Page 3 Main motors 1PH813_1PH816 Introduction Fundamental safety instructions SIMOTICS Description Preparations for use Drive technology Main motors 1PH813_1PH816 Mechanical mounting Connection Operating Instructions Commissioning Operation Maintenance Spare parts Decommissioning and disposal Appendix 09/2021 A5E50030782B AD...
Page 4 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
Page 5 These operating instructions are valid in conjunction with the relevant Siemens configuration manual. Siemens strives to continually improve the quality of information provided in these operating instructions. • If you find any mistakes or would like to offer suggestions about how this document could be improved, contact the Siemens Service Center.
Page 6 Later, you can log on with your login data. You can create your own personal library under "mySupport" using the following procedure. Precondition You have registered for and logged on to "Siemens Industry Online Support", hereinafter referred to as "SIOS". SIOS (https://support.industry.siemens.com/cs/ww/en/)
Page 7 In this way, you can create your own library and quickly access your documentation. Training The following link provides information on SITRAIN - training from Siemens for products, systems and automation engineering solutions: SITRAIN (http://siemens.com/sitrain)
Page 8 Introduction Websites of third parties This publication contains hyperlinks to websites of third parties. Siemens does not take any responsibility for the contents of these websites or adopt any of these websites or their contents as their own, because Siemens does not control the information on these websites and is also not responsible for the contents and information provided there.
Page 9 Table of contents Introduction ............................3 Fundamental safety instructions ......................11 General safety instructions ....................11 Equipment damage due to electric fields or electrostatic discharge ........15 Security information ......................16 Residual risks of power drive systems ................. 17 Description ............................19 Use for the intended purpose .....................
Page 10 Table of contents Connection ............................63 Mechanical connection of water cooling system ..............63 Electrical connection ......................63 5.2.1 Cable routing ........................65 5.2.2 Circuit diagram ........................66 5.2.3 Terminal box ........................67 5.2.4 Power connector (for 1PH813 only) ................... 70 5.2.5 Electrical connection data ....................
Page 11 Table of contents 10.1 Decommissioning ......................115 10.2 Disposal ........................... 116 Appendix............................117 Note regarding a holding brake ..................117 Operating Instructions for the holding brake ..............118 Operating Instructions for the external fan, SH132 ............148 A.3.1 Operating instructions for the external fan, Type K2D200AB1806 ........148 A.3.2 Operating instructions for the external fan, Type K2D200AB1808 ........
Page 12 Table of contents Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 13 Fundamental safety instructions General safety instructions WARNING Electric shock and danger to life due to other energy sources Touching live components can result in death or severe injury. • Only work on electrical devices when you are qualified for this job. •...
Page 14 Fundamental safety instructions 1.1 General safety instructions WARNING Electric shock due to damaged motors or devices Improper handling of motors or devices can damage them. Hazardous voltages can be present at the enclosure or at exposed components on damaged motors or devices. •...
Page 15 • Therefore, if you move closer than 20 cm to the components, be sure to switch off radio devices or mobile telephones. • Use the "SIEMENS Industry Online Support app" only on equipment that has already been switched off. WARNING Unrecognized dangers due to missing or illegible warning labels Dangers might not be recognized if warning labels are missing or illegible.
Page 16 Fundamental safety instructions 1.1 General safety instructions Note Important safety notices for Safety Integrated functions If you want to use Safety Integrated functions, you must observe the safety notices in the Safety Integrated manuals. WARNING Active implant malfunctions due to electromagnetic fields Electromagnetic fields (EMF) are generated by the operation of electrical power equipment, such as transformers, converters, or motors.
Page 17 Fundamental safety instructions 1.2 Equipment damage due to electric fields or electrostatic discharge WARNING Fire due to incorrect operation of the motor When incorrectly operated and in the case of a fault, the motor can overheat resulting in fire and smoke. This can result in severe injury or death. Further, excessively high temperatures destroy motor components and result in increased failures as well as shorter service lives of motors.
Page 18 Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to...
Page 19 Fundamental safety instructions 1.4 Residual risks of power drive systems Residual risks of power drive systems When assessing the machine- or system-related risk in accordance with the respective local regulations (e.g., EC Machinery Directive), the machine manufacturer or system installer must take into account the following residual risks emanating from the control and drive components of a drive system: 1.
Page 20 Fundamental safety instructions 1.4 Residual risks of power drive systems Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 21 When necessary, take into account deviations regarding approvals or country-specific regulations. • If you have any questions regarding the intended use, please contact your local Siemens office. • If you wish to use special versions and design variants whose specifications vary from the motors described in this document, then first contact your local Siemens office.
