Page 2
Main Page Safety Instructions Notational Power Installation Cleaning Other Introduction Unpacking Front Rear Bottom Setup Connecting Your Monitor Installing the Monitor Driver Automatic Manual Base Installation Main > Index On-Screen Display Troubleshooting Check List Q & A Self-Test Feature Check Specifications General Specifications Preset Timing Modes...
Page 3
Notational Power Installation Clean Other Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment. Prohibited Do not disassemble Do not touch Main > Safety Instructions > Notational Important to read and understand at all times Disconnect the plug from the outlet Grounding to prevent an electric shock...
Page 4
Notational Power Installation Clean Other When not used for extended periods of time, set your PC to DPMS. If using a screen saver, set it to the active screen mode. If the size of your monitor is small, or if the same image is present for long periods of time, you may see afterimages due to damage to the fluorescent substance on the inside of the CRT.
Page 5
Notational Power Installation Clean Other Do not cover the vents on the monitor cabinet. Bad ventilation may cause a breakdown or fire. Put your monitor in a location with low humidity and a minimum of dust. An electric shock or fire could result inside the monitor. Do not drop the monitor when moving it.
Page 6
You can prevent the coated CRT from being damaged or the monitor cabinet from being dissolved, cracked or discolored. You can buy a recommended detergent at any Samsung Service Center. If the connector between the plug and the pin is dusty or dirty, clean it properly with a dry cloth.
Page 7
Notational Power Installation Clean Other Do not remove cover(or back). No user serviceable parts inside. This may cause an electric shock or a fire. Refer servicing to qualified service personnel. If your monitor does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized dealer or...
Page 8
Keep the monitor away from any magnetic substances. This may cause discoloring or distortion of the image.
Page 9
Unpacking Front Rear Bottom (Some models include a stand attached. ) Please make sure the following items are included with your monitor. If any items are Monitor and Stand missing, contact your dealer. Power Cord Stand Quick Setup Guide Warranty Card (Not available in all locations) User's Guide and Driver Installation CD...
Page 10
Monitor and Stand Unpacking Front Rear Bottom (Some models include a stand attached. ) Please make sure the following items are included with your monitor. If any items are missing, contact your For Multimedia model (Option) Multimedia Speaker Stand SyncMaster 753Ms Power Cord Stand Quick Setup Guide...
Page 11
Unpacking Front Rear Bottom 1. Exit button 2,3. Adjust buttons 4. Menu button 5. Power indicator 6. Power button Note: See PowerSaver functions. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. Use this button to Exit the active menu or the OSD.
Page 12
Unpacking Front Rear Bottom (The configuration at the back of the monitor may vary from product to product.) 1. Power port 2. Signal Cable Note: See Connecting Your Monitor Connect the power cord for your monitor to the power port on the back of the monitor.
Page 13
Unpacking Front Rear Bottom 1. Signal Cable 2. Power port 3. Tilt/Swivel Base Connect the signal cable to the video port on your computer, video board, video card, or graphics card. Connect the power cord for your monitor to the power port on the back of the monitor.
Page 14
Connecting Your Monitor Installing the Monitor Driver Base Installation 1. Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. 2. Connect the signal cable to the video port on your computer, video board, video card, or graphics card.
Page 15
1. Setup-General Connecting Your Monitor Installing the Monitor Driver Base Installation 1. Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet. 2.
Page 16
1. Turn off your computer and unplug the power cord. 2. Connect the end of the signal cable to your computer's video port(video board, video card or graphics card). 3. Connect one end of a sound cable to the Stereo Output jack on your sound card or computer.Connect the other end of the cable to the Stereo Input jack on the back of the monitor stand Connect one end of the other sound cable to the Mic Input jack on your sound card or...
Page 17
5. Monitor driver installation is completed. Windows XP/2000 1. Insert CD into the CD-ROM driver. 2. Click "Windows XP/2000 Driver". 3. Choose your monitor model in the model list, then click the "OK" button. http://www.samsung-monitor.com/ http://www.samsungusa.com/monitor/ http://www.sec.co.kr/monitor/ (Korea) http://www.samsungmonitor.com.cn/ (WorldWide)
Page 18
5. If you can see following "Message" window, then click the "Continue Anyway" button. Then click "OK" button. This monitor driver is under certifying MS logo,and this installation don't damage your system.The certified driver will be posted on Samsung Monitor Homepage http://www.samsung-monitor.com/. 6. Monitor driver installation is completed.
