- Page 1 EN User Manual | Tumble Dryer EDH812R7WC...
- Page 2 Products must be used, installed and operated in accordance with this manual. You may not be able to claim on the Electrolux manufacturer’s warranty in the event that your product fault is due to failure to adhere to this manual.
- Page 3 damage. Always keep the instructions with the appliance for future reference. - Read the supplied instructions. Warning: Risk of fire / Flammable materials. The appliance contains flammable gas, propane (R290), a gas with a high level of environmental compatibility. Keep fire and ignition sources away from the appliance.
- Page 4 1.2 General Safety • Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
- Page 5 • If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. • Do not exceed the maximum load of 8,0 kg (refer to the "Programme chart"...
- Page 6 • Remove all objects from items that could be a source of fire ignition such as lighters or matches. • WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
- Page 7 • Do not pull the mains cable to disconnect the appliance. Always pull the mains plug. Warning: Risk of fire / Flammable • Do not touch the mains cable or the mains materials. The appliance contains flammable plug with wet hands. gas, propane (R290), a gas with a high level of environmental compatibility.
- Page 8 • Remove the door catch to prevent children Waste Electrical and Electronic Equipment or pets from becoming trapped in the (WEEE). drum. • Dispose of the appliance in accordance with local requirements for the disposal of 4. PRODUCT DESCRIPTION Water container Condenser cover Control panel Adjustable feet...
- Page 9 Access your appliance details, documentation and articles on how to use the best features (User Manual also available at electrolux.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at electrolux.com/ support ) • Buy accessories, Consumable and Original Spare parts for your appliance (also available at electro‐...
- Page 10 5. CONTROL PANEL 5.1 Control Panel Program dial Finish In touch buttons Display Time Dry touch button Direct access to dryness level: Extra Anticrease touch button • Extra Dry touch button • Cupboard Dry touch button On/Off button • Iron Dry touch button SyncDry touch button Press the touch buttons with your finger in the area with the symbol or name of...
- Page 11 Symbol on the display Symbol description time drying option on finish in option on Notifications indicator remote start option on check Heat Exchanger indicator: clean filter indicator: drain the water container indicator: extra silent option on child lock on extra anti-crease option on drum light on end alarm off wrong selection or favourite position not saved...
- Page 12 By rotating the program dial it is possible to program data via the home router Wi-Fi to the select the desired program. Electrolux Cloud, as well as to your tumble dryer. 6.4 SmartSelect In order to use the SyncDry function, the...
- Page 13 3. All display symbols will stay lighted off except Wi-Fi icon that run an animation TIME DRYING RECOMMENDATION for a few seconds as the appliance is additional drying to retrieving data from the cloud. improve dryness af‐ 4. Display will update itself automatically 20 - 40 min ter previous drying with the suggested program.
- Page 14 The related led comes on and the related icon appears on display. If the door is open, the Remote Start is To exit this state, tap again the button; the deactivated. related icon turns it off. WI-FI - CONNECTIVITY SETUP 7.2 Over-the-air update This chapter describes how to connect the smart appliance to the Wi-Fi network and to...
- Page 15 The Remote Start enables you to start a cycle ready the symbol: (Access Point) in remote control. appears on the display. Access Point is open for around 5 minutes. 4. Configure our app on your smart device The Remote Control activates and follow the on screen instructions to connect the appliance to your WiFi automatically when you press the...
- Page 16 3. Start the application. Select the country QR code can be used in two ways: and language and login with Your email • Scan the QR code with the built-in camera and password. If you do not have an app to download our app from the App account, create a new one following the store on your smart device and follow the instructions in our app.
- Page 17 Load 1) Properties / Fabric type 2) Program Designed for routine drying of what you wash without sorting. Dries evenly clothes MixCare 6,0 kg made of cotton, cotton-synthetic blends and synthetic. Cottons 8,0 kg Blended garments containing mostly syn‐ Synthetics 4,0 kg thetic fibres like polyester, polyamide, etc.
