GB
The StudSensor
HD55 features two
scanning modes:
• StudScan: Locates the edges of wood
and metal studs up to 19 mm deep
• DeepScan
: Locates the edges
of wood and metal studs up to
38 mm deep
WireWarning
detection automatically
detects and alerts the user to live AC
wires in StudScan and DeepScan
When AC voltage is detected,
the AC WireWarning
displayed on screen.
Visit gb.zircon.com for the most current instructions.
LIMITED TWO-YEAR WARRANTY
Zircon Corporation ("Zircon") warrants to the original
purchaser (or original user by gift) that this product will be
free from defects in materials and workmanship for two
years from date of purchase. This warranty is limited to the
electronic circuitry of the product, and specifically excludes
consumable parts, including batteries, and software, even
if packaged with the product. Defects caused by abuse,
modification, handling contrary to these instructions, other
unreasonable use, or neglect are not covered under this
warranty. No liability is accepted under this Limited Warranty
for normal wear and tear and minor defects which do not
detract from the function of the product. This Limited Warranty
is in addition to the statutory rights to which purchaser is
entitled and which are not excluded by this warranty, to the
extent any such exclusion is permitted by law.
IN NO EVENT WILL ZIRCON BE LIABLE FOR ANY LOSS THAT
IS NOT FORSEEABLE RESULTING FROM POSSESSION, USE,
OR MALFUNCTION OF THIS PRODUCT.
StudSensor
Stud Finder
modes.
icon will be
55
HD
Stud Edge Groove
WireWarning
Detection
Indicator
StudScan
Mode
Power
Button
Any in-warranty defective product returned to the place of
purchase with original proof of purchase will be replaced
or purchase price refunded at retailer's option. This Limited
Warranty applies only to products purchased within the
European Economic Area and United Kingdom. For warranties
applicable to Zircon products purchased in other geographical
areas, see www.zircon.com/warranty-registration.
For questions about this warranty or Zircon products, contact:
Customer Service: +1-408-963-4550
Monday–Friday, 8:00 a.m. to 5:00 p.m. PT
gb.zircon.com • info@zircon.com
DeepScan, SpotLite, StudSensor, WireWarning, and Zircon are
trademarks or registered trademarks of Zircon Corporation.
Zircon Corporation is a wholly owned subsidiary of ZRCN Inc.
©2024 Zircon Corporation
P/N 74314 Rev B 07/24
SpotLite
READY
StudScan
DeepScan
Mode Switch
Pointer
Target
Spotlight
Target
Indication
Bars
READY Icon
DeepScan
Mode
Battery
Door Tab