Page 19
2. Click "Start" —> "Control Panel" then click the "Appearance and Themes" Icon. 3. Click "Display" icon and choose the "Settings" tab then click "Advanced..". 4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab. Windows Me Windows NT http://www.samsung-monitor.com/ http://www.samsungusa.com/monitor/ http://www.sec.co.kr/monitor/ http://www.samsungmonitor.com.cn/ ®...
Page 20
8. If you can see following "Message" window, then click the "Continue Anyway" button. Then click "OK" button. This monitor driver is under certifying MS logo,and this installation don't damage your system.The certified driver will be posted on Samsung Monitor Homepage http://www.samsung-monitor.com/. 9. Click the "Close" button then click "OK" button continually.
10. Monitor driver installation is completed. ® ® Microsoft Windows 2000 Operating System When you can see "Digital Signature Not Found" on your monitor, follow these steps. 1. Choose "OK" button on the "Insert disk" window. 2. Click the "Browse" button on the "File Needed" window. 3.
® ® Microsoft Windows NT Operating System 1. Click Start, Settings, Control Panel, and then double-click Display icon. 2. In Display Registration Information window, click Settings Tab and then click All Display Modes. 3. Select a mode that you wish to use (Resolution, Number of colors and Vertical frequency) and then click OK.
Page 23
Connecting Your Monitor With the built-in pedestal, you can tilt and/or swivel the monitor for the most comfortable Installing the Monitor Driver viewing angle. Base Installation Note: The base is detachable. If your monitor was supplied with the base detached, attach the base as follows. Remove the twist-tie before attaching the base to the monitor.
Page 24
Attaching the Base 1. Place the monitor upside-down on a flat work surface. 2. Align the tabs on the base with the corresponding slots on the bottom of the monitor. 3. Press the base onto the monitor until the tabs are fully engaged in the slots. 4.
On Screen Display (OSD) Menu System Menu How to adjust Brightness Adjust the Brightness. With the menu off, push the menu Push the - button or + button until the Brightness screen is displayed. Push the menu button to open the Brightness adjustment screen. Use the + button to increase the brightness or - button to decrease the brightness.
Page 27
On Screen Display (OSD) Menu System Menu How to adjust H-Position Follow these instructions to change the Position of the monitor’s entire display. With the menu off, push the menu Push the - button or + button until the H-Position screen is displayed.
Page 28
On Screen Display (OSD) Menu System Menu How to adjust H-Size Follow these instructions to change the Size of the monitor’s entire display. With the menu off, push the menu Push the - button or + button until the H-Size screen is displayed. Push the menu button to open the H-Size adjustment screen.
Page 29
On Screen Display (OSD) Menu System Menu How to adjust Pincushion Adjust the pincushion setting when the sides of the display are bowed in or bowed out With the menu off, push the menu Push the - button or + button until the Pincushion screen is displayed.
Page 30
On Screen Display (OSD) Menu System Menu How to adjust Parallelogram Adjust the parallelogram setting when the display is leaning left or right. With the menu off, push the menu Push the - button or + button until the Geometry screen is displayed.
Page 31
On Screen Display (OSD) Menu System Menu How to adjust Pinbalance Adjust the pinbalance setting when the sides of the display are bowed towards the left or right. With the menu off, push the menu Push the - button or + button until the Geometry screen is displayed.
Page 32
On Screen Display (OSD) Menu System Menu How to adjust Language Follow these steps to change the language used in the menu. You can choose one of ten languages. English,German,French, Italian, Portuguese, Spanish, Swedish, Russian, Polish, or Magyar. (Some OSD languages may not appear in some areas.) With the menu off, push the menu Push the - button or + button until the Language screen is displayed.
Page 33
On Screen Display (OSD) Menu System Menu How to adjust H-Moire A “Moiré” pattern can appear on your screen, looking like a series of concentric circles or arcs. To eliminate this pattern, use the clear moiré adjustments. With the menu off, push the menu Push the - button or + button until the Advanced screen is displayed.