- Page 18 8.3 Woolmark Premium Wool Care - Green The wool drying cycle of this machine has been tested and approved by The Woolmark Company. The cycle is suitable to dry wool garments which are labelled “hand wash” provi‐ ded that the garments are washed in a Woolmark endorsed hand washing cycle and dried according to the instructions is‐...
- Page 19 9. SETTINGS 9.2 Adjustment of the target final A B C D E moisture This may be necessary since the dryness results are impacted by many conditions, e.g. the water type, the supply voltage or the ambient temperature etc. HOW TO ACHIEVE A PERFECT DRYING: Dry‐...
- Page 20 5. To accept the selected degree of target End Alert final moisture, press and hold buttons (G) The buzzer sounds at the: and (H) at the same time. • cycle end Dryness level • start and end of the anti-crease phase •...
- Page 21 9.7 Factory Defaults 3. The appliance will acknowledge the operation by displaying This function allows to restore the factory default settings. The saved options and working modes will be reset. It will also If the procedure does not work (this could remove WiFi network credentials from the be due to timeout or wrong keys appliance memory and reset personalized...
- Page 22 Working pump and transferring condensation to the tank. Working fans. 11. DAILY USE 11.1 Start a program 1. Prepare the laundry and load the Real drying time will depend on type of appliance. the load (quantity and composition), the room temperature and the initial moisture after spinning phase of your laundry.
- Page 23 11.4 Change a program program should end (e.g. if the program has to finish within 12 hours.) 1. Press the on/off button to deactivate appliance 3. Touch the Start/Pause button. The 2. Press the on/off button to activate the drum starts rotating to perform the appliance.
- Page 24 Always clean the filter and empty the When the appliance goes in low power water container when a program is mode, the display and icons turn off. You completed. can reactivate it by pressing on/off button and the dryer. Leave the door slightly opened after every cycle to avoid moisture.
- Page 25 Fabric label Description Laundry is suitable for tumble drying. Laundry is suitable for tumble drying at higher temperatures. Laundry is suitable for tumble drying at low temperatures only. Laundry is not suitable for tumble drying. 13. CARE AND CLEANING 13.1 Periodic cleaning schedule If the appliance is not used for a long time unplug the appliance.
- Page 26 CAUTION! When cleaning the filters, the lint should be thrown in the garbage bin and not washed through the drain in order to avoid spreading microplastics in the used water system. 1. Open the door. Pull the filter up. 13.4 Emptying the water container Empty the condensed water container after each drying cycle.
- Page 27 13.5 Cleaning the condenser If the symbol of the condenser flashes on the display, inspect the condenser and its compartment. If it is dirty, clean it. Do the check not less than once a 6 months. WARNING! 4. If necessary, remove the fluff from the Do not touch the metal surface with bare condenser and its compartment.
- Page 28 Use a standard neutral soap detergent to Use a moist cloth to clean. Dry the cleaned clean the inner surface of the drum and drum surfaces with a soft cloth. lifters. Dry the cleaned surfaces with a soft CAUTION! cloth. Do not use furniture cleaning agents or CAUTION! cleaning agents which can cause...
- Page 29 14.2 Troubleshooting Problem Possible solution You cannot activate the appliance. Make sure that the mains plug is connected to the mains socket. Check fuse in fuse box (domestic installation). The program does not start. Press Start/Pause. Make sure that the appliance door is closed. The appliance door does not close.
- Page 30 The energy consumption of the connected function is approximately 17,5 kWh per year. To disconnect this func‐ tion, please refer to the chapter "Wi-fi - Connectivity setup". 16. WARRANTY - AUSTRALIA AND NEW ZEALAND FOR SALES IN AUSTRALIA AND NEW APPLIANCE: ELECTROLUX DRYER ZEALAND ENGLISH...
- Page 31 Appliance. offered for a valid warranty claim is repair This warranty is in addition to other rights or replacement. Electrolux or its ASC may you may have under the Australian use refurbished parts to repair your Consumer Law.
- Page 32 In addition, Electrolux is not liable under Australian Consumer Law. You are this warranty if: entitled to a replacement or refund for a a. the Appliance has been, or Electrolux major failure and for compensation for reasonably believes that the...
- Page 33 17. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
- Page 36 136214690-A-262024...
