Pelican 7110 Instruction Manual

Cat. #7110
7110
INSTRUCTION MANUAL
This compact flashlight produces an ultra bright
pre-focused light beam by using a high-efficiency LED
powered by either (1) AA alkaline, (1) CR123 lithium or
(1) AA NiMH rechargeable battery. The 7110 flashlight is
designed for easy use with one hand operation and has a
dual-switch mode for constant-on or momentary-on
activation. The 7110 body is made by high precision CNC
machines from aerospace-grade aluminum alloy and is
hard anodized for the most durable construction. The lens
is constructed with anti-reflective (AR) glass for added
durability and increased light output. The 7110 carries an
ingress protection level of IPX8, which allows for use in
the most inclement weather conditions.
TO INSERT BATTERIES
1. Remove the tail cap by turning counter-clockwise.
2. Install battery (see figure 1) with + terminal facing to
the head assembly.
3. Replace the tail cap onto the flashlight by turning
clockwise until sealed.
OPERATION
To select a program, partially depress the button
(momentary press, do not click) as indicated in the table
below and hold until the 7110 flashes in
acknowledgment.
The light will flash to let you know that a new program
has successfully been selected. The number of
flashes indicates the program number.
Program 1
(default) High > Strobe > Medium > Low
Program 2 High Only
Program 3 High > Medium > Low
Program 4 Low > Medium > High
Program 5 High > Low
To change the mode within a program, depress the
button (momentary, do not click) once for each step in
the program. Presses need to be within .5 second.
Fully depress the switch to lock on the desired mode.
To turn off, fully depress the switch once more.
The 7110 has a full-time battery status indicator built in.
The small LED between the collar and the head
indicates the battery status when the light is turned on:
Green
Amber
Red
Note: The battery status indicator is calibrated for one AA alkaline
or one CR123 Lithium battery. It will not show accurate battery
status with any other usable battery types.
= Full
= Mid
= Low
Momentary Confirmation
presses
8
10
12
14
16
flashes
*
**
***
****
*****
