Quick Setup Guide
Guide d'installation rapide
KM24A KM24A-P
English
* The colour and the appearance may differ depending on the product, and the specifications are subject
to change without prior notice to improve the performance.
* Recommended hours of use per day of this product is under 16 hours. If the product is used for longer
than 16 hours a day, the warranty may be void.
* Download the user manual from the website for further details.
http://www.samsung.com/displaysolutions
Français
* La couleur et l'aspect du produit peuvent varier en fonction du modèle, et ses spécifications peuvent
être modifiées sans préavis pour des raisons d'amélioration des performances.
* Il est recommandé d'utiliser ce produit moins de 16 heures par jour. L'utilisation quotidienne du produit
pendant une durée supérieure à 16 heures peut entraîner l'annulation de la garantie.
* Téléchargez le manuel utilisateur du site Web pour obtenir plus de détails.
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator,
Inc. in the United States and other countries.
BN68-11641D-02

Advertisement

loading
Need help?

Need help?

Do you have a question about the KM24A and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung KM24A

  • Page 1 Quick Setup Guide Guide d’installation rapide KM24A KM24A-P English * The colour and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. * Recommended hours of use per day of this product is under 16 hours. If the product is used for longer than 16 hours a day, the warranty may be void.
  • Page 2 Checking the Components Vérification des composants English Display: Quick Setup Guide / Warranty card (Not • available in some locations) / Regulatory guide / Power cord / RS232C(IN) adapter Connection box: Power strip / OCM cable / Screw(M4, • L12) x 7 / Screw(M3, L5) x 11 / Screw(M3, L8) x 2 / Sheet cover x 2 / EFT Terminal cover holder / EFT Terminal holder guide Contact the vendor where you purchased the product if...
  • Page 3 ‫حامل جهاز الخدمة الذاتية غير مرفق. يجب عليك شراء الحامل وتركيبه‬ .‫بشكل منفصل‬ Ports Ports USB1 RS232C1 TOUCH HDMI ONE CONNECT (5V 1.0A) Português English Porta Descrição Port Description Liga-se a um MDC utilizando um adaptador RS232C. RS232C1 RS232C1 Connects to MDC using an RS232C adapter. Liga-se a um PC através de um cabo USB (para TOUCH ), para ativar funções táteis.
  • Page 4 Assembling the display and the Connection Box Assemblage de l'écran et du module de connexion Screw(M4, L12) Screw(M4, L12) x 4 Français English CAUTION: Connect the power cable after completing the assembling process. ATTENTION : ne branchez pas CAUTION: Use the provided power strip only. Retail power strips cannot be ATTENTION : utilisez uniquem assembled to the Connection Box, and the safety is not guaranteed.
  • Page 5 Screw(M4, English CAUTION: Connect the power cable after completing the assembling process. CAUTION: Use the provided power strip only. Retail power strips cannot be assembled to the Connection Box, and the safety is not guaranteed. CAUTION: The power cable must be disconnected when you connect the cable. Tighten the screws on the bottom of the Connection Box to prevent tip-over.
  • Page 6 256.3 mm English Português CAUTION: Connect the power cable after completing the assembling process. ATENÇÃO: ligue o cabo de alimentação só após concluir o processo de montagem. CAUTION: Use the provided power strip only. Retail power strips cannot be ATENÇÃO: utilize apenas a tomada múltipla fornecida. As tomadas múltiplas disponív assembled to the Connection Box, and the safety is not guaranteed.
  • Page 7 Ingenico Lane3000/5000 , P400 Lane3000/5000 (le terminal de paiement n'est ni fourni Ingenico Lane3000/5000 (Thiết bị thanh toán không ).‫ جهاز الدفع أو تبيعه‬Samsung ‫(ال توفر شركة‬ ni vendu par Samsung) được Samsung cung cấp hoặc bán.) sold by Samsung.) Français...
  • Page 8 VESA holes by pressing them with a pen from the inner side of the rear cover, and then install the wall-mount bracket. Wall mount bracket Product VESA screw hole Thread size C (mm) Quantity Model specs (A * B) (mm) 7.0 (Min.) ~ KM24A 200 x 200 9.0 (Max.)
  • Page 9 Connecting and using a source device Connexion et utilisation d'un appareil source English To connect a PC or other source device, you must have an HDMI cable or a USB cable (for TOUCH ) connected to the display before assembling it to the Connection Box. Français Pour connecter un PC ou tout autre appareil source, un câble HDMI ou USB (pour TOUCH ) doit être connecté...
  • Page 10 Connecting to a PC/video device Connexion à un PC / dispositif vidéo HDMI HDMI TOUCH English Connect a USB cable (for TOUCH ) before connecting to a PC. Français Connectez un câble USB (pour TOUCH ) avant la connexion à un PC.
  • Page 11 Português Ligue um cabo USB (para TOUCH ) antes de ligar a um PC. Tiếng Việt Kết nối cáp USB (đối với TOUCH ) trước khi kết nối với PC. 繁體中文 先連接 USB 纜線(適用於 TOUCH )才能連接至電腦。 ‫العربية‬ .‫) قبل التوصيل بجهاز كمبيوتر‬TOUCH ‫...
  • Page 12 Kiosk Home menu Menu d'accueil de l'application Kiosk English When you turn on the product without the Kiosk app installed, the home menu appears. • To display the home menu when the Kiosk app or external device (connected with an •...
  • Page 13: Contact Samsung World Wide

    Este é um produto de classe A. Num ambiente doméstico, este produto poderá provocar interferência radioelétrica. Caso tal aconteça, o • utilizador poderá ter de tomar medidas adequadas. AUSTRALIA 1300 362 603 Para obter mais informações sobre as especificações do dispositivo, visite o website da Samsung . • AUSTRALIA 1300 362 603 IRAN...
  • Page 14 Country/Area Customer Care Centre 021-5699-7777 INDONESIA 0800-112-8888 (Toll Free) 021-8255 IRAN 80010080 IRAQ ISRAEL *6963 0800-22273 JORDAN 06 5777444 KENYA 0800 545 545 183-CALL (183-2255) KUWAIT LAOS +856-214-17333 LEBANON 1598 0800 333 MACAU 1800-88-9999 MALAYSIA +603-7713 7420 (Overseas contact) 800 5050 MAURITIUS MOROCCO 080 100 22 55...
  • Page 15: Saudi Arabia

    NEW ZEALAND 0800 726 786 NIGERIA 0800 726 7864 OMAN 800-SAM CS (800-72627) PALESTINE +970-2-2792447 PAKISTAN 0800-Samsung (7267864) 1-800-10-726-7864 [ PLDT Toll Free ] 1-800-8-726-7864 [ Globe Landline and PHILIPPINES Mobile ] 02-8-422-2111 [ Standard Landline ] 800-CALL (800-2255) QATAR REUNION...
  • Page 16 TAIWAN 0809-00-5237 (B2B / Dealer) TANZANIA 0800 780 089 Hotline no : 1282 1800-29-3232 (Toll free for all THAILAND product) 80 100 012 TUNISIA U.A.E 800-SAMSUNG (800 - 726 7864) 0800 300 300 UGANDA VIETNAM 1800 588 889 ZAMBIA 3434...