On Screen Display (OSD) Menu System Menu How to adjust Video Input Level Some video cards use video signals higher than 1.0V which causes the display to be very bright. For those video cards, use this feature to select the 1.0V Level. With the menu off, push the menu Push the - button or +button until the Advanced screen is displayed.
Page 35
On Screen Display (OSD) Menu System Menu How to adjust Zoom Follow these instructions to get a close-up or a longshot view of the monitor’s viewing area. With the menu off, push the menu Push the - button or + button until the Zoom screen is displayed.
Page 36
On Screen Display (OSD) Menu System Menu How to adjust Degauss The Degauss feature will remove color impurities caused by magnetic fields. You can use this function to turn on the power of the monitor or change the power saving mode to the normal mode. Do not use the Degauss feature more than once within a 30-minute period.
On Screen Display (OSD) Menu System Menu How to adjust Display Timing The information on this screen shows Display Timing , User Timing and Factory Timing. With the menu off, push the menu Push the - button or + button until the Display Timing screen is displayed.
Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the warranty card, Check List Symptom Q & A Self-Test Feature Check No images on the screen.
Page 39
Is the screen displaying only The screen shows one color as if looking at the strange colors or screen through a cellophane just black and paper? white. Have the screen colors become strange after running a program or due to a crash between applications? Has the video card been set properly?
Page 40
5. If you have problems in installing the adapter (video) driver, boot the computer in Safe Mode, remove the Display Adapter at the "Control Panel, System, Device Administrator" and then reboot the computer to reinstall the adapter (video) driver. Note: If problems repeatedly occur, contact an authorized service center.
Page 41
Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the warranty card, the phone number on the Information section or contact your Check List Q &...
Page 42
Is the screen displaying only The screen shows one color as if looking at the strange colors or screen through a cellophane just black and white. paper? Have the screen colors become strange after running a program or due to a crash between applications? Has the video card been set properly?
Page 43
The sound is too thick. The microphone is not working. The sound is distorted. Check the following items if there is trouble with the monitor. 1. Check if the power cord and the cable are properly connected to the computer. 2.
Page 44
How can I change the frequency? Check List Q & A Self-Test Feature Check How can I adjust the resolution? How can I set the Power Saving function? The monitor makes a sound when it is turned on. How can I clean the outer case/Picture tube? Question Frequency can be changed by reconfiguring the video...
Page 45
Your monitor provides a self test feature that allows you to check whether your monitor is functioning properly. Check List Q & A Self-Test Feature Check 1. Turn off both your computer and the monitor. 2. Unplug the video cable from the back of the computer. 3.
Page 46
1 If th 1. If there are any woofer speakers near the monitor, unplug and relocate the woofer to another room. 2. Remove all electronic devices such as radios, fans, clocks and telephones that are within 3 feet (one meter) of the monitor. 3.
Page 47
General Model Name Picture Tube General Type PowerSaver Preset Timing Deflection angle Modes Dot Pitch Screen type Maximum Resolution 1280 Dots, 1024 Lines Active Display Horizontal Vertical Synchronization Horizontal Vertical Input Signal Definition Video Signal Sync Signal Display Color Unlimited Maximum Pixel Clock 110 MHz Power Supply...
Page 48
® This monitor is EPA E NERGY used with a computer equipped with VESA DPMS functionality. ® As an E Partner, SAMSUNG has determined that this product meets NERGY ® the E guidelines for energy efficiency. NERGY Power-off Mode EPA/ENERGY...
Page 49
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Table 1.
Page 50
General Model Name Picture Tube General Type PowerSaver Preset Timing Deflection angle Modes Dot Pitch Screen type Maximum Resolution 1280 Dots, 1024 Lines Active Display Horizontal Vertical Synchronization Horizontal Vertical Input Signal Definition Video Signal Sync Signal Display Color Unlimited Maximum Pixel Clock 110 MHz Power Supply...
Page 51
® This monitor is EPA E NERGY used with a computer equipped with VESA DPMS functionality. ® As an E Partner, SAMSUNG has determined that this product meets NERGY ® the E guidelines for energy efficiency. NERGY Power-off Mode EPA/ENERGY...
Page 52
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Table 1.