Page 22 Description 2.2 Technical characteristics and ambient conditions Technical characteristics and ambient conditions 2.2.1 Directives and standards Standards that are complied with The motors of the type series SIMOTICS S, SIMOTICS M, SIMOTICS L, SIMOTICS T, SIMOTICS A, called "SIMOTICS motor series" below, fulfill the requirements of the following directives and standards: •...
Page 23 UL or cUL mark on the rating plate! Quality systems Siemens AG employs a quality management system that meets the requirements of ISO 9001 and ISO 14001. Certificates for SIMOTICS motors can be downloaded from the Internet at the following link: Certificates for SIMOTICS motors (https://support.industry.siemens.com/cs/ww/en/ps/13347/cert)
Page 24 The most important technical characteristics of the motors can be found on the rating plate (type plate): You will find detailed overviews of the technical characteristics of the motors in the Configuration Manual "SIMOTICS M-1PH8 Main Motors for SINAMICS S120" or in catalogs D 21.4 and NC 61.
Page 25 Description 2.2 Technical characteristics and ambient conditions 2.2.3 Ambient conditions The following temperature ranges apply to motors with forced ventilation. Permissible temperature range during operation: T = -15 °C to +40 °C Under conditions other than those specified above (ambient temperature > 40°C or installation altitude >...
Page 26 Description 2.2 Technical characteristics and ambient conditions 2.2.5 Noise emission WARNING Hearing damage Hearing damage may occur if the motor exceeds a sound pressure level of 70 dB (A) due to the type of mounting or pulse frequency. • Reduce the sound pressure level by implementing sound damping and/or soundproofing measures.
Page 27 Description 2.3 Rating plate data (type plate) Rating plate data (type plate) The nameplate (rating plate) shows the technical specifications for the supplied motor. Figure 2-2 Nameplate layout for 1PH808 to 1PH816 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 28 Description 2.3 Rating plate data (type plate) Table 2- 4 Elements on the rating plate Description Description L010 Article No. (MLFB) L190 Rated voltage U L025 UL mark L191 Connection method (3) L029 Type of construction L200 Rated current I L030 Type of construction L210...
Page 29 Description 2.4 Design Design 2.4.1 Types of construction The motor can have the following types of construction: Table 2- 5 Types of construction Motor Types of construction 1PH813 IM B3 (IM V5, IM V6, IM B6, IM B7, IM B8) IM B5 (IM V1, IM V3) IM B35 (IM V15, IM V35) 1PH816...
Page 30 Description 2.4 Design 2.4.2 Cooling Forced ventilation This cooling method is realized using a separate ventilation module equipped with a fan (external fan) that operates independently of the motor. NOTICE Risk of overheating if external cooling is inadequate If the external fan fails or the motor is operated for a short time without forced ventilation, this can cause it to overheat.
Page 31 Description 2.4 Design Water cooling The motor can only be operated in a closed cooling-water circuit with a heat-exchanger unit. The motor is connected to the cooling circuit by means of two female threads on the rear of the motor. The operator can decide on the best method of connecting the inlet and outlet. Table 2- 6 Technical data relating to water cooling Cooling water connection...
Page 32 Description 2.4 Design The values specified for the cooling water (refer to the following table) correspond to the requirements of closed cooling circuits. Not all of the specified concentrations will occur in the cooling water at the same time. Table 2- 7 Cooling water specifications Component Quality of the water used as coolant for motors with stain-...
Page 33 Description 2.4 Design 2.4.3 Holding brake (option) 2.4.3.1 Properties Operation with holding brake on the SINAMICS S The SINAMICS S drive system has various types of brake control. A detailed description of the individual functions and corresponding parameter assignment information can be found in the following manuals: •...
Page 34 Br Note Selection and ordering data The selection and ordering data can be found in the Configuration Manual "SIMOTICS M-1PH8 main motors", Chapter "Selection and ordering data". Note Disclaimer of liability The customer is responsible for choosing of contactors.
Page 35 Description 2.4 Design Figure 2-6 Terminology (time) for holding operation Explanation of terminology in the table Holding torque in Nm: on motors with shaft heights 100 ... 160, the holding torque can be continuously set in the specified value range using an adjusting ring. The dynamic braking torque is approximately 70% of the set holding torque.
Page 36 Description 2.4 Design Use for the intended purpose "Spring-applied single-disk brake modules" are for mounting on induction or synchronous motors and intended for use in commercial or industrial systems. It is prohibited to use the brake in hazardous areas and zones or areas with firedamp. The externally mounted spring- applied single-disk brake (electromagnetically released system) is designed as a holding brake.
