Strongway 64409 Owner's Manual

Strongway 64409 Owner's Manual

44 inch l x 26 inch w 1200-lb. poly dump cart
Hide thumbs
Table of Contents

Advertisement

Quick Links

44 Inch L x 26 Inch W
1200-Lb. Poly Dump Cart
Owner's Manual
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #64409
READ & SAVE THESE INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 64409 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Strongway 64409

Summary of Contents for Strongway 64409

  • Page 1 1200-Lb. Poly Dump Cart Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #64409 READ & SAVE THESE INSTRUCTIONS...
  • Page 2 Thank you very much for choosing a Strongway™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.

  • Page 3: Table Of Contents

    Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Main Parts of Cart ..........................6 Assembly Instructions .......................... 7 Before Each Use ............................ 9 Operating Instructions ..........................

  • Page 4: Intended Use

    Intended Use The Strongway 1200-Lb. Poly Dump Cart is perfect for moving and unloading supplies around the yard when gardening and landscaping. Packaging Contents    Poly Tub Handle Front Axle Assembly    Rear Axle Assembly Dump Lock Handle Cap ...

  • Page 5: Specific Operation Warnings

    ⚠WARNING PERSONAL SAFETY  Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury.

  • Page 6: Main Parts Of Cart

     Do not inflate the tires to more than 30 PSI. Do not use the cart on surfaces or for transporting objects that can cause damage to the pneumatic tires.  Always check of damaged or worn out parts before using the cart. Broken parts will affect the operation.

  • Page 7: Assembly Instructions

    Subassembly 5 – Front Axle Assembly (1) 6 – Rear Axle Assembly (1) 7 – Tires (4) 8 – Hardware Kit (1) Assembly Instructions ⚠WARNING  Read and understand all assembly and operating instructions before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Recommended Tools Screwdriver, needle-nosed pliers, adjustable wrenches STEP 1...
  • Page 8 STEP 2 Assemble the dump lock to the tub of the cart. Tighten all bolts securely. STEP 3 Assemble the front axle assembly to the rear axle assembly. Tighten all bolts securely. STEP 4 Place the wheels onto each axle (valve stem facing out) and secure using washers and cotter pins. Bend back the ends of the cotter pins to keep them in place.

  • Page 9: Before Each Use

    STEP 5 Turn the cart over. Slide the handle cap to the handle. Attach the handle to the yoke. Tighten bolt securely. Before Each Use ⚠WARNING  If any parts become damaged, broken, or misplaced, do not use this cart until replacement parts have been obtained.
  • Page 10 Using the Swivel Handle 1. Remove the clips and cotter pins. 2. Rotate the handle and insert the cotter pin. Secure by attaching the clip. 3. The second cotter pin is used to attach the handle to the trailer hitch. Dumping Feature To use the dumping feature, pull the dumping release handle forward to release the tub from the locking mechanism.

  • Page 11: Maintenance

    Maintenance It is recommended the cart be inspected for damage before each use. Check for damaged parts before each use. Carefully check that the cart will operate properly and perform its intended function. When not in use, store in a safe dry place, out of direct sunlight. Maintenance Interval Maintenance Point ...

  • Page 12: Replacement Parts

    Replacement Parts  For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.  Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ...

  • Page 13: Limited Warranty

    Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Strongway product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase.
  • Page 14 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 14 of 14...
