Page 7
PERFORMANCE CHARTS ARGO 245C / 3SC Cooling only model Conditions: Power source 230 V - 1- 50 Hz - Single phase Indoor air velocity High speed Cooling characteristics Indoor relative humidity 48% Capacity (%) indoor air D.B. temp. DISEGNO MACCHINA outdoor air D.B.temp.
Page 8
ARGO 235H / 3HP Heat pump model Conditions: Power source 230 V - 1- 50 Hz - Single phase Indoor air velocity High speed Cooling characteristics Indoor relative humidity 48% Capacity (%) indoor air D.B. temp. °C DISEGNO MACCHINA outdoor air D.B.temp. °C Power input (%) indoor air D.B.
Page 9
Heating characteristics Outdoor relative humidity 85% Capacity (%) indoor air D.B. temp.20°C DISEGNO MACCHINA outdoor air D.B.temp. °C Power input (%) indoor air D.B. temp.20°C outdoor air D.B.temp. °C COP (%) indoor air D.B. temp.20°C outdoor air D.B.temp. °C...
Page 11
FUNCTIONS 1) Cool Mode Operation In Cooling Mode, the operation of the compressor (CM), Outdoor Fan (FMO) and Indoor Fan (FMI) are determined by the difference between the room air temperature (RAT) and the set point temperature (SPT) as shown in the graph. NOTES 1.
Page 12
2) Heat Mode Operation The Heating mode operation is similar to the Cooling mode operation. The CM, FMO and FMI are mainly controlled by the value of (RAT – SPT). In the graph above, the FMI is operating in AUTO speed mode. Therefore, the FMI speed changes automatically according to the (RT - SPT).
Page 13
3) Auto Mode Operation In Auto Mode, the unit switches automatically between the Auto Cooling and Auto Heating in order to maintain the room temperature (RAT) at the prescribed set point (SPT). The switching between the two modes is according to the above graph. Refer to the sections 1.COOLING MODE and 2.HEATING MODE for system operation details.
Page 14
4) Dry Mode Operation Dry operation remove moisture from indoor air running, in cooling mode, at a low level without reducing the ambient temperature. This is done cycling ON and OFF indoor and outdoor units according to below. ROOM DRY LEVEL TEMP Operation according to COOLING mode ≥...
Page 15
7) Forced Mode In this mode the system operates (COOLING or HEATING mode – fixed settings) or is switched off by means of the OPERATION button on the front panel. The operation modes can be selected pressing the button in a cyclic way (OFF COOL HEAT OFF…).
Page 16
9) Protection operations in Heat Mode 9.1 Cold draft This feature prevents the supply of cold air forcing the indoor fan to a speed which cannot be changed by the user. As soon as the protection mode is exited speed can be changed manually through the remote controller.
Page 17
9.3 Overheat This feature prevents the build up of high pressure in the indoor heat exchanger during heating operation 235H A (°C) B (°C) C (°C)
Page 18
10) I FEEL Function As standard configuration the air conditioner operates detecting the room temperature through the sensor equipped in the wireless remote controller (icon I FEEL shown on the display). This feature provides a personalised environment since the temperature can be detected where the remote controller is located.
Page 19
12) Diagnostic With this feature is possible to have a visual signal that a trouble is occurring. This mode is always active and the signalling is made through the display board LEDS . In case of no troubles the LEDS status follows its normal function. NOTES The troubles are showed according a priority list that is in case of more than one trouble present, is always showed, at first, the one with the highest priority (1...
Page 20
JUMPERS CONFIGURATION Jumpers are located on the indoor PCB near the MODE button. Unit is shipped with jumpers set according to the following table: JUMPER STATUS open open for H/P models - closed for other versions open closed closed...
Page 21
14) MAINTENANCE Changing the Address of the Air Conditioner In case of more than one air conditioner operating in the same room, it may be necessary to assign an address to each unit in order to avoid operation conflicts. Address is set acting on the dip-switches located on the indoor PCB and on the remote controller.