Page 37 Radial and axial forces The specifications for the "standard" bearing version apply for the permissible radial and axial forces. (Refer to the Configuration Manual "SIMOTICS M-1PH8 main motors") See also Note regarding a holding brake (Page 117) Operating Instructions for the holding brake (Page 118)
Page 38 Description 2.4 Design Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 39 The drive systems are assembled on an individual basis. Upon receipt of the delivery, check immediately whether the items delivered are in accordance with the accompanying documents. Siemens will not accept any claims relating to items missing from the delivery and which are submitted at a later date.
Page 40 Preparations for use 3.2 Transportation and storage WARNING Danger to life as a result of incorrect transport and/or lifting of the motor Incorrectly transporting and/or lifting the motor can lead to severe injuries and/or material damage. For instance, the motor can fall. •...
Page 41 Preparations for use 3.2 Transportation and storage ① Horizontal shaft extension (standard) ② Shaft extension pointing upwards ③ Shaft extension pointing downwards Figure 3-2 Location of the lifting eyebolts on 1PH813 and 1PH816 Transporting a motor that has already been in operation Procedure If you want to transport a motor that has already been in operation, proceed as follows: 1.
Page 42 Preparations for use 3.2 Transportation and storage 3.2.2 Storage Note Replacing roller bearings • Even if the motor was stored for more than three years under favorable conditions (i.e. in a dry, dust-free room that is not susceptible to vibration), you must replace the bearings. •...
Page 43 Preparations for use 3.2 Transportation and storage Long-term storage If you intend to place the motor in storage for longer than six months, you must check its condition every six months. • Check the motor for any damage. • Carry out any necessary maintenance work. •...
Page 44 Preparations for use 3.2 Transportation and storage Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 45 Mechanical mounting Installation NOTICE Thermal damage to temperature-sensitive parts Some parts of the motor enclosure can reach temperatures that exceed 100°C. If temperature-sensitive parts, e.g. electric cables or electronic components are in contact with hot surfaces, they can be damaged. •...
Page 46 Mechanical mounting 4.2 Mounting • Make sure that you either tighten or remove eyebolts that have been screwed in after installation. • Make sure that you install air-cooled motors in such a way that the cooling air can flow in and out without any obstruction and that the minimum distance s is maintained between the air inlet and discharge openings and adjacent components (see "Minimum distance"...
Page 47 Mechanical mounting 4.3 Attaching the output elements Mounting using the motor flange (flange mounting) Note Flange mounting When the motor is flange-mounted, this creates a system that is capable of oscillation with specific natural mounting frequencies. In operation, this can result in excessive vibration. To counter this, additional support can be provided at the NDE.
Page 48 Mechanical mounting 4.3 Attaching the output elements Attaching the output elements • Make sure that the balancing method of the output element is correct! The output elements must be balanced to balance quality grade G2.5 to ISO 1940. Rotary forces that exceed this are not permissible.
Page 49 Mechanical mounting 4.4 Vibration stressing Vibration stressing The on-site mechanical system vibration characteristics depend on factors such as the output elements, mounting situation, alignment, installation, and external vibration and can increase the level of motor vibration. Under certain circumstances, the rotor may have to be balanced completely with the output element.
Page 50 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting of rotating unions on 1PH8 hollow-shaft motors General information 1PH8 main motors with a hollow shaft (13th position in the Article No.: " 3 ") are designed as main spindle motors for machine tools and machining centers with internal tool cooling.
Page 51 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors With opening seals, the sealing surfaces are separated when there is no coolant pressure, e.g. during a tool change. In this case, coolant runs out of the supply line and out of the motor shaft through the opened seal.
Page 52 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Figure 4-4 Mounting the rotating union Figure "Mounting the rotating union," illustrates how an axial force arises due to joint pressure, for example, in the gap between the motor shaft (hole bolt) and the spindle shaft. This acts upon the motor shaft against the bearing preloading force F .
Page 53 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors This advantage does not apply to rotor-supported rotating unions. It is important to ensure that the preloading force of the motor bearing is not eliminated (see figure "Mounting the rotating union"...
Page 54 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting rotor-supported rotating union on water-cooled motors ① Sealing cover ② Balancing disk ③ Rotor-supported rotating union, e.g. DEUBLIN 1109-020-188 ④ Leakage hose ⑤ Inlet hose Mounting on air-cooled motors Air-cooled motors have a “0”...
