Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual
Kelly Cheetah series KLS-S
Light & flexible Sinusoidal BLDC Motor Controllers
KLS4812S
KLS7212S
KLS8412S
User Manual
Devices Supported:
KLS4818S KLS4830S KLS4812Z KLS4818Z
KLS7218S KLS7230S KLS7212Z KLS7218Z
KLS8418S KLS8412Z KLS8418Z
V2.1.0
Rev. 2.1.0
Sep. 2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the KLS-S Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kelly KLS-S Series

Summary of Contents for Kelly KLS-S Series

  • Page 1 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Kelly Cheetah series KLS-S Light & flexible Sinusoidal BLDC Motor Controllers User Manual Devices Supported: KLS4812S KLS4818S KLS4830S KLS4812Z KLS4818Z KLS7212S KLS7218S KLS7230S KLS7212Z KLS7218Z KLS8412S KLS8418S KLS8412Z KLS8418Z Rev.
  • Page 2 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Contents Chapter 1 Introduction ................2 1.1 Overview........................ 2 Chapter 2 Features and Specifications ............ 2.1 General functions ....................3 2.2 Features ........................ 4 2.3 Specifications ......................5 2.4 Name Regulation ....................5 Chapter 3 Wiring and Installation .............
  • Page 3 KLS-S/KLS-Z are compact variants of standard KLS-N controllers, which equipped with improved housing, providing the same performance in a smaller size. This manual introduces the features, installation, and maintenance of the Kelly sinusoidal brushless DC (BLDC) motor controller. Please read the manual carefully before using the controller.
  • Page 4 8. The controller can be programmed and configured using user program or an Android app. For the PC side, please connect the controller and PC using a Kelly USB cable or a USB-RS232 set to use the user program. For the Android side, please connect the controller to a Bluetooth adapter which purchased from out site to use the configuration app on Android devices.
  • Page 5 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 22. CAN Bus (Optional), broadcast type, with a customizable baud rate(default at 250Khz) . CAN bus is not included by default in KLS-N controllers. 23. Bidirectional anti-slip function (Optional), Prevent the stationary vehicle moving in the opposite direction.
  • Page 6 The name regulation of Kelly BLDC motor controllers KLS4818S/KLS4818Z For example: : Kelly BLDC motor controller based on sinusoidal waveform which is supposed to work with BLDC motor with three hall sensors. All KLS controllers can do regen brake function by default.
  • Page 7 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Kelly KLS-S Space-saving Sinusoidal Brushless Motor Controller Model 1 Minute Boost Continuous Nominal Max Operating Current(Amp) Current(Amp) Voltage(Volt) Voltage(Volt) KLS4812S 36-48 30-60 KLS4818S 36-48 30-60 KLS4830S 36-48 30-60 KLS7212S...
  • Page 8 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 mounting holes’ dimensions Figure 1:KLS-12S (dimensions in millimeters)
  • Page 9 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 mounting holes’ dimensions Figure 2:KLS-18S (dimensions in millimeters)
  • Page 10 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 mounting holes’ dimensions Figure 3: KLS-30S (dimensions in millimeters)
  • Page 11 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Figure 4: KLS-4812Z KLS7212Z KLS8412Z mounting holes’ dimensions (dimensions in millimeters)
  • Page 12 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Figure 5: KLS-4818Z KLS7218Z KLS8418Z mounting holes’ dimensions (dimensions in millimeters)
  • Page 13 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 3.2 Connections 3.2.1 Pin definition of KLS-N Controller waterproof connector Figure 10: DJ7091Y-2.3-11 Pin Definition 1. REV_SW(14): Reverse switch input. ※Orange 2. GND(6): Signal return or power supply return. ※Black 3.
  • Page 14 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 3. GND(20): Signal return. ※Black 4. Meter(8): Copied signal of hall-A sensor. ※Dark Gray 5. 5V(4): 5V Supply, <40mA. ※Purple Brake_AN(2): Brake variable regen or Boost function. ※Brown 12V(11): 12V Supply. ※Red DJ7061Y-2.3-21 Pin Definition...
