GB
MetalliScanner
™
metal up to 15.2 cm deep in concrete and other non-metallic surfaces. The easy-to-
read display screen indicates target depth in both centimeters and inches.
Crosshairs
Recalibration
Switch
Power/Mode
Switch
Battery Compartment
MetalliScanner
Electronic Metal Locator
MT 6 locates, and differentiates between, ferrous and non-ferrous
Liquid
Crystal
Display
MT 6
™
1. INSTALLING THE BATTERY
Push in the battery door tab and open the door.
Insert a new 9V alkaline battery, matching the
positive (+) and negative (-) terminals and replace
the door.
Zircon stud finders and detectors, particularly those
with LCD screens, require and consume a great deal
of current from batteries. For optimal performance,
brand-new, recently purchased alkaline batteries are
strongly recommended for use in these tools. If you
are experiencing any trouble with your tool, contact
your Zircon dealer or email info@zircon.com.
2. GETTING FAMILIAR
WITH THE DISPLAY
Depth Range Numbers
Plus/Minus Sign
Depth Bars
Magnetic/Non-Magnetic Icon
Silent icon
Audible
icon
Low Battery icon

Advertisement

loading
Need help?

Need help?

Do you have a question about the MetalliScanner MT 6 and is the answer not in the manual?

Questions and answers

Related Manuals for Zircon MetalliScanner MT 6

Summary of Contents for Zircon MetalliScanner MT 6

  • Page 1 Insert a new 9V alkaline battery, matching the positive (+) and negative (-) terminals and replace the door. Zircon stud finders and detectors, particularly those with LCD screens, require and consume a great deal of current from batteries. For optimal performance,...
  • Page 2 The display has indicators that indicate status and show information about detected objects (targets). There are 3 status indicators: low battery, audible, and silent icons. The low battery icon is displayed when the battery has less than five hours of use remaining.
  • Page 3 • The MT 6 performs a calibration immediately after it is turned on. Note: If the unit fails to calibrate, you will hear a long, low-pitched tone and all the depth bars will be displayed. If this happens, check the area for any large metal objects and remove them or move the unit to a different location.
  • Page 4 • If desired, mark target locations. Crosshairs on the top and front of the unit show where sensitivity is maximum. 5. RECALIBRATION FOR MAXIMUM DEPTH ACCURACY The MT 6 automatically calibrates when turned on. However, depth accuracy is dependent on the materials in the vicinity of the measurement, in particular, when the materials may contain metal or metallic minerals, as is common with various...

  • Page 5: Special Considerations

    • Large metallic objects, such as pieces of sheet metal, at very shallow depths may give erroneous indications of metal type (magnetic vs. non-magnetic). WARNING 1. Always turn off power when working near electrical wires. 2. In situations involving multiple, closely spaced targets, the MT 6 may be unable to detect the exact location and/or depth of each piece of metal.
  • Page 6 ZirconToolPro ZirconTools other warranties, express or implied, and no other representations or claims of any nature shall bind or obligate Zircon. Any implied warranties applicable to this product are limited to the two year period following its purchase. © 2016 Zircon Corporation • P/N 62148 • Rev D 12/16...
