- Page 1 Dolly with Pneumatic Tires Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #52516 SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Strongway™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Main Parts of Product ........................... 5 Assembly Instructions .......................... 6 Operating Instructions .......................... 7 Maintenance ............................7 Parts Diagram ............................8 Parts List .............................. -
Page 4: Intended Use
Intended Use The Strongway Dolly with Pneumatic Tires is intended for moving large, heavy, or bulky items. It may work well when two dollies are used together. This dolly will help you safely move large, heavy items, such as drywall or wood panels, sheets of steel or steel parts, large doors, or any other heavy or bulky items. -
Page 5: Specific Operation Warnings
Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. ... -
Page 6: Assembly Instructions
Assembly Instructions ⚠WARNING IMPORTANT! Repeat for the opposite side. You will have two assemblies when it is complete. Step 1: Assemble the wheel on the shaft of the back plate and lock it with cap. Hardware Needed: Qty 2: Back plate assembly (Part #1) Qty 2: Wheels (Part #3) Qty 2: Cap (Part #5) Qty 6: Flat Washer (Part #4) -
Page 7: Operating Instructions
Operating Instructions Step 1: Adjust the opening of two back plates to fit the item to be moved. Step 2: Set the load or cargo on the adjustable tube. Step 3: Lock with a T-style screw to secure the load or cargo. Maintenance ... -
Page 8: Parts Diagram
Parts Diagram Parts List Part# Description Qty. Back plate Assembly Adjustable Tube Wheels Flat Washer T-style Screw Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. -
Page 9: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Strongway product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 10 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 10 of 10...
