DIGITAL MEDIA RECEIVER
RÉCEPTEUR NUMÉRIQUE MULTIMÉDIA
RICEVITORE MULTIMEDIALE DIGITALE
RECEPTOR DE MEDIOS DIGITALES
DIGITALER MEDIA RECEIVER
DIGITALE MEDIA-RECEIVER
MVH-330DAB
MVH-130DAB
Quick start guide
Guide de démarrage rapide
Guida rapida all'uso
Guía de iniciación rápida
Schnellstartanleitung
Snelstartgids
1270750036200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVH-330DAB and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer MVH-330DAB

Summary of Contents for Pioneer MVH-330DAB

  • Page 1 DIGITAL MEDIA RECEIVER RÉCEPTEUR NUMÉRIQUE MULTIMÉDIA RICEVITORE MULTIMEDIALE DIGITALE RECEPTOR DE MEDIOS DIGITALES DIGITALER MEDIA RECEIVER DIGITALE MEDIA-RECEIVER MVH-330DAB MVH-130DAB Quick start guide Guide de démarrage rapide Guida rapida all’uso Guía de iniciación rápida Schnellstartanleitung Snelstartgids 1270750036200...
  • Page 2 Pioneer vakuuttaa, että radiolaitetyyppi [*] on direktiivin Español: 2014/53/EU mukainen. Por la presente, Pioneer declara que el tipo de equipo EU-vaatimustenmukaisuusvakuutuksen täysimittainen radioeléctrico [*] es conforme con la Directiva 2014/53/UE. teksti on saatavilla seuraavassa internetosoitteessa: http:// El texto completo de la declaración UE de conformidad www.pioneer-car.eu/compliance...
  • Page 3 • This product is evaluated in moderate and tropical climate condition under the Audio, video and similar electronic apparatus - Safety requirements, IEC 60065. If you experience problems Should this unit fail to work properly, please contact your dealer or nearest authorized PIONEER Service Station.
  • Page 4 Connections Important • When installing this unit in a vehicle without an ACC (accessory) position on the ignition switch, failure to connect the red cable to the terminal that detects operation of the ignition key may result in battery drain. ACC position No ACC position • Use of this unit in conditions other than the...
  • Page 5 RCA pre-outs are stored in memory if the unit is disconnected from power supply. This unit Microphone (Only for MVH-330DAB) 3 m DAB antenna input To receive DAB signals, connect a DAB antenna (CA-AN-DAB.001) (sold separately) to the unit.

  • Page 6: Power Cord

    Power cord To power cord input Depending on the kind of vehicle, the function of may be different. In this case, be sure to connect Yellow Back-up (or accessory) Yellow Connect to the constant 12 V supply terminal. Accessory (or back-up) Connect to terminal controlled by the ignition switch (12 V DC).

  • Page 7: Power Amp (Sold Separately)

    Speaker leads White: Front left White/black: Front left Gray: Front right Gray/black: Front right Green: Rear left Green/black: Rear left Violet: Rear right Violet/black: Rear right ISO connector In some vehicles, the ISO connector may be divided into two. In this case, be sure to connect to both connectors.
  • Page 8 than 60°. • When installing, to ensure proper heat dispersal when using this unit, make sure you leave ample space behind the rear panel and wrap any loose cables so they are not blocking the vents. Leave ample 5 cm space 5 cm DIN mount installation...
  • Page 9 Tapping screw (5 mm × 9 mm, not supplied with product) Mounting bracket Dashboard or console Using the included bracket Check to make sure that the included bracket matches your particular model of vehicle and then attach it to the unit as shown below. Screw Bracket Removing the unit (installed with the...

  • Page 10: Installing The Microphone

    Pull the unit out of the dashboard. Installing the microphone (Only for MVH-330DAB) • The microphone should be placed directly in front of the driver at a suitable distance to pick up their voice clearly.
  • Page 11 Microphone clip Clamps Use separately sold clamps to secure the lead where necessary inside the vehicle. To install on the steering column Fit the microphone into the Microphone Base. Microphone Microphone base with double-sided tape Install the microphone on the rear side of the steering column.

  • Page 12: Basic Operation

    Basic operation MVH-330DAB USB port M.C. (multi-control) dial SRC (source)/OFF DISP (display)/DISP OFF Detach button BAND/DIMMER Display window AUX input jack (3.5 mm stereo jack) MVH-130DAB USB port M.C. (multi-control) dial SRC (source)/OFF DISP (display)/DISP OFF Detach button DAB button...
  • Page 13 About the main menu You can adjust various settings in the main menu. Press the M.C. dial to display the main menu. Turn the M.C. dial to select one of the categories below, then press to confirm. • FUNCTION settings • AUDIO settings • SYSTEM settings Turn the M.C.

  • Page 14: Setup Operation

    Setup operation When you turn the ignition switch to ON after installation, [SETUP:YES] appears in the display. Press the M.C. dial. Turn the M.C. dial to select the options, then press to confirm. To proceed to the next menu option, you need to confirm your selection.

  • Page 15: Tuner Operation

    Rear output [QUIT :YES] appears when all the settings have been made. compartment. Microphone input (Only for MVH-330DAB) To return to the first item of the setup menu, turn the M.C. dial to − Cover any disconnected cable connectors with Antenna input insulating tape.

  • Page 16: Bluetooth Connection

    Perform the pairing operation by operating the unit and the device. NOTE The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Pioneer Corporation is under license. Other trademarks and trade names are those of their respective owners.

  • Page 17: Bluetooth Telephone

    Bluetooth telephone Only for MVH-330DAB Basic operations Purpose Operation Answer an incoming call Press any button when a call is received. End a call Press Reject an incoming call Press and hold when a call is received. Bluetooth audio Connect the Bluetooth device as explained in the “Bluetooth connection”...

  • Page 18: Bass And Treble Control

    Bass and treble control Press the M.C. dial to display the main menu. Turn the M.C. dial to select [AUDIO], then press to confirm. Turn the M.C. dial to select [BASS&TRE], then press to confirm. Turn the M.C. dial to select a tone control from [FLAT] to [EQ : 3] or select [CUSTOM], then press to confirm.
