  • Page 1 CD RDS RECEIVER AUTORADIO CD RDS REPRODUCTOR DE CD CON RECEPTOR RDS DEH-S7200BHS Quick start guide Guide de démarrage rapide Guía de inicio rápido Important (Serial number) The serial number is located on the bottom of this unit. For your own security and convenience, be sure to record this number on the enclosed warranty card.
  • Page 2 Before You Start Thank you for purchasing this PIONEER product To ensure proper use, please read through this guide before using this product. It is especially important that you read and observe WARNINGS and CAUTIONS in this guide. Please keep the guide in a safe and accessible place for future reference.
  • Page 3 FEDERAL COMMUNICATIONS COMMISSION SUPPLIER’S DECLARATION OF CONFORMITY Product Name: CD RDS RECEIVER Model Number: DEH-S7200BHS Responsible Party Name: PIONEER ELECTRONICS (USA), INC. SERVICE SUPPORT DIVISION Address: 2050 W. 190TH STREET, SUITE 100 TORRANCE, CA 90504, U.S.A. Phone: 1-310-952-2915 URL: http://www.pioneerelectronics.com The Safety of Your Ears is in Your Hands Get the most out of your equipment by playing it at a safe level—a level that lets the sound...
  • Page 4 WARNING • Rear visibility systems (backup cameras) are required in certain new vehicles sold in the U.S. and Canada. U.S. regulations began according to a two year phase-in on May 1, 2016, and both the U.S. and Canada require that all such vehicles manufactured on or after May 1, 2018 have rear visibility systems.
  • Page 5 After-sales service for Pioneer products Please contact the dealer, distributor from where you purchased this unit or the authorized PIONEER Service Station for after-sales service or any other information. In case the necessary information is not available, please contact the companies listed below: Please do not ship your unit to the companies at the addresses listed below for repair without contacting them in advance.
  • Page 6 Connections In the following, “NW” represents network mode and “STD” represents standard mode. According to the connections you have established, change the speaker mode to standard mode (STD) or network mode (NW). WARNING • When speaker output is used by 4 channels, use speakers rated over 50 W (maximum input power) and between 4 Ω...
  • Page 7 Important • When installing this unit in a vehicle without an ACC (accessory) position on the ignition switch, failure to connect the red cable to the terminal that detects operation of the ignition key may result in battery drain. ACC position No ACC position •...
  • Page 8 • When this unit is on, control signals are sent through the blue/white cable. Connect this cable to the system remote control of an external power amp or the vehicle’s auto-antenna relay control terminal (max. 300mA 12 V DC). If the vehicle is equipped with a glass antenna, connect it to the antenna booster power supply terminal.
  • Page 9 This unit Microphone 3 m (9 ft. 10-1/8 in.) SiriusXM Connect Vehicle Tuner input Power cord input Microphone input Rear output (STD) or middle range output (NW) Front output (STD) or high range output (NW) Antenna input Fuse (10 A) Wired remote input Hard-wired remote control adapter can be connected (sold separately).

  • Page 10: Power Cord

    Power cord Perform these connections when not connecting a rear speaker or middle range speaker lead to a subwoofer. White White/black Gray Gray/black Green Green/black Violet Violet/black Black Yellow Blue/white Orange/white...
  • Page 11 Perform these connections when using a subwoofer without the optional amplifier. White White/black Gray Gray/black Green Green/black Violet Violet/black Black Yellow Blue/white Orange/white Green Green/black Violet Violet/black Important In the case of above, two 4 Ω subwoofers wired in parallel will represent a 2 Ω load.
  • Page 12 To power cord input Front left speaker (STD) or high range left speaker (NW) Front right speaker (STD) or high range right speaker (NW) Rear left speaker (STD) or middle range left speaker (NW) Rear right speaker (STD) or middle range right speaker (NW) White White/black...