Page 55 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting rotor-supported rotating unions on air-cooled motors ① Sealing cover ② Balancing disk ③ Intermediate housing ④ Rotor-supported rotating union, e.g. DEUBLIN 1109-020-188 ⑤ Cutout ⑥ Cover (openings for connections must be closed again) ⑦...
Page 56 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting steps Procedure Note Mounting steps for air-cooled motors The mounting steps 1, 11, 12, 13, and 14 are only required for air-cooled motors. 1. Remove the fan and intermediate housing from the motor. 2.
Page 57 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors 4.5.2 Bearingless, frame-supported rotating union The bearingless frame-supported rotating union cannot be mounted directly on the motor. An adapter is required for the static part of the rotating union. The adapter is not included in the scope of delivery and must be made by the customer to match the rotating union to be used.
Page 58 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting on water-cooled motors Water-cooled motors have a “2” in the 11th position of Article No. together with option Y64. Rotating unions with radial or axial connections can be used. Mounting a bearingless rotating union on a water-cooled motor Encoder cover Balancing disk...
Page 59 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting on air-cooled motors Air-cooled motors have a “0” or a “1” in the 11th position of Article No. together with option Y64. Air-cooled motors are equipped with an intermediate housing between the motor and the axially mounted fan.
Page 60 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting of bearingless rotating union on an air-cooled motor Encoder cover Leakage hose as backup and for faults Balancing disk Inlet hose Adapter Sealing air connection 6 x M5 bolts Intermediate housing Rotating part of the rotating union, e.g.
Page 61 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Mounting steps Procedure Note Mounting steps for air-cooled motors The mounting steps 1, 13, 14, 15, and 16 are only required for air-cooled motors. 1. Disassemble the fan and intermediate housing from the motor. 2.
Page 62 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors 4.5.3 Mounting information and instructions • Do not mount any additional anti-rotation pins on rotor-supported rotating unions • Never screw pipes directly to the rotating union. • Always use a hose between the rotating union and the fixed piping. To do this, route the hoses in curves and torsion-free.
Page 63 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Intermediate housing for air-cooled motors ① Cutout for hoses (to be made by the customer) ② Motor side ③ Fan side Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 64 Mechanical mounting 4.5 Mounting of rotating unions on 1PH8 hollow-shaft motors Slot dimensions for the intermediate housing SH132 SH160 4.5.4 Suggestion for an adapter for bearing-free, frame-supported rotating unions Note Comply with the manufacturer's specifications Comply with the specifications and instructions provided by the manufacturer when installing the rotating union.
Page 65 Connection Mechanical connection of water cooling system The inlet and outlet holes for the cooling water supply are located on the NDE in the bearing shield. Procedure 1. Make sure that the cooling water fulfills the required cooling water specification, see the chapter titled "Cooling".
Page 66 The signal and power cables to the motor must be shielded. Apply the EMC installation guideline of the converter manufacturer. For Siemens converters, this is available under document order number 6FC5297-☐AD30-0☐P☐. Main motors 1PH813_1PH816...
Page 67 Connection 5.2 Electrical connection 5.2.1 Cable routing • When selecting the required connecting cables, make sure that you take into account the rated current and plant-specific conditions, such as ambient temperature, routing type, etc. according to IEC / EN 60364-5-52 and IEC / EN 60204-1. •...
Page 68 Connection 5.2 Electrical connection 5.2.2 Circuit diagram The circuit diagram contains information about wiring and connecting the motor winding. The circuit diagram can be found on the lid of the terminal box. Figure 5-1 Circuit diagram NOTICE Cable damage caused by inappropriately changing the cable outlet direction You will damage connecting cables if you inappropriately change the cable outlet direction.
Page 69 Connection 5.2 Electrical connection 5.2.3 Terminal box • Assign the terminals in the terminal box as shown in the diagrams "Terminal box: 3-pole" and "Terminal box: 6-pole". • Connect the PE conductor. • Use cable lugs to DIN 46234. • Do not remove the insulation strips. •...
Page 70 Connection 5.2 Electrical connection ① Terminal stud M6 ② Jumper ③ Grounding screw M6 ④ Insulation strips Figure 5-4 Terminal box gk846 (1PH813) and gk876 (1PH816), 6-pole (can be switched between star and delta) ① Terminal screw M10 ② Grounding screw M6 ③...
Page 71 Connection 5.2 Electrical connection ① Terminal screw M6 ② Grounding screw M6 ③ Insulation strips Figure 5-6 Terminal box gk843 (1PH813), gk873 (1PH816), 3-pole, cable entry DE Note Cable exit direction DE The motor with the cable exit direction DE has a "D" in the 15th position of the Article No. Star/delta connection A star/delta connection is implemented by means of an external contactor circuit or as a fixed configuration in terminal box gk846 (1PH813) and gk876 (1PH816).
