?

Do you have a question about the IB4 2310 and is the answer not in the manual?

Questions and answers

Summary of Contents for Electrolux IB4 2310

Page 1 INSTALLATION MANUAL IRONERS IB4 2310 - IB4 2314 - IB4 2316 05405004GB 2007-16...
Page 3 05405004 1006 INSTALLATION Table of contents Notice Date Page MANUAL Pages/Chapters Environmental information ..................1/1 Preliminary instructions ..................2/1 Note about the A.C. power ..................3/1 Packaging ......................1/2 Technical characteristics ..................1/3 Noise level ......................3/3 Installation ......................1/4 Work station lighting ....................
Page 4 05405004 1006 INSTALLATION 1. Preliminary instructions Notice Date Page MANUAL Environmental information Concerned by providing the end user with useful and necessary environmental information, we wish to precise: • Data about energetic consumptions, wastes (atmospheric and liquid) and sound level are indicated in the paragraph "Technical characteristics".
Page 5 05405004 1006 INSTALLATION 1. Preliminary instructions Notice Date Page MANUAL This machine should be installed in conformance to the health and safety regulations, and only used in a sufﬁ ciently aerated area. Check the instructions before installing or using the machine. SAFETY The mechanical and electrical installation of the machine should only be done by...
Page 6 05405004 1006 INSTALLATION 1. Preliminary instructions Notice Date Page MANUAL Note about the A.C. power According to the EN 60204-1:1997 standard, the machine is provided for AC supplies corresponding to the extracted caracteristics below : 4.3.2 AC supplies Voltage: Steady state voltage: 0.9…1.1 of nominal voltage. Frequency: 0.99…1.01 of nominal frequency continuously.
Page 7 05405004 1006 INSTALLATION 2. Packaging Notice Date Page MANUAL The ironing machining is secured to a transport pallet and packaged in a cardboard box. Machine type 1.4 m 1.6 m Packaging dimensions (boxed) Lenght (A) 1480 1880 2130 Width (B) Height (C) 1150 1150...
Page 8 05405004 1006 3. Technical INSTALLATION Notice Date Page characteristics MANUAL Neither base nor sealing are indispensable. It is yet possible to ﬁ x the ironer to tje ﬂ oor. To do so, use the holes made to block the machine on the transport pallet. 07100017...
Page 9 05405004 1006 3. Technical INSTALLATION Notice Date Page characteristics MANUAL Machine type 1.4 m 1.6 m Overall length 1395 1795 2045 Length of insertion table 1000 1400 1650 Cylinder diameter Distance between feet 1220 1620 1870 Evacuation diameter nothing 36/40 36/40 Electrical connection see table...
Page 10 05405004 1006 3. Technical INSTALLATION Notice Date Page characteristics MANUAL Noise level Airborne noise emitted by the machine (values established as from measurements made on the machine at points A,B,C,D). D0267 Machine type 1.4 m 1.6 m Point A Point B Weighted acoustic pressure level (A) in dB(A) Point C...
Page 11 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Installation The ironer must be transported to its ﬁ nal position in the laundry before the pallet is removed. Remove the cardboard box and the two side panels (key included). Remove the 2 ﬁ xing screws (1 screw Fig.
Page 12 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Fig. Install the four adjusting blocks and the counternuts in the foreseen places. Place the machine on a perfectly stable and level ﬂ oor. Check the horizontality of the machine using a spirit level at both its centre and ends. If required, use the adjusting blocks to level the machine then lock with the counternuts.
Page 13 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Electrical connection CAUTION Prior to use, the machine should be plugged into a correctly earthed power socket complying with the standards in force. SAFETY The mechanical and electrical installation of the machine should only be done by qualiﬁ...
Page 14 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Mains transformer connection diagrams according to the customer's various mains voltages (machines equiped with a transformer only). 400 Volts supply -15 230 Measure the mains voltage at the Fig. primary with a voltmeter between 0 and 400 Volts of the transformer.
Page 15 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Once connected, make sure to check the correct order of phase connections. CAUTION If the phases are not connected the right order, when switching on the machine, the bed remains in contact against the cylinder, this last rotates clockwise (see from the machine right side), but the safety hand device is inoperative.
Page 16 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Check before use Fig. The ironing machine is delivered with the tray in contact with the cylinder. Check that the machine’s on/off switch is to "0". Turn on the main switch of the machine.
Page 17 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL If the functionning of the machine does not correspond to either case (A) or (B), stop the machine with the On/off switch (Fig.8), put the main switch to off and invert the 2 phase wires on the power supply terminal block (Fig.4).
Page 18 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Disconnecting the machine N B: If you wish to disconnect the electrical supply cable, it si more wise to do it once the machine is cooled down and to stop the ironer with the tray in contact with the cylinder.
Page 19 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Releasing process to follow in case of connection while the tray is in back position. Fig. If you connect the machine with the tray in back position and the control pedal activated (when two wires of phase are inverted), an electrical device doubled with a mechanical system of locking prevents to deteriorate essential...
Page 20 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL Safety Thermostat’s adjustment This ironer has a an adjustable safety thermostat in order to avoid damages of the cotton covering in case of machine stop with the bed closed. This safety thermostat is adjusted in our plant so that the regulation thermostat doesn’t go above the temperature corresponding to the position which is aproximatly 150 °C ;...
Page 21 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL This page is left blank purpose.
Page 22 05405004 1006 INSTALLATION 4. Installation Notice Date Page MANUAL 36000168...
Page 23 05405004 1006 INSTALLATION 5. Appendices Notice Date Page MANUAL Star/Triangle Commutation diagram Heating resistor commutation Motion motor commutation "Star" commutation from 380 to 460 Volt three-phases "Triangle" commutation from 200 to 240 Volt three-phases Commutation from 200 to 240 Volt monophase Phase shifting capacitor...
Page 24 05405004 1006 INSTALLATION 5. Appendices Notice Date Page MANUAL Control diagram printed circuit 36000172C...
Page 25 05405004 1006 INSTALLATION 5. Appendices Notice Date Page MANUAL Component implantation printed circuit PLASTRON = PANEL CONTROL BARRE = BAR CUV. = BED MONNAYEUR = COIN OPERATING SYSTEM MOTEUR = MOTOR CHAUFFAGE = HEATING VENT. = VENTILATOR PEDALE = PEDAL 36000173B...
Page 26 05405004 1006 INSTALLATION 5. Appendices Notice Date Page MANUAL Conversion of measurement units The following is a list of correspondences of the main frequently used units, to avoid the need to use measurement unit conversion tables. bar : 1 bar = 100 000 Pa 1 kg/cm²...