  • Page 13: Power Amp (Sold Separately)

    Power amp (sold separately) Perform these connections when using the optional amplifier. System remote control Connect to blue/white cable. Power amp (sold separately) Connect with RCA cables (sold separately) To rear output (STD) or middle range output (NW) Rear speaker (STD) or middle range speaker (NW) To front output (STD) or high range output (NW)

  • Page 14: Installation

    Installation Important • Check all connections and systems before final installation. • Do not use unauthorized parts as this may cause malfunctions. • Consult your dealer if installation requires drilling of holes or other modifications to the vehicle. • Do not install this unit where: −it may interfere with operation of the vehicle.
  • Page 15 DIN mount installation Insert the supplied mounting sleeve into the dashboard. Secure the mounting sleeve by using a screwdriver to bend the metal tabs (90°) into place. Dashboard Mounting sleeve • Make sure that the unit is installed securely in place. An unstable installation may cause skipping or other malfunctions.
  • Page 16 Removing the unit (installed with the supplied mounting sleeve) Remove the trim ring. Trim ring Notched tab • Releasing the front panel allows easier access to the trim ring. • When reattaching the trim ring, point the side with the notched tab down. Insert the supplied extraction keys into both sides of the unit until they click into place.

  • Page 17: Installing The Microphone

    Installing the microphone The microphone should be placed directly in front of the driver at a suitable distance to pick up their voice clearly. CAUTION It is extremely dangerous to allow the microphone lead to become wound around the steering column or shift lever. Be sure to install the microphone in such a way that it will not obstruct driving.
  • Page 18 To install on the sun visor Fit the microphone lead into the groove. Microphone lead Groove Install the microphone clip on the sun visor. Lowering the sun visor reduces the voice recognition rate. Microphone clip...
  • Page 19 To install on the steering column Slide the microphone base to detach it from the microphone clip. Microphone Microphone clip Microphone base Install the microphone on the rear side of the steering column. Double-sided tape...
  • Page 20 Leave ample 5 cm Basic operation space Tighten the screws on each side. 5 cm DEH-S7200BHS M.C. (multi-control) dial USB port Disc loading slot (eject) SRC (source)/OFF DISP (display) Screw Mounting bracket Dashboard or console • Use either truss (5 mm × 9 mm) or flush surface (5 mm ×...
  • Page 21 Frequently used operations Purpose Operation Microphone clip Press SRC/OFF to turn on the Turn on the power power. Double-sided tape Press and hold SRC/OFF to turn off the power. Turn the M.C. dial. Adjust the volume Press SRC/OFF repeatedly. Select a source Press DISP repeatedly.
  • Page 22 Turn the M.C. dial to select the options, then press to confirm. To proceed to the next menu option, you need to confirm your selection. Menu Item Description LANGUAGE Select the language to display the text information from a compressed audio file. [ENG](English), [ESP](Spanish), [FRA]...
  • Page 23 HD Radio™ operation Receiving preset stations Press SRC/OFF to select [HD RADIO]. Press BAND/ to select the band. [FM1] [FM2] [FM3] [AM] Press a number button (1/ to 6/ ). Best stations memory (BSM) After selecting the band, press the M.C. dial to display the main menu.
  • Page 24 CD/USB/iPhone®/AUX operation (iPhone source is not available when [USB MTP] is set to [ON] in the SYSTEM settings.) Insert a disc into the disc loading slot with the label side up. To eject a disc, stop playback first then press . USB/iPhone Open the USB port cover.
  • Page 25 Bluetooth connection Up to two Bluetooth telephones can be connected simultaneously. Turn on the Bluetooth function of the device. Select the unit name shown in the device display. Make sure the same 6-digit number appears on this unit and the device.
  • Page 26 Bluetooth telephone Basic operations Purpose Operation Answer an incoming call Press any button when a call is received. End a call Press Reject an incoming call Press and hold when a call is received. Activating voice recognition mode Press and hold and then talk into the microphone to input voice commands.
  • Page 27 Pioneer Smart Sync. − For devices other than the USB-connected Android device, press SRC/OFF to select any source and press and hold the M.C. dial. − For iPhone, launch Pioneer Smart Sync on the mobile device.
  • Page 28 Preparing for the SiriusXM Satellite Radio service Press SRC/OFF to select [SIRIUSXM]. Press to select Channel 0. The Radio ID appears on the display. In addition, the Radio ID is located on the bottom of the SiriusXM Connect Vehicle Tuner. NOTE The Radio ID does not include the letters I, O, S or F.