Page 72 Connection 5.2 Electrical connection 5.2.4 Power connector (for 1PH813 only) • Use connector M63. • Assign the connector as shown in the "Power connector" diagram. Connect the protective conductor. Brake connection 24 V: "+" = BD1+; "-" = BD2 Figure 5-8 Power connector (view of connector pins) 5.2.5 Electrical connection data...
Page 73 Connection 5.2 Electrical connection Table 5- 3 1PH8 motors, shaft height 160 Terminal Cable entry Cable entry (ex- Max. external Number of main Max. cross- Max. cur- box type (power) ternal signals) cable diameter terminals section per rent per terminal terminal gk863 1 x M50 x 1.5...
Page 74 Connection 5.2 Electrical connection Figure 5-9 Motor with DRIVE-CLiQ interface (example) The signal connection between the motor and Motor Module is established by means of a MOTION-CONNECT DRIVE-CLiQ cable. The MOTION-CONNECT DRIVE-CLiQ cable connector must be inserted far enough so that the catch springs engage. Figure 5-10 Encoder interface with DRIVE-CLiQ Main motors 1PH813_1PH816...
Page 75 Connection 5.2 Electrical connection 5.2.7 Motors without DRIVE-CLiQ interface If a motor is not equipped with a DRIVE-CLiQ interface, the speed encoder and temperature sensor are connected via a signal connector. Motors that are not equipped with DRIVE-CLiQ require a Sensor Module Cabinet-Mounted (SMC) or a Sensor Module External (SME) when operated with SINAMICS S120.
Page 76 Connection 5.2 Electrical connection Design of signal connectors Pin assignment, 12-pin Pin assignment, 17-pin signal connector signal connector Incremental encoder Incremental encoder Incremental encoder Absolute encoder HTL 2048 S/R IC 2048 S/R IN 256 S/R AM 2048 S/R HTL 1024 S/R IN 512 S/R 1 = B* 1 = Α...
Page 77 Connection 5.2 Electrical connection 5.2.8 Connecting an HTL incremental encoder Encoder connection with terminal block using an additional terminal box Induction motors can be equipped with an additional terminal box. This means that you can connect the following HTL incremental encoders for operation with a SINAMICS G via a terminal block: •...
Page 78 Connection 5.2 Electrical connection 5.2.9 Connecting the temperature sensor The temperature sensor in the motor winding is connected to the signal connector together with the speed encoder signal. NOTICE Thermal motor damage Windings and bearings can be destroyed if the motor overheats. •...
Page 79 Connection 5.2 Electrical connection 5.2.11 Connecting the external fan The fan connection is located in the fan terminal box. Table 5- 4 Connection specifications for external fans on 1PH813 Air flow direction Max. current consumption at 400 V / 50 Hz (±10 %) 400 V / 60 Hz (±10 %) 480 V / 60 Hz (±10 %) in A...
Page 80 Connection 5.2 Electrical connection Black Blue Brown Green/yellow Figure 5-14 Connection of external fan in the terminal box NOTICE Damage to the fan when inappropriately operated The fan can be destroyed if inappropriately operated. • Use blocking protection (stall protection) to protect the fan against inappropriate operation.
Page 81 Connection 5.2 Electrical connection Connection of the external fan by means of connector for 1PH813 Note If you order the motor with a power connector, the external fan is connected with an M23 power connector. ① SPEED CONNECT connector, M23 ②...
Page 82 Connection 5.2 Electrical connection 5.2.12 Connecting-up a converter Selecting and connecting the cables • To connect the motor to a converter, use MOTION-CONNECT cables or shielded connecting cables. Note The cable shielding, made up of as many strands as possible, must have a high electrical conductivity.
Page 83 Connection 5.2 Electrical connection 5.2.14 Sealing air connection (option Q12) Cooling lubricants containing oil with creepage, which can also be aggressive, are mainly used for machine tools and transfer machines. For critical applications involving media with extremely high creepage rates, generally degree of protection against water (according to EN 60034-5/IEC 60034-5) is not sufficient.
Page 84 Connection 5.2 Electrical connection Conditioning B: 1PH8 motors with shaft sealing ring (option K18) Min. air intake temperature in °C Ambient temperature Max. air intake temperature in °C Max. residual water content in g/m 0.12 Max. residual oil content in g/m 0.01 Max.
