- Page 1 CD RDS RECEIVER AUTORADIO CD RDS SINTOLETTORE CD RDS REPRODUCTOR DE CD CON RECEPTOR RDS CD RDS-EMPFÄNGER CD RDS-ONTVANGER DEH-S410BT DEH-S41BT DEH-S310BT Quick start guide Guide de démarrage rapide Guida rapida all’uso Guía de iniciación rápida Schnellstartanleitung Snelstartgids QRD3579-A...
- Page 2 - Safety requirements, IEC 60065. CAUTION This product is a class 1 laser product classified under the Safety of laser products, IEC 60825-1:2007. If you experience problems Should this unit fail to work properly, please contact your dealer or nearest authorized PIONEER Service Station.
- Page 3 Connections Important • When installing this unit in a vehicle without an ACC (accessory) position on the ignition switch, failure to connect the red cable to the terminal that detects operation of the ignition key may result in battery drain. ACC position No ACC position •...
- Page 4 to ground. − Never band together negative cables of multiple speakers. • When this unit is on, control signals are sent through the blue/white cable. Connect this cable to the system remote control of an external power amp or the vehicle’s auto-antenna relay control terminal (max.
-
Page 5: Power Cord
Power cord To power cord input Depending on the kind of vehicle, the function of may be different. In this case, be sure to connect Yellow Back-up (or accessory) Yellow Connect to the constant 12 V supply terminal. Accessory (or back-up) Connect to terminal controlled by the ignition switch (12 V DC). -
Page 6: Power Amp (Sold Separately)
Gray/black: Front right Green: Rear left or subwoofer Green/black: Rear left or subwoofer Violet: Rear right or subwoofer Violet/black: Rear right or subwoofer ISO connector In some vehicles, the ISO connector may be divided into two. In this case, be sure to connect to both connectors. - Page 7 a sudden stop. • Install this unit away from hot places such as near the heater outlet. • Optimum performance is obtained when the unit is installed at an angle of less than 60°. • When installing, to ensure proper heat dispersal when using this unit, make sure you leave ample space behind the rear panel and wrap any loose cables so they are not blocking the vents.
-
Page 8: Installing The Microphone
Tighten two screws on each side. Tapping screw (5 mm × 9 mm, not supplied with product) Mounting bracket Dashboard or console Removing the unit (installed with the supplied mounting sleeve) Remove the trim ring. Trim ring Notched tab • Releasing the front panel allows easier access to the trim ring. - Page 9 to arrange the lead. NOTE Depending on the vehicle model, the microphone cable length may be too short when you mount the microphone on the sun visor. In such cases, install the microphone on the steering column. To install on the sun visor Fit the microphone lead into the groove.
- Page 10 Install the microphone on the rear side of the steering column. Double-sided tape...
-
Page 11: Basic Operation
Basic operation DEH-S410BT/S41BT/S310BT (navigation)/LIST USB port (eject) M.C. (multi-control) dial SRC (source)/OFF Disc loading slot Detach button DISP (display) Display window AUX input jack (3.5 mm stereo jack) BAND/ About the main menu You can adjust various settings in the main menu. -
Page 12: Setup Operation
Frequently used operations Purpose Operation Press SRC/OFF to turn on the Turn on the power power. Press and hold SRC/OFF to turn off the power. Turn the M.C. dial. Adjust the volume Press SRC/OFF repeatedly. Select a source Press DISP repeatedly. Change the display information Press BAND/ Return to the previous display/list... -
Page 13: Tuner Operation
[USB CONN. SET] appears when all the settings have been made. Press the M.C. dial to clear the message. • A message that prompts you to install the Pioneer Smart Sync application will appear on your device by connecting your device to the unit via USB. - Page 14 Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu. Turn the M.C. dial to select [FUNCTION], then press to confirm. Turn the M.C. dial to select [BSM], then press to confirm. To store stations manually While receiving the station you want to store, press and hold one of the number buttons (1/ to 6/ ) until it stops flashing.
-
Page 15: Bluetooth Connection
MTP connection A device installed with Android OS 4.0 or most of later versions can be connected to the unit via MTP, using the cable supplied with the Android device. However, depending on the connected device, OS version or the numbers of the files in the device, audio files/songs may not be able to be played back via MTP. -
Page 16: Bluetooth Telephone
To exit the voice recognition mode, press BAND/ Making a connection with Pioneer Smart Sync Pioneer Smart Sync is the application that intelligently brings your maps, messages, and music together in the vehicle. NOTE DEH-S310BT is not compatible with Apple devices. - Page 17 Pioneer Smart Sync. − For devices other than the USB-connected Android device, press SRC/OFF to select any source and press and hold the M.C. dial. − For iPhone, launch Pioneer Smart Sync on the mobile device.
-
Page 18: Listening To Spotify
Listening to Spotify® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings.) NOTE DEH-S310BT is not compatible with Apple devices. Update the firmware of the Spotify application to the latest version before use. Before you start, connect this unit with the mobile device via USB (iPhone only) or Bluetooth. Enter the SYSTEM menu (refer to “About the main menu”). - Page 19 Pioneer vakuuttaa, että radiolaitetyyppi [*] on direktiivin Español: 2014/53/EU mukainen. Por la presente, Pioneer declara que el tipo de equipo EU-vaatimustenmukaisuusvakuutuksen täysimittainen radioeléctrico [*] es conforme con la Directiva 2014/53/UE. teksti on saatavilla seuraavassa internetosoitteessa: http:// El texto completo de la declaración UE de conformidad www.pioneer-car.eu/compliance...
