Summary of Contents for Electrolux EDH80 Series

  • Page 1 Tumble Dryer EN User Manual EDH80******...
  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooter, service information, buy accessories & spare parts, online product registration : www.electrolux.com CUSTOMER CARE AND SERVICE We recommend the use of original spare parts. When contacting Service, ensure that you have the following data available.
  • Page 3: Safety Information

    SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damage. Always keep the instructions with the appliance for future reference. Read the instructions.
  • Page 4 • Keep all packaging away from children and dispose of it appropriately. • Keep detergents away from children. • Keep children and pets away from the appliance when the door is open. • If the appliance has a child safety device, it should be activated.
  • Page 5 • Do not exceed the maximum load (refer to the "Programme chart" chapter in User manual). • Do not use the appliance if items have been soiled with industrial chemicals. • Wipe away lint or packaging debris that has accumulated around the appliance. •...
  • Page 6 • If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products be placed in a tumble dryer they should first be washed in hot water with extra detergent. This will reduce, but not eliminate, the hazard. •...
  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS 2.1 Installation • Make sure that the parameters on the rating plate are compatible with the • Remove all the packaging. electrical ratings of the mains power supply. • Do not install or use a damaged appliance. • Always use a correctly installed shockproof socket.
  • Page 8 2.4 Internal lighting (Available for • For more detailed information about recycling this product, Please contact model EDH***R7**, EDH***R9**) your local city office, your household waste disposal service, or the shop WARNING! where you purchased the product. Risk of injury. 2.7 Care and cleaning •...
  • Page 9: Product Description

    PRODUCT DESCRIPTION Water Container Control Panel Door Lock Filter Heat Exchanger lid Heat Exchanger cover Adjustable Feet Appliance Door ENGLISH...
  • Page 10: Installation

    INSTALLATION Unpacking Installation *Available for model EDH***J5** WARNING! Before proceeding with installation, read the safety information, and dimension preferred. 596 mm *Available for model EDH***P5**, EDH***R7**, EDH***R9** For model EDH***J5**, Use the DRUM UNLOCKED KEY to unlock Rear Drum locks, before using the appliance. For other models, the rear drum locks are removed automatically when the dryer is activated for the first time.
  • Page 11 662 mm 810 mm 1250 mm 10 mm 10 mm 155° 958 mm wall 30 mm WARNING! The tumble dryer cannot be placed on top of a washing machine. For more information, please contact authorized dealer. 15 mm ENGLISH...
  • Page 12: Control Panel

    CONTROL PANEL 5.1 Control Panel Description Programme knob Display Time Dry touch key On/Off button Dryness Level touch key Extra Anticrease touch key End Alert touch key • Iron Dry • (Lock Option) • Cupboard Dry Finish In Adjustment touch key •...
  • Page 13 5.2 Display Indicator : Anticrease phase Notifications icon Time Dry icon Remote Start icon Extra Anticrease icon SmartLeaf icon End alert icon Extra Silent icon Finish In icon Child lock icon Decrease finish in time Indicator : Clean filter Increase finish in time Indicator : Check heat exchanger Programme duration...
  • Page 14: Programmes

    PROGRAMMES 6.1 Programme Chart Programme Load Properties / Fabric type Cottons White and colored cotton fabrics program. The default setting Đồ Cottons is for ready-to-store dryness level. Eco Cottons Cotton fabrics programme designed for maximum energy Tiết kiệm (đồ saving. Cottons) Delicates Recommended for generic delicate fabrics such as viscose,...
  • Page 15 6.2 Programme Options Compatibility Extra Reverse Programme Dryness Level Anticrease Plus Finish In Time Dry Cottons        Đồ Cottons Eco Cottons    Tiết kiệm (đồ Cottons) Delicates    Đồ mỏng Wool ...
  • Page 16: Options And Settings

    OPTIONS AND SETTINGS 7.1 Options Finish In Time Dry Before you start the programme, this option makes it possible to define the You can set the programme duration, end of the drying programme from from a minimum of 10 minutes to a minimum of 1 hour to maximum of 24 maximum of 2 hours.
  • Page 17 7.2 Settings Adjustment of remaining laundry moisture Child lock function This function prevents children playing Every time you enter in the with the appliance while a programme is "Adjustment of remaining laundry operating. The touch buttons are locked. moisture" mode, previously set degree of remaining moisture will change into Only the "...
  • Page 18: Daily Use

    DAILY USE 8.1 Start a programme without Finish 8.2 Starting the programme with Finish In Before you use the appliance to dry 1. Set the correct programme and items: options for the type of load. 1. Prepare the laundry and load the 2.
  • Page 19: Hints And Tips Care

    When the anticrease phase is completed: Always clean the filter and empty 1. Press the " on/off" button to the water container when a programme deactivate the appliance. is completed. 2. Open the appliance door. 3. Remove the laundry. 8.5 Stand-by function 4.
  • Page 20: Care And Cleaning

    CARE AND CLEANING 10.1 Cleaning the filter WARNING! Avoid the use of water to clean the filter. Instead throw away lint in the dustbin (avoid dispersion of plastic fibre in ambient water). To achieve the best drying performances, clean the filter regularly. Clogged filters lead to longer cycles and increase in energy consumption.
  • Page 21 You can use the water from the water container as an alternative to distilled water (e.g. for steam ironing). Before you use the water, remove dirt residues with a filter. 10.3 Cleaning the Heat Exchange CAUTION! Do not touch the metal surface with bare hands.
  • Page 22 10.4 Cleaning the drum 10.6 Cleaning the airflow slots Use a vacuum cleaner to remove fluff WARNING! from the airflow slots. Disconnect the appliance before you clean it. Use a standard neutral soap detergent to clean the inner surface of the drum and drum lifters.
  • Page 23: Troubleshooting

    TROUBLESHOOTING WARNING! Deactivate the appliance before you do the checks. Alarm Malfunction Possible cause Solution Code • • • The programme Appliance motor The programme was not was not overloaded. Too much completed. Remove the laundry complete laundry or entrap in the from the drum, set the programme drum.
  • Page 24 Problem Possible solution The cycle time is too long or unsatisfactory Make sure that the weight of the laundry is drying result. suitable for the duration of the programme. Make sure that the filter is clean. The laundry is too wet. Spin the laundry in the washing machine again.
  • Page 25: Technical Data

    TECHNICAL DATA Model Name EDH803J5WC, EDH803J5SC Height x Width x Depth 850 x 596 x 662 mm Max. depth with the appliance door open 1107 mm Max. width with the appliance door open 958 mm Adjustable height 850 mm (+ 15 mm - feet adjustment) Drum volume 113 l Maximum load...
  • Page 26: Environment Concerns

    ENVIRONMENT CONCERNS 13.1 Packaging Materials The materials marked with the symbol are recyclable. >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene. This means that they can be recycled by disposing them properly in appropriate collection containers. 13.2 Old Machine Use authorized disposal sites for your old appliance. Help to keep your country tidy! The symbol on the product or on its packaging indicates that this product may not be treated as household waste.
  • Page 27 ENGLISH...
  • Page 28 G0043763-002-A28646501...