Page 85 Commissioning Safety instructions for commissioning WARNING Danger to life as a result of hazardous voltages when connected to inadequately grounded line supplies In the case of a fault, connecting a motor to an inadequately grounded line supply can result in death, severe injury and/or motor damage. •...
Page 86 Commissioning 6.1 Safety instructions for commissioning WARNING Danger to life when the cooling system bursts The motor will overheat if it is operated without cooling. When cooling water enters the hot motor, this immediately and suddenly generates hot steam that escapes under high pressure.
Page 87 Commissioning 6.1 Safety instructions for commissioning NOTICE Motor damage when the maximum speed is exceeded The maximum speed n is the highest permissible operating speed. The maximum speed is stamped on the rating plate (nameplate). The motor can be damaged if operated at inadmissible speeds. •...
Page 88 Are the manufacturer's documentation for the system components (e.g. drive system, encoder, cooling system, brake) and the "SIMOTICS M-1PH8 main motors" Configura- tion Manual available? If the 1PH8 motor is to be fed from a SINAMICS S120 drive system: Is the following, current SINAMICS documentation available? •...
Page 89 Commissioning 6.2 Checklists for commissioning Table 6- 2 Checklist (2) - checks regarding the mechanical system Check Have all touch protection measures for moving and live parts been taken? Has the motor been correctly mounted and aligned? Can you rotate the rotor without it touching the stator? Do the operating conditions correspond to the data specified on the rating plate? Are all mounting screws, connecting elements, and electrical connections tight and attached properly?
Page 90 Commissioning 6.2 Checklists for commissioning Table 6- 5 Checklist (5) - checks regarding the cooling system Check Water cooling Has the cooling water supply been connected and is it ready for operation? Is the cooling water circulation (flow rate, temperature) in compliance with the specifi- cations? Forced ventilation Have you checked all safety-related and function-relevant details?
Page 91 Commissioning 6.3 Checking the insulation resistance Checking the insulation resistance After long storage or shutdown periods, the insulation resistance of the windings must be measured to ground with direct voltage. WARNING Danger to life through electric shock During and immediately after the measurement, the terminals are in some cases at hazardous voltages, which can lead to death when touched.
Page 92 Commissioning 6.4 Switching-on and switching-off Note the following: • Dry, new windings have an insulation resistance of between 100 and 2000 MΩ (sometimes higher). If the insulation resistance is close to the minimum value, this could be due to humidity and/or an accumulation of dirt.
Page 93 Commissioning 6.4 Switching-on and switching-off Switching on Precondition • Ensure that the converter is correctly parameterized. • Use the appropriate commissioning tools, for example, "Drive ES" or "STARTER". • Switch on the cooling system. Procedure 1. Switch on the motor at the converter. 2.
Page 94 Commissioning 6.5 Cooling Cooling Water cooling The motor must always be connected to the cooling water supply when in operation. WARNING Danger to life when the cooling system bursts The motor will overheat if it is operated without cooling. When cooling water enters the hot motor, this immediately and suddenly generates hot steam that escapes under high pressure.
Page 95 Operation Note EMERGENCY OFF To avoid accidents, inform yourself about the EMERGENCY OFF function before you switch on the system. Switching on WARNING Danger to life caused by the machine moving and loose objects Machine movement and loose objects, which can fall or are flung out, can cause severe injury.
Page 96 Operation 7.1 Faults Switching off The motor is switched off at the converter. • Read about this topic in the converter operating instructions. Faults WARNING Injuries caused by the drive system as a result of ineffective protective devices Injuries can be caused if protective devices are deactivated while troubleshooting. •...
Page 97 Locate leaks and seal as necessary, or consult the manufacturer defective If the fault still cannot be resolved after applying the measures specified above, please contact the manufacturer or the Siemens Service Center. Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 98 Operation 7.2 Non-operational periods Non-operational periods Measures for longer non-operational periods NOTICE Damage due to improper storage The motor can be damaged if it is not stored properly. • If the motor is not operational for longer periods of time, preserve it by using anti- corrosion protection and ensure that it remains dry (e.g.
Page 99 Maintenance CAUTION Risk of burns when hot cooling water escapes There is a risk of burns caused by escaping hot cooling water and steam if you open the cooling circuit of a motor that was previously in operation. • Do not open the motor cooling circuit until the motor has cooled down. CAUTION Risk of injury through contact with cleaning agents and solvents Contact with cleaning agents and solvents can cause chemical burns and irritate the skin...
Page 100 If you have any questions, please contact the manufacturer, informing them of the machine type and serial number. We recommend that a Siemens Service Center carries out inspection and maintenance work. The contact data is provided in the introduction under "Technical support".