Page 22
15) Manual Unit Control and LED indicators The push button switch and the LED indicators on display panel let the user to control the unit operation without a R/C (Remote Controller). Their operations are provided below. Push Button Switch : Use to cycle the operation mode of the A/C unit among COOL, HEAT and OFF modes, without using the R/C.
Page 23
16) Outdoor fan operation Outdoor fan speed change from HI to Low according to outdoor air temperature as indicated on the chart below.
Page 24
17) DRAIN PUMP Pump operates when the unit is running in COOLING and DRY modes. The level detection is done through a float switch connected at the input FS (closed under normal condition, and opened when water overflow). System operation is according to the following chart: 10sec 0sec 0sec...
Page 25
ELECTRIC WIRING DIAGRAMS 1- Cooling only model ARGO 245C ARGO 3SC LEGENDA Controller SW-IND-ASSY Indicator assy Indoor fan motor TH1-2-3-4-5 Thermistor Compressor motor Terminal plate Overload relay Hot water control Outdoor fan motor Limit water thermostat C1-2-3 Capacitor Water electric valve...
Page 26
2- Heat pump model ARGO 235H ARGO 3HP LEGENDA Controller SW-IND-ASSY Indicator assy Indoor fan motor TH1-2-3-4-5 Thermistor Compressor motor Terminal plate Overload relay Hot water control Outdoor fan motor Limit water thermostat C1-2-3 Capacitor Water electric valve Condensate pump motor...
Page 27
TROUBLESHOOTING CHECK BEFORE AND AFTER «TROUBLESHOOTING» (A) Check power supply wiring. • Check the power supply wires are correctly connected. (B) Check power supply. • Check that voltage is in specified range (±10% of the rating). • Check that power is being supplied. •...
Page 28
2 • The unit does not run. WATER LEVEL ALARM - OPERATION LAMP IS BLINKING. Malfunctioning of the condensate drainanege system. NOTE: In case of emergency the air conditioner can work by drainage the condensate from the little pipe into a rather short container. Extract the little pipe and remove the cap.
Page 29
UNIT AND COMPRESSOR DO NOT RUN. The unit does not run when air conditioner is in the follwing conditions: • When the room temperature is below the setting temperature. • During the protection modes.
Page 30
SOME PARTS OF THE AIR CONDITIONER DO NOT OPERATE.
Page 31
AIR CONDITIONER OPERATES, BUT ABNORMALITIES ARE OBSERVED.
Page 34
EXCESSIVE COOLING OR HEATING. A SENSOR IS DEFECTIVE.
Page 35
REFRIGERANT CHARGE ARGO 245C / 3SC ARGO 235H /3HP REFRIGERANT CHARGE R410A 600 g 520 g IMPORTANT In order to recharge the unit use the high-pressure side gate. Preliminary operation after refrigerant charge DISEGNO...
Page 38
BOILER CONNECTION KIT ONLY FOR MODELS 245C / 235H Typical installation Hot water coil Existing water connections By installer DISEGNO MACCHINA 1/2" Gas Female diameter Electric water valve Controller By installer Air conditioner unit Boiler connection Kit 1) SPECIFICATIONS Power source 230 V ~ 50 Hz Capacity at standard conditions 2100...
Page 39
2) PERFORMANCE CHARTS Performance on different conditions Capacity ruduction factor : High speed = 1 ; Med. speed = 0,96 ; Low speed = 0,93 140% 120% 70° C inlet water temp. 100% 60° C DISEGNO MACCHINA 50° C ∆t = (inlet water temp.) - (outlet water temp.) WATER FLOW AND PRESSURE DROP –...
Page 40
3) COMPONENT SPECIFICATIONS ( Boiler connection kit ) CONTROLLER ( HWC ) Type 000TSA Controls Manual Thermostat Setting 6°C ±1°C ÷ 30°C ±1°C Differential THERMISTOR ( ROOM SENSOR ) TH4 Type STLNGY050 Resistance (at 25° C) kΩ 4,7 ±2% as alternative CONTROLLER ( HWC ) Type 078564-00 Controls...
Page 41
4) HYDRAULIC CONNECTIONS AND VALVES DISEGNO MACCHINA...
