CD RDS RECEIVER
AUTORADIO CD RDS
REPRODUCTOR DE CD CON RECEPTOR RDS
DEH-S5120BT
DEH-S5100BT
DEH-S4120BT
DEH-S4100BT
DEH-S31BT
Important (Serial number)
The serial number is located on the bottom of this unit. For your own security and
convenience, be sure to record this number on the enclosed warranty card.
Important (Numéro de série)
Le numéro de série se trouve au bas de cet appareil. Pour votre sécurité et votre commodité,
veillez à noter ce numéro sur la carte de garantie fournie.
Importante (Número de serie)
El número de serie se encuentra en la parte inferior de esta unidad. Por su propia seguridad
y comodidad, asegúrese de anotar este número en la tarjeta de garantía que se adjunta.
Guide de démarrage rapide
Guía de inicio rápido
Quick start guide
QRD3581-D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DEH-S5120BT and is the answer not in the manual?

Questions and answers

Related Manuals for Pioneer DEH-S5120BT

Summary of Contents for Pioneer DEH-S5120BT

  • Page 1 CD RDS RECEIVER AUTORADIO CD RDS REPRODUCTOR DE CD CON RECEPTOR RDS DEH-S5120BT DEH-S5100BT DEH-S4120BT DEH-S4100BT DEH-S31BT Quick start guide Guide de démarrage rapide Guía de inicio rápido Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.
  • Page 2 FEDERAL COMMUNICATIONS COMMISSION SUPPLIER’S DECLARATION OF CONFORMITY Product Name: CD RDS RECEIVER Model Number: DEH-S5120BT/DEH-S5100BT/DEH-S4120BT/DEH-S4100BT/DEH-S31BT Responsible Party Name: PIONEER ELECTRONICS (USA), INC. SERVICE SUPPORT DIVISION Address: 2050 W. 190TH STREET, SUITE 100 TORRANCE, CA 90504, U.S.A. Phone: 1-310-952-2915 URL: http://www.pioneerelectronics.com...
  • Page 3 The Safety of Your Ears is in Your Hands Get the most out of your equipment by playing it at a safe level—a level that lets the sound come through clearly without annoying blaring or distortion and, most importantly, without affecting your sensitive hearing.
  • Page 4 After-sales service for Pioneer products Please contact the dealer, distributor from where you purchased this unit or the authorized PIONEER Service Station for after-sales service or any other information. In case the necessary information is not available, please contact the companies listed below: Please do not ship your unit to the companies at the addresses listed below for repair without contacting them in advance.
  • Page 5 Doing so may result in battery drain or a malfunction. • The graphical symbol placed on the product means direct current. This unit DEH-S5120BT/S5100BT DEH-S4120BT/S4100BT DEH-S31BT Microphone 3 m (9 ft. 10-1/8 in.) Power cord input...

  • Page 6: Power Cord

    Microphone input Rear output Front output Antenna input Fuse (10 A) Wired remote input Hard-wired remote control adapter can be connected (sold separately). Subwoofer output Rear output or subwoofer output* * The ringtone and caller’s voice of the Bluetooth telephone are not output from the rear speakers. Power cord Perform these connections when not connecting a rear speaker lead to a subwoofer.
  • Page 7 Do not connect anything to the green and green/black leads. Not used. Subwoofer (4 Ω) × 2 Orange/white (Only for DEH-S5120BT/S5100BT) Connect to a car’s illumination signal.

  • Page 8: Power Amp (Sold Separately)

    Power amp (sold separately) Perform these connections when using the optional amplifier. DEH-S5120BT/S5100BT DEH-S4120BT/S4100BT DEH-S31BT System remote control Connect to blue/white cable. Power amp (sold separately) Connect with RCA cables (sold separately) To rear output Rear speaker To front output...

  • Page 9: Installation

    Installation Important • Check all connections and systems before final installation. • Do not use unauthorized parts as this may cause malfunctions. • Consult your dealer if installation requires drilling of holes or other modifications to the vehicle. • Do not install this unit where: −...
  • Page 10 • Make sure that the unit is installed securely in place. An unstable installation may cause skipping or other malfunctions. When not using the supplied mounting sleeve Determine the appropriate position where the holes on the bracket and the side of the unit match.

  • Page 11: Installing The Microphone

    Pull the unit out of the dashboard. To secure the front panel The front panel can be secured with the supplied screw. Screw Installing the microphone The microphone should be placed directly in front of the driver at a suitable distance to pick up their voice clearly.
  • Page 12 Install the microphone clip on the sun visor. Lowering the sun visor reduces the voice recognition rate. Microphone clip To install on the steering column Slide the microphone base to detach it from the microphone clip. Microphone Microphone clip Microphone base Install the microphone on the rear side of the steering column.

  • Page 13: Basic Operation

    Basic operation DEH-S5120BT/S5100BT M.C. (multi-control) dial USB port SRC (source)/OFF Disc loading slot (eject) DISP (display) BAND/ Display window Detach button BASS (navigation)/LIST AUX input jack (3.5 mm stereo jack) DEH-S4120BT/S4100BT/S31BT (navigation)/LIST USB port (eject) M.C. (multi-control) dial SRC (source)/OFF...
  • Page 14 About the main menu You can adjust various settings in the main menu. Press the M.C. dial to display the main menu. Turn the M.C. dial to select one of the categories below, then press to confirm. • FUNCTION settings •...

  • Page 15: Setup Operation

    [USB CONN. SET] appears when all the settings have been made. Press the M.C. dial to clear the message. • A message that prompts you to install the Pioneer Smart Sync application will appear on your device by connecting your device to the unit via USB.

  • Page 16: Tuner Operation

    Tuner operation Receiving preset stations Press SRC/OFF to select [RADIO]. Press BAND/ to select the band. [FM1] [FM2] [FM3] [AM] Press a number button (1/ to 6/ ). Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu.

  • Page 17: Bluetooth Connection

    USB/iPhone Open the USB port cover. Plug in the USB device/iPhone using an appropriate cable. MTP connection A device installed with Android OS 4.0 or most of later versions can be connected to the unit via MTP, using the cable supplied with the device. However, depending on the connected device, OS version or the numbers of the files in the device, audio files/songs may not be able to be played back via MTP.

  • Page 18: Bluetooth Telephone

    To exit the voice recognition mode, press BAND/ Making a connection with Pioneer Smart Sync Pioneer Smart Sync is the application that intelligently brings your maps, messages, and music together in the vehicle.
  • Page 19 − For devices other than the USB-connected Android device, press SRC/OFF to select any source and press and hold the M.C. dial. − For iPhone, launch Pioneer Smart Sync on the mobile device. Listening to Pandora® (Not available when [USB MTP] is set to [ON] in the SYSTEM settings.) NOTE DEH-S31BT is not compatible with Apple devices.

  • Page 20: Listening To Spotify

    Turn the M.C. dial to select [APP CONTROL], then press to confirm. Turn the M.C. dial to select one of the below. • Select [WIRED] for the USB connection. • Select [BLUETOOTH] for the Bluetooth connection. Press SRC/OFF to select [PANDORA]. Launch the Pandora application on the mobile device and start playback.
