- Page 1 (English) DM-HRB001-11 Dealer's Manual Roller brakes BR-C6050-F BR-C6051-F BR-C6060-F BR-C6061-F BR-C6000 BR-C6001 BR-C3000 BR-C3001 BR-C3010 BR-C3011 BR-IM81 BR-IM86 BR-IM31 BR-IM35 BL-C6000 BL-C6010 BL-IM60-A...
- Page 2 CONTENTS IMPORTANT NOTICE ..................4 TO ENSURE SAFETY ..................5 INSTALLATION ................... 10 List of tools to be used ..........................10 Installation of the lever ..........................11 Installing the INTER M brake to the hub body ..................11 Installation of the hub to the frame ......................12 Installation of the brake cable ........................16 ADJUSTMENT ....................
- Page 3 Parts / Series INTER-8 INTER-7 INTER-5 INTER-3 SG-C6010-8R SG-5R30 SG-C3000-7R SG-3R40 SG-C6000-8R SG-5R35 Internal hub gear BL-IM45 BL-C6010 BL-IM65 BL-IM60-A BL-IM60 Brake lever BL-C6000 BR-C3000 BR-C3001 BR-C3010 BR-C3011 BR-IM31 BR-C6000 BR-IM35 BR-C6001 BR-IM81 Roller brakes BR-C6050-F BR-IM86 BR-C6051-F BR-C6060-F BR-C6061-F Brake cable...
- Page 4 • All manuals and technical documents are accessible online at https://si.shimano.com. • For consumers who do not have easy access to the internet, please contact a SHIMANO distributor or any of the SHIMANO offices to obtain a hardcopy of the User's Manual.
- Page 5 Improper use of your bicycle's brake system may result in a loss of control, which could lead to serious injury due to a fall or collision. • It is necessary to use the brake caliper of the SHIMANO front INTER M brake and the hub as a set (excluding the BR-C6050-F, BR-C6051-F, BR-C6060-F and BR-C6061-F).
- Page 6 • When securing the brake arm to the frame, be sure to use an arm clip that matches the size of the chainstay, and securely tighten them with the clip bolt and clip nut to the specified tightening torque. Use a lock nut with nylon insert (self-locking nut) as the clip nut. It is recommended that SHIMANO made clip bolts, clip nuts, and arm clips be used.
- Page 7 If it is used on a bicycle which is smaller than 26 inches, the braking force may be too great, which could cause accidents. • In order to get the best performance from the SHIMANO front INTER M brake, be sure to use SHIMANO brake cables and brake levers as a set.
- Page 8 • Products are not guaranteed against natural wear and deterioration from normal use and aging. • For maximum performance we highly recommend SHIMANO lubricants and maintenance products. The actual product may differ from the illustration because this manual is intended mainly to explain the procedures for...
- Page 9 INSTALLATION...
- Page 10 INSTALLATION List of tools to be used INSTALLATION „ List of tools to be used The following tools are needed for installation, adjustment, and maintenance purposes. Tool Tool Tool 17 mm spanner Adjustable wrench Cross head screwdriver [#1] 10 mm spanner 5 mm hexagon wrench Cross head screwdriver Mode switching...
- Page 11 INSTALLATION Installation of the lever „ Installation of the lever Ø22.2 mm Clamp screw Grip 5 mm hexagon wrench Tightening torque 6 - 8 N·m „ Installing the INTER M brake to the hub body Engage the splines on the hub body (B) INTER M brake with the splines on the INTER M brake Hub body...
- Page 12 INSTALLATION Installation of the hub to the frame „ Installation of the hub to the frame Rear side The hub installation is an example. Also refer to the manual for the hub. Mount the chain on the sprocket, then Hub axle set the hub axle (A) into the rear Rear dropout dropout (B).
- Page 13 INSTALLATION Installation of the hub to the frame Attach the brake arm of the INTER M Brake unit fixing nut/Brake unit brake to the chainstay with the brake fixing washer arm clip (C). Clip nut Brake arm clip Then temporarily fix the clip bolt (D) Clip bolt (M6×16 mm) and clip nut (B) by lightly tightening them.
- Page 14 INSTALLATION Installation of the hub to the frame Fix the brake arm (A) securely to the Brake arm chainstay (B) with the brake arm clip Chainstay (C). Brake arm clip Check that the brake arm is securely fastened to the chainstay by the brake Tightening torque arm clip.
- Page 15 INSTALLATION Installation of the hub to the frame Front side <For quick release type> Check that the front brake unit (A) is Brake unit firmly secured to the hub with the Brake unit fixing nut brake unit fixing nut (B). With notches (The side with Tightening torque notches is the front.)
- Page 16 INSTALLATION Installation of the brake cable „ Installation of the brake cable Rear side After checking that the cable Adjustment nut adjustment barrel (B) and adjustment Cable adjustment barrel nut (A) are fully tightened, insert the Outer holder unit outer holder unit (C) into the inner cable in the direction shown in the illustration.
- Page 17 INSTALLATION Installation of the brake cable Align the red mark on the inner cable Groove in the winder unit fixing washer (B) so that it faces in the Red mark on inner cable fixing direction of the groove in the winder washer unit (A), and then insert the inner Inner cable fixing bolt unit...
- Page 18 INSTALLATION Installation of the brake cable After pressing the lever, check that the red marks on the inner cable fixing washer with the inner cable fixing bolt unit press-fit into the winder unit are When detaching the cable, perform in reverse order.
- Page 19 INSTALLATION Installation of the brake cable Place the components as shown in the Inner cable fixing nut following figure and tighten the inner TL-IM21 cable fixing nut (A). Use (x) 109 mm of TL-IM21 (B) to Tightening torque tighten the inner cable fixing nut as shown in the illustration.
- Page 20 INSTALLATION Installation of the brake cable Hook the inner cable (B) over the cable Cable hook hook (A). Inner cable Insert the outer holder unit (B) into Brake arm the hole of the brake arm (A) from Outer holder unit underneath and slide it to the lower section of the hole.
- Page 21 INSTALLATION Installation of the brake cable <For BR-IM31 / 35> Place the cable adjustment barrel (A) Cable adjustment barrel so that it is (z) 13 to 15 mm from the Outer casing holder end of the outer casing holder (B), and Hole in the inner cable fixing bolt then pass the inner cable through the cable adjustment barrel and then...
- Page 22 ADJUSTMENT...
- Page 23 ADJUSTMENT Adjusting the brake cable ADJUSTMENT „ Adjusting the brake cable Rear side NOTICE After checking that the wheel does not easily turn while the brake cable is If the brake cable is not run in, it will need being pulled, depress the brake lever to be adjusted again after only a short about 10 times as far as the grip in period of use.
- Page 24 ADJUSTMENT Adjusting the brake cable Front side NOTICE After checking that the wheel does not easily turn while the brake cable is If the brake cable is not run in, it will need being pulled, depress the brake lever to be adjusted again after only a short about 10 times as far as the grip in period of use.
- Page 25 MAINTENANCE...
- Page 26 After application, check that braking is properly applied and that no abnormal noise is heard. For the BR-C6050-F / C6051-F / C6060-F / C6061-F / C6000 / C6001 / C3000 / C3001 / C3010 / C3011 For BR-IM31 / 35...
- Page 27 Please note: specifications are subject to change for improvement without notice. (English) © May 2024 by SHIMANO INC. ITP...
