CODELOCKS KL1100 Programming And Operating Instructions

Hide thumbs Also See for KL1100:

Advertisement

Quick Links

Download this manual
Codelocks Support
KL1100 RFID - Programming and Operating
Instructions
Table of contents
ABOUT KL1100 RFID
STANDALONE MODE
Standard Programming
Additional Programming
Functions
Private Function
Public Function
THE BASICS
Standalone Access
Penalty Time
Batteries
Override Code
Card Types
Master Card
Technician Card
User Card
RCA Registered Card Clients
FIRST USE (INITIALISATION)
For Private Use:
For Public Use:
https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the KL1100 and is the answer not in the manual?

Questions and answers

Related Manuals for CODELOCKS KL1100

Summary of Contents for CODELOCKS KL1100

  • Page 1 Codelocks Support KL1100 RFID - Programming and Operating Instructions Table of contents ABOUT KL1100 RFID STANDALONE MODE Standard Programming Additional Programming Functions Private Function Public Function THE BASICS Standalone Access Penalty Time Batteries Override Code Card Types Master Card Technician Card...
  • Page 2 FACTORY RESET Via Reset Pinhole Button TROUBLESHOOTING Low Battery Battery Failure Override Additional Programming with KL1100 Programmer CHANGE THE MASTER CARD CHANGE THE FUNCTION PROGRAMMING THE LOCK: PRIVATE FUNCTION Adding/Removing User Codes Remove all User Cards Add/Remove a Technician Card...
  • Page 3 Use Override Code RCA MODE Functions RCA Private Function RCA Public Function RCA into Standalone Function Codelocks Desktop Client (CDC) - Offline Software (Recommended) FACTORY RESET Via Reset Pinhole Button Via Programmer DIAGNOSTIC/SERVICE FUNCTIONS Battery Level Check Indicate Firmware Version...
  • Page 4 ABOUT KL1100 RFID The KL1100 RFID can operate in Standalone Mode or in Remote Card Authorisation (RCA) Mode. RCA Mode gives the ability to remotely set-up and allocate cards to locks or lock groups  with our offline or cloud based software.
  • Page 5 Presenting an unregistered card 3 times will incur a 10 second time delay before any further use is possible. Batteries The KL1100 RFID uses 4 x AA batteries. Always use high quality batteries. Dispose of old batteries according to local authority recommendations.
  • Page 6 4. Repeat step 3 to add additional Technician Card. Up to 10 can be active on the lock at any given time. 5. Wait 5 seconds for the Blue LEDs to stop flashing and for the latch to retract. The lock will now be in Public Function. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 7 Standard Programming/Use KL1100 RFID PRIVATE FUNCTION Adding / Removing User Cards 1. Present the Master Card to the lock. 2. Present a new User Card immediately. The Blue LED will start to flash for 5 seconds indicating it is waiting for more cards: a.
  • Page 8 The lock will operate for approximately 100 times with low battery. Battery Failure Override The KL1100 RFID has been designed so that a 5V (max.) mobile power bank can be used to open the lock to allow access to the batteries so they can be replaced should they fail.
  • Page 9 • • 26  • • 4. To exit programming mode, unplug the Programmer. The Red LED will flash once within 5 seconds to confirm. PROGRAMMING THE LOCK: PRIVATE FUNCTION Adding/Removing User Codes 1. Present the Master Card to the lock. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 10 2. Present the Master Card to the lock. 3. Press: #  • • 05  • • 05  • • 4. To exit programming mode, unplug the Programmer. The Red LED will flash once within 5 seconds to confirm. Re-lock Delay https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 11 Add/Remove a Technician Card 1. Plug the Programmer into the lock. 2. Present the Master Card to the lock. 3. Press: # •• 04  •• 4. Present a card to the lock within 5 seconds while the Blue LED is flashing: https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 12 To free a paired User Card: 1. Plug the Programmer into any lock. 2. Present the Master Card to the lock. 3. Press: #  ••  09 •• https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 13 4. To exit programming mode, unplug the Programmer. The Red LED will flash once within 5 seconds to confirm. Disable Auto-Unlock 1. Plug the Programmer into the lock. 2. Present the Master Card to the lock. 3. Press: #  •• 11  •• 2400  •• https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 14 This 4 digit code can be used to unlock in the event that the Master Card is not available. The default Override Code is: # # 2244. Set Override Code 1. Plug the Programmer into the lock. 2. Present the Master Card to the lock. 3. Press: #  ••  98  •• New Override Code  ••  Repeat New Override Code  •• https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 15 Only Master, Initialisation, Block and Audit Card Clients can be created using the RCA method, all others must be created via the Standalone method to function. There is no limit on RCA initialised Master Card Clients, but only 1 Standalone Master Card Client can be registered per lock at any one time. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 16 For instructions on how to use the Office Based Software click here. FACTORY RESET The KL1100 RFID can be factory reset using the button in the latch unit, or via the Programmer. Via Reset Pinhole Button 1. Open latch unit battery compartment and remove 1 battery.
  • Page 17 Note: The Red LED will flash to indicate multiples of 10 and the Blue LED will indicate individual digits. TROUBLESHOOTING Low Battery When the battery power is low the Red LED will flash 3 times before the Blue LED flashes to signal acceptance of the card. Batteries should be changed as soon as this happens. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1100-programming-and-operating-instructions...
  • Page 18 The lock will operate for approximately 100 times with low battery. Battery Failure Override The KL1100 RFID has been designed so that a 5V (max.) mobile power bank can be used to open the lock to allow access to the batteries so they can be replaced should they fail.