  • Page 15 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 3.2.2 KLS-N Controller Standard Wiring Figure 11: KLS-N controller standard wiring (Battery is also used as controller’s power supply) Caution! Make sure the controller wiring is correct and has been double checked, especially the B+ and the B- of the controller before power on.
  • Page 16 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 3.2.3 Communication Port A 4pin connector is provided to communicate with host for calibration and configuration. Figure 12: SM-4P connector 3.3 Installation Check List 1. Conduct a visual inspection to ensure that components such as mounting holes, wiring, and sealing rings are intact.
  • Page 17 3. Use the RS232-USB cable and SM-4P adapter provided by Kelly to connect to a host computer. During the opeartion, the PWR of the controller needs to be provided with >+18V (for a 24V controller, provide >+8V).
  • Page 18 You have three way to connect the controller to host computers or Android devices: 1. Using Kelly USB cable, connect SM-4P(Female) from controller to the USB port on computer. You may download Kelly USB Cable driver or at our website.
  • Page 19 11). Please make sure there is no load on the motor shaft before starting the programming. 2. Connect the controller to PC by using a Kelly USB cable or an USB to RS232 set. For Android devices, please use the Bluetooth adapter to connect the controller.
  • Page 20 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 6. Turn on the power supply after the power supply is off for a few seconds. The motor shaft will try to run on random directions. This is a normal operating phenomenon.
  • Page 21 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 4.3 Program parameters and value On program’s initial interface, these items are listed: Default Possible Source of Number Parameter Description Value Value Value* Model Name Controller Model. Default User Name User code, to identify controller variants.
  • Page 22 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Throttle Type, User TPS Type 1 / 2 1: 0-5K,resistance pedal; Configuration 2: 0,5V,Hall active pedal; Throttle Dead Zone Lower Limit, User TPS Dead Low 0-60% 20%*5V=1V. Configuration Throttle Dead Zone Higher Limit,...
  • Page 23 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 User PWM frequency 10 / 16 / 20 PWM modulation frequency (Khz) Configuration Kp of Q-ring, the proportional gain in Q-ring current loop, is mainly effective at speeds below 400 RPM. Increasing this...
  • Page 24 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Brake pedal regen’s regen strength, User BRK_AD Brk 0-50% 0= no regen. Configuration When the anti-theft function is activated, the percentage of the User Anti-theft 0-30% motor's locking current to the maximum current.
  • Page 25 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Limit of Kp and Ki in torque mode, need to be adjusted at User Speed Err Limit 50-4000 1000 same time when adjusting Configuration Kp and Ki in torque mode.
  • Page 26 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 An error will be reported when the amplitude of the sine/cosine sensor signal exceeds this value. User Line Hall High 1-1023 this value / 1024 * 5 = actual voltage value (Volts).
  • Page 27 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Neutral High-pedal function checked/ Checked: the first time throttle being pressed after switching User NTL H-Pedal unchecked unchecked gears, the controller will report a high pedal error to prevent Configuration accidental starting, need to step on the pedal again to start.
  • Page 28 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Anti-Slip function checked/ Checked: enable anti-slip function, User Anti-Slip unchecked unchecked The motor will resist rotation to prevent the vehicle from Configuration moving due to external forces. Change Direction function Checked: Swap the forward and backward directions.
  • Page 29 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 Table 1: Error Codes Buzzer Error Codes Error code Explanation Solution 1. Check Phase line or Hall line. Auto-Identification 2. Check Hall power line(+5V and GND). 1, 1 ¤...
  • Page 30 Kelly Cheetah series KLS-S Sinusoidal BLDC Motor Controller User Manual V2.1.0 fix the issue, check if the throttle is functioning properly. Reserved 3, 1 ¤¤¤ ¤ Current is too high or current fluctuations are too large. Internal reset Reduce the phase current and check if the 5V and 12V 3, 2 ¤¤¤...