Page 53
General Model Name Picture Tube General Type PowerSaver Preset Timing Deflection angle Modes Dot Pitch Screen type Maximum Resolution 1280 Dots, 1024 Lines Active Display Horizontal Vertical Synchronization Horizontal Vertical Input Signal Definition Video Signal Sync Signal Display Color Unlimited Maximum Pixel Clock 110 MHz Power Supply...
Page 54
® This monitor is EPA E NERGY used with a computer equipped with VESA DPMS functionality. ® As an E Partner, SAMSUNG has determined that this product meets NERGY ® the E guidelines for energy efficiency. NERGY Power-off Mode EPA/ENERGY...
Page 55
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Table 1.
Page 56
General Model Name Picture Tube General Type PowerSaver Preset Timing Deflection angle Modes Dot Pitch Screen type Maximum Resolution 1280 Dots, 1024 Lines Active Display Horizontal Vertical Synchronization Horizontal Vertical Input Signal Definition Video Signal Sync Signal Display Color Unlimited Maximum Pixel Clock 110 MHz Power Supply...
Page 57
Frequency Response 180Hz ~ 20,000Hz Power Supply DC (Adapter) 12V / 1A Note: Design and specifications are subject to change without prior notice.
Page 58
® This monitor is EPA E NERGY used with a computer equipped with VESA DPMS functionality. ® As an E Partner, SAMSUNG has determined that this product meets NERGY ® the E guidelines for energy efficiency. NERGY Power-off Mode EPA/ENERGY...
Page 59
If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows. Table 1.
Page 60
U.S.A. : Samsung Computer Products Customer Service 400 Valley Road, Suite 201, Mt. Arlington, NJ 07856 Tel. : (973)601-6000, 1-800-SAMSUNG (1-800-726-7864) Service Fax. : (973)601-6001 http://www.samsungusa.com/monitor/ Terms BRAZIL : Regulatory Samsung Eletronica da Amazonia Ltda. Natural Color R. Prof. Manoelito de Ornellas, 303, Terro B Authority Chacara Sto.
Page 61
175 SOI SUEKSA VIDHAYA SATHON SOI 12 SILOM ROAD ,SILOM,BANGRAK BANGKOK 10500 TEL : 0-2635-2567 FAX : 0-2635-2556 SOUTH AFRICA : Samsung Electronics,5 Libertas Road, Somerset Office Park, Bryanston Ext 16. Po Box 70006, Bryanston,2021, South Africa Tel : 0027-11-549-1621 Fax : 0027-11-549-1629 http://www.samsung.co.za/ UKRAINE : SAMSUNG ELECTRONICS REPRESENTATIVE OFFICE IN UKRAINE 4 Glybochitska str.
Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the 'Dot Pitch'. Unit: mm Service Vertical Frequency Terms The screen must be redrawn several times per second in order to create and display an image...
Page 64
Communications Commission. It is available from the U.S. Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4. The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA Tel) 949-975-7310...
Page 65
Products with the CE Marking comply with both the EMC Directive (89/336/EEC), (92/31/EEC), (93/68/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European Norms: EN55022:1998 - Radio Frequency Interference EN55024:1998 - Electromagnetic Immunity EN61000-3-2:1995+A1+A2 - Power Line Harmonics EN61000-3-3:1995 - Voltage Fluctuations...
Page 66
reasonable for the user. Labelled products must meet strict environmental demands, for example in respect of the reduction of electric and magnetic fields, along with physical and visual ergonomics and good usability. TCO Development Unit 1996-11-29 On the page this folder you will find a brief summary of the environmental requirements met by this product.
Page 67
Why do we have environmentally labelled computers? In many countries, environmental labelling has become an established method for encouraging the adaptation of goods and services to the environment. The main problem, as far as computers and other electronics equipment are concerned, is that environmentally harmful substances are used both in the products and during their manufacture.
Page 68
For more information, refer to Help (F1) in the software program. How to install the Natural Color software Insert the CD included with the Samsung monitor into the CD-ROM Drive. Then, the initial screen of the program installation will be executed. Click Natural Color on the initial screen to install the Natural Color software.
Page 69
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Service Co., Ltd. is strictly forbidden. Terms Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or Regulatory consequential damages in connection with the furnishing, performance, or use of this material. Natural Color Authority Samsung is the registered trademark of Samsung Electronics Co., Ltd.;...
