  • Page 1 3-242-072-21 (1) Audio Library System Installation/Connections Installation/Anschluss Installation/Connexions Installazione/Collegamenti Montage/Aansluitingen MEX-1HD Sony Corporation © 2002 Printed in Japan...
  • Page 2 121 mm 142.5 mm 18.5 mm 19 mm 60 mm 170 mm Dimensions include unit size, front panel and disc tray open, etc. Abmessungen des Geräts, der Frontplatte und des CD-Fachs in geöffnetem Zustand. Les dimensions comprennent l’appareil lui-même, la façade et le plateau de disque lorsqu’ils sont ouverts, etc.
  • Page 3 Equipment used in illustrations (not supplied) In Abbildungen dargestellte Geräte (nicht mitgeliefert) Appareils utilisés dans les illustrations (non fournis) Apparecchiatura utilizzata nelle illustrazioni (non in dotazione) Apparatuur gebruikt voor illustratiedoeleinden (niet meegeleverd) Active subwoofer Front speaker Aktiver Tiefsttöner Frontlautsprecher Caisson de graves actif Haut-parleur avant Subwoofer attivo Diffusori anteriori...
  • Page 4 (OFF) (RELEASE)
  • Page 6 with the TOP marking up Mit der TOP-Markierung nach oben weisend avec l’inscription TOP vers le haut con l’indicazione ”TOP” rivolta verso l’alto met de zijde met het woord “TOP” naar boven gericht...
  • Page 7 Bend these claws outward for a tight fit, if necessary. Falls erforderlich, diese Klammern für einen sicheren Halt hochbiegen. Pliez ces griffes vers l’extérieur pour assurer une prise correcte si nécessaire. Piegare questi morsetti per un‘installazione più sicura, se necessario. Indien nodig kunt u deze lipjes ombuigen voor een steviger bevestiging.
  • Page 9: Power Connection Diagram

    Dashboard Armaturenbrett Tableau de bord Fire wall Cruscotto Motorraumtrennwand Dashboard Paroi ignifuge Parete tagliafiamma Brandschot Power connection diagram Voorzorgsmaatregelen Auxiliary power connector may vary depending er l’installazione in •Kies de installatieplaats zorgvuldig zodat het toestel de on the car. Check your car’s auxiliary power ca con le operazioni di bestuurder niet hindert tijdens het rijden.
  • Page 10 Auxiliary power connector Hilfsstromanschluss Connecteur d’alimentation auxiliaire Connettore di alimentazione ausiliare Hulpvoedingsaansluiting Rouge Rouge Rosso Rosso Rood Rood Yellow Yellow Gelb Gelb Jaune Jaune Giallo Giallo Geel Geel Yellow continuous power supply switched power supply Gelb permanente Stromversorgung geschaltete Stromversorgung Jaune alimentation continue Rouge...
  • Page 11: Before Installation

    Cautions •This unit is designed for negative earth 12 V DC operation only. •Do not get the wires under a screw, or caught in moving parts (e.g. seat railing). •Before making connections, turn the car ignition off to avoid short circuits. •Connect the power connecting cord 8 to the unit and speakers before connecting it to the auxiliary power connector.
  • Page 12: Mounting Example

    Precautions •Choose the installation location carefully so that the unit will not interfere with normal driving operations. •Avoid installing the unit in areas subject to dust, dirt, excessive vibration, or high temperature, such as in direct sunlight or near heater ducts. •Use only the supplied mounting hardware for a safe and secure installation.
