Setup/Programming Instructions
Programmable Touch Screen
Thermostat
Order Numbers: X13511538010,
BAYSTAT152A,THT02775
Illustration shows a typical Home screen display.
Note:
Any graphics shown in red are only for emphasis in this
document and do not represent the actual thermostat display
screen colors.
Only qualified personnel should install and service the equipment. The installation,
starting up, and servicing of heating, ventilating, and air-conditioning equipment can
be hazardous and requires specific knowledge and training. Improperly installed,
adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
August 2022
SAFETY WARNING
BAS-SVN202D-EN
©2022 Trane
X39641189-01

Advertisement

loading
Need help?

Need help?

Do you have a question about the BAYSTAT152A and is the answer not in the manual?

Questions and answers

Related Manuals for Trane BAYSTAT152A

Summary of Contents for Trane BAYSTAT152A

  • Page 1 Setup/Programming Instructions Programmable Touch Screen Thermostat Order Numbers: X13511538010, BAYSTAT152A,THT02775 Illustration shows a typical Home screen display. Note: Any graphics shown in red are only for emphasis in this document and do not represent the actual thermostat display screen colors.
  • Page 2 Bubbled letters correspond to the letters indicated in each section title. Setpoint display from top clockwise: • Increment • Fahrenheit/Celsius • Decrement • Override hourglass Days of the week • Cool/heat setpoint thermometer Mo–Fr shown selected • Temperature setpoint Sa and Su shown unselected From top to bottom: •...

  • Page 3: Time Setup

    Time Setup D E F I J To set time: 1.From the Home screen (typical Home screen shown in Panel 1), touch to activate the Time Setting Mode. The LCD screen displays hours:minutes (with the hours blinking to indicate it is selected) and either AM or PM as shown:...
  • Page 4 Note: A 20-second time out will also save and exit Dehumidify Setting Mode. 4. Touch to exit without saving any changes. System Mode Setup E F G Note: All system icons may not be available– this is configuration setup dependent. Refer to the Installation/Configuration Instructions (X39641190-01), and Option Number 0130.

  • Page 5: Fan Mode

    Resetting Filter Change Indicator Filter change indicates when the system filter timer has expired. The filter icon will blink continuously 1.5 seconds ON and 0.5 seconds OFF from the Home screen or TOV active screen until reset. To reset the filter change indicator, press and hold both left and right arrows at the same time for 3 seconds.
  • Page 6 Timed Override (TOV) B C E F G OV can be used to temporarily override the scheduled temperature setpoint and/or fan settings. There are two ways to enter TOV Mode from the Home screen: • Quick TOV; Touch the Occ ( ) or Unocc ( ) icon from the Home screen.

  • Page 7: General Notes

    Note: Desired settings are also activated after a 20-second time out. • To Cancel the TOV time period, touch at any time to cancel and exit TOV Mode. General Notes: • TOV setup has three modes: TOV Setpoint Setup, TOV Time Setup, and TOV Active.
  • Page 8 Schedule Setup Schedule Display Mode A C E This display mode is used to view current settings such as setpoints, periods, and day of the week as shown in the illustration on the right. When in Schedule Display Mode, the user cannot change settings. •...
  • Page 9 Morning Day Evening Night Time Heat Cool Fan Trane has a policy of continuous product and product data improvement and reserves the Trane - by Trane Technologies (NYSE: TT), a global climate innovator - creates right to change design and specifications without notice. We are committed to using comfortable, energy efficient indoor environments for commercial and residential environmentally conscious print practices.
