Vehicle Dock
Quick Start Guide
822002792 (Rev. C) July 2019
See the Safety & Regulatory Addendum included with
your product for additional regulatory, safety and legal
information.
©2019 Datalogic S.p.A. and/or its affiliates. All
rights reserved. Datalogic and the Datalogic logo
are registered trademarks of Datalogic S.p.A. in
many countries, including the U.S. and the E.U.
www.datalogic.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the memor 10 and is the answer not in the manual?

Questions and answers

Related Manuals for Datalogic memor 10

Summary of Contents for Datalogic memor 10

  • Page 1 See the Safety & Regulatory Addendum included with your product for additional regulatory, safety and legal information. ©2019 Datalogic S.p.A. and/or its affiliates. All rights reserved. Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S. and the E.U.

  • Page 2: General View

    Out of the Box The Memor 10 Vehicle Dock package contains: y Memor 10 Vehicle Dock y Quick Start Guide y Safety & Regulatory Addendum Remove all the components from their packaging; check their integrity and compare them with all the packing documents.
  • Page 3 Mount the Ram Mount Adjustable The Ram Mount Adjustable Arm is available as optional accessory (P/N 94ACC0075) and allows wide range of rotation for the dock. It can be mounted on any flat surface while the ball joints enable position flexibility. 1.

  • Page 4: Power The Dock

    CAUTION To reduce quiescent current and extend battery life, disconnect the vehicle dock when the car is not powered. NOTE Available as accessory: 94A050045 POWER ADAPTER 12/24VDC CLA, MEMOR 10 (U.S. Models) 94A050048 POWER ADAPTER,12/24VDC CLA, MEMOR 10 (E.U. Models)
  • Page 5 Charge the Memor 10 To insert the Memor 10 into the vehicle dock, the rubber boot is needed. The rubber boot provides additional protection to the device and is available as optional accessory (P/N 94ACC0193 for; standard models; P/N 94ACC0204 for healthcare models).

  • Page 6: Led Indicators

    LED Indicators LED Behavior Operation Status Power ON Solid green Dock is powered Foreign Object Detection (FOD) Blinks red slow at 0.625Hz Foreign object detected, output power is reduced. Blinks red fast at 2.5Hz Foreign object detected, output power is further reduced.

  • Page 7: Support Through The Website

    Datalogic S.p.A. and/ or its affiliates. Owners of Datalogic products are hereby granted a non- exclusive, revocable license to reproduce and transmit this documentation for the purchaser’s own internal business purposes.