Page 101 Abnormalities identified during inspection that are subsequently ignored can result in machine damage. • Analyze and remove any abnormalities identified, taking into consideration Chapters, "Faults" and "Maintenance". • Contact the Siemens Service Center if you require any support. Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 102 Abnormalities identified during inspection that are subsequently ignored can result in machine damage. • Analyze and remove any abnormalities identified, taking into consideration Chapters, "Faults" and "Maintenance". • Contact the Siemens Service Center if you require any support. Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 103 Maintenance 8.1 Inspection and maintenance 8.1.5 Bearing replacement intervals The bearings are subject to wear and must be replaced after a defined number of operating hours. The recommended bearing replacement intervals t are listed in the following table. Bearing replacement intervals can be extended if the motor is operated under favorable conditions, e.g.
Page 104 8000 8000 Note 1PH8 motors require special bearings, which can be obtained via the Siemens Service Center. 8.1.6 Cleaning the motor and fan (external fan) • Check the degree of pollution of the motor and the external cooling unit at regular intervals.
Page 105 Maintenance 8.1 Inspection and maintenance Cleaning WARNING Danger to life due to risk of explosion caused by solvents When using solvents, vapors are released, which can explode if they come into contact with a source of ignition. The explosion can cause death or severe injury. •...
Page 106 • If you are such a person (with heart pacemaker or implant) then keep a minimum distance of 2 m from an opened motor. • Only the Siemens Service Center should remove the rotor. Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 107 • Carefully observe the information in Chapter "Handling electrostatic sensitive devices (ESD)". The Siemens Service Center Bad Neustadt, Germany should be contacted when carrying out motor repair work. You can replace a defective encoder on site where the motor is installed.
Page 108 Maintenance 8.2 Corrective maintenance Mounting • Do not reuse rolling-contact bearings that have been removed. • Heat up the new rolling-contact bearings evenly to 80 - 100°C and attach them. When doing so, make sure that the bearing inner ring lies on the shaft shoulder. •...
Page 109 Maintenance 8.2 Corrective maintenance 8.2.2 Removing/installing the speed encoder WARNING Uncontrolled motor motion as a result of incorrect adjustment Incorrect adjustment of the encoder regarding motor EMF can lead to uncontrolled motion which can cause personal injury and/or material damage. •...
Page 110 Maintenance 8.2 Corrective maintenance Removing the encoder Procedure 1. Unscrew the screw (1). 2. Remove the connector cover (2). 3. Remove the connector with signal cable. 4. Unscrew the screws (9.07) for the torque bracket. 5. Unscrew the encoder screw (9.05) (make sure that the motor rotor does not also start to rotate).
Page 111 Maintenance 8.2 Corrective maintenance 8.2.3 Removing/installing the toothed-wheel encoder Note Toothed-wheel encoder The toothed-wheel encoder has the following description without the DRIVE-CLiQ interface: “Incremental encoder sin/cos 1 Vpp 256 S/R without C and D tracks (encoder IN256 S/R).” The marking is: 1PH8☐☐☐-☐C☐☐☐-☐☐☐☐ The toothed-wheel encoder has the following description with the DRIVE-CLiQ interface: “Incremental encoder 19-bit without commutation position (encoder IN19DQ).”...
Page 112 Maintenance 8.2 Corrective maintenance Removing the encoder Procedure 1. Unscrew the screws (1) and remove the cover (2). 2. Pull out the balancing weight (3). 3. Unscrew the screws (4) and remove the cover (5). 4. Scanning unit: – Unscrew the screw (6). –...
Page 113 • Only use the DRIVE-CLiQ encoder and the electronic type plate for the original motor. • Do not mount the DRIVE-CLiQ encoder onto other motors. • Do not replace a DRIVE-CLiQ encoder by a DRIVE-CLiQ encoder belonging to another motor. • Only appropriately trained Siemens service personnel should replace DRIVE-CLiQ encoders. NOTICE Electrostatic discharge Electronic modules contain components that can be destroyed by electrostatic discharge.
Page 114 Maintenance 8.2 Corrective maintenance 8.2.6 Removing/mounting a holding brake (option) Removing/mounting a holding brake (option) is described in the Appendix "Holding brake operating instructions". Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 115 "Spares on Web" provides a quick and uncomplicated way for you to determine the article numbers of standard spare parts and parts kits for motors. Simply enter the article number (machine type) and serial number at: www.siemens.com/sow 1.00 DE bearing assembly, complete 1.01...
