Prerequisites
1. Follow the procedure in
2. Remove the base cover.
About this task
The following images indicate the location of the battery and provide a visual representation of the removal procedure.
Figure 25. Removing the battery
Steps
1. Disconnect the battery cable from the connector (BATTERY) on the system board.
2. Loosen the five captive screws (M2x4.5) that secure the battery to the palm-rest and keyboard assembly.
3. Lift the battery, along with the battery cable, off the palm-rest and keyboard assembly.
NOTE: The battery and the battery cable are separate serviceable parts. If battery replacement is required, reuse the
existing battery cable. To disconnect the battery cable, see

Installing the battery

CAUTION: The information in this section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the battery and provide a visual representation of the installation procedure.
Before working inside your computer.
Disconnecting the battery
Removing and installing Field Replaceable Units (FRUs)
cable.