Page 116 Spare parts Figure 9-1 Spare parts (example) Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 117 Decommissioning and disposal 10.1 Decommissioning Disassembly of the motor must be carried out and/or supervised by qualified personnel with appropriate expert knowledge. Preparing for disassembling the motor Procedure 1. Contact a certified waste disposal organization in your vicinity. Clarify what is expected in terms of the quality of dismantling the motor and provision of the components.
Page 118 Decommissioning and disposal 10.2 Disposal 10.2 Disposal Recycling and disposal For environmentally-friendly recycling and disposal of your old device, please contact a company certified for the disposal of waste electrical and electronic equipment, and dispose of the old device as prescribed in the respective country of use. Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 119 Notes on operation are provided in the operating instructions provided. Note Maintenance and corrective maintenance Maintenance and corrective maintenance must only be carried out by personnel that have been appropriately authorized by Siemens! See also Properties (Page 31) Operating Instructions for the holding brake (Page 118)
Page 120 Appendix A.2 Operating Instructions for the holding brake Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 121 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 122 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 123 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 124 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 125 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 126 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 127 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 128 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 129 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 130 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 131 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 132 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 133 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 134 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 135 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 136 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 137 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 138 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 139 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 140 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 141 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 142 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 143 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 144 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 145 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 146 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 147 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 148 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 149 Appendix A.2 Operating Instructions for the holding brake Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 150 Appendix A.3 Operating Instructions for the external fan, SH132 Operating Instructions for the external fan, SH132 A.3.1 Operating instructions for the external fan, Type K2D200AB1806 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 151 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 152 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 153 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 154 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 155 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 156 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 157 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 158 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 159 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 160 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 161 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 162 Appendix A.3 Operating Instructions for the external fan, SH132 A.3.2 Operating instructions for the external fan, Type K2D200AB1808 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 163 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 164 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 165 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 166 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 167 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 168 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 169 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 170 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 171 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 172 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 173 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 174 Appendix A.3 Operating Instructions for the external fan, SH132 A.3.3 Operating instructions for the external fan, Type K2D200AB2405 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 175 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 176 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 177 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 178 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 179 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 180 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 181 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 182 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 183 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 184 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 185 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 186 Appendix A.3 Operating Instructions for the external fan, SH132 A.3.4 Operating instructions for the external fan, Type K2D200AB2407 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 187 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 188 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 189 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 190 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 191 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 192 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 193 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 194 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 195 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 196 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 197 Appendix A.3 Operating Instructions for the external fan, SH132 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 198 Appendix A.4 Operating Instructions for the external fan, SH160 Operating Instructions for the external fan, SH160 A.4.1 Operating instructions for the external fan, Type K2D250AB3205 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 199 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 200 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 201 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 202 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 203 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 204 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 205 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 206 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 207 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 208 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 209 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 210 Appendix A.4 Operating Instructions for the external fan, SH160 A.4.2 Operating instructions for the external fan, Type K2D250AB3206 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 211 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 212 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 213 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 214 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 215 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 216 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 217 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 218 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 219 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 220 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 221 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 222 Appendix A.4 Operating Instructions for the external fan, SH160 A.4.3 Operating instructions for the external fan, Type K2D250AB3207 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 223 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 224 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 225 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 226 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 227 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 228 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 229 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 230 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 231 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 232 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 233 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 234 Appendix A.4 Operating Instructions for the external fan, SH160 A.4.4 Operating instructions for the external fan, Type K2D250AB3208 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 235 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 236 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 237 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 238 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 239 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 240 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 241 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 242 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 243 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 244 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 245 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 246 Appendix A.4 Operating Instructions for the external fan, SH160 Main motors 1PH813_1PH816 Operating Instructions, 09/2021, A5E50030782B AD...
Page 247 Index Ambient conditions, 23 Inspection and maintenance, 98 Area of application, 19 Maintenance intervals, 98 Bearing replacement intervals, 101 Mounting the motor, 44 Certificates Nameplate, 25 EAC, 21 Noise emission, 24 EC Declaration of Conformity, 21 Non-operational periods of the motor, 96 UL and cUL, 21 Circuit diagram, 66 Cleaning, 98...
Page 248 Index Technical Support Hotline, (Siemens Service Center), 5 Terminal box, 67 Tightening torques Electrical connections, 65 Foot/flange mounting, 45 Screwed union connections, 111 Training, 5 Transportation, 38 Types of construction, 27 Use for the intended purpose, 19 Vibration strength, 47...

This manual is also suitable for:

1ph8131ph816

Siemens SIMOTICS M-1PH8 Operating Instructions Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Siemens SIMOTICS M-1PH8

Summary of Contents for Siemens SIMOTICS M-1PH8

This manual is also suitable for:
