- Page 1 PORTABLE INVERTER GENERATOR Owner’s Manual SUA4600iF DO NOT RETURN TO STORE! CALL US FIRST 855-888-3598 FOR SUPPORT Model# 1491012 REV00 Model: Serial: Date Purchased: SAVE THIS MANUAL FOR FUTURE REFERENCE P/N: 32082-07126-00...
-
Page 2: Table Of Contents
Table of Contents Maintenance And Storage....23 Introduction..........1 Safety............1 Maintenance Schedule......23 General Safety Precautions....2 Engine Maintenance......23 Safety and Dataplate Labels....8 Engine Oil Level Check......23 Unpacking the Generator.......9 Change Engine Oil........24 Parts Included........9 Spark Plug Maintenance.......25 Controls and Features......10 Valve Clearance........25 Control Panel Features......11 Air Filter Maintenance......25 Specifications........13 Cleaning the Spark Arrestor....26... -
Page 3: Introduction
If any section of this manual is not understood, contact customer Service at 855-888-3598, or www.a-ipower.com for starting, operating and servicing procedures. The owner is responsible for proper maintenance and safe use of the unit. SAVE THESE INSTRUCTIONS for future reference. -
Page 4: General Safety Precautions
Asphyxiation Electric Shock Fire Hazard Hazard Hazard Hot Surface. Explosion Moving Parts Do Not Touch the Surface. Hazard Hazard Burn Hazard Operator’s Manual Kickback GENERAL SAFETY PRECAUTIONS • Operate this product ONLY outside and at least 20 feet away from windows, doors and vents to Using a generator indoors CAN KILL YOU IN MINUTES. -
Page 5: Incorrect Usage
CORRECT USAGE Example location to reduce risk of carbon monoxide poisoning • Operate generators outside and at least 20 feet away from any structure with exhaust pointed away from doors and windows. at least 20 feet away from windows, doors and vents INCORRECT USAGE Do not operate in any of the following locations: •... - Page 6 WHEN STARTING EQUIPMENT WARNING • Ensure spark plug, muffler, fuel cap, and air Starter cord kickback (rapid retraction) cleaner are in place. will pull hand and arm toward engine • DO NOT crank engine with spark plug removed. faster than you can let go which could WHEN OPERATING EQUIPMENT cause broken bones, fractures, bruises, or sprains resulting in serious injury.
- Page 7 • It is a violation of California Public Resource Code, DANGER Section 4442, to use or operate the engine on any Contact with terminals, bare wires and forest-covered, brush-covered, or grass-covered electrical connections when generator land unless the exhaust system is equipped with a is running will result in death or serious spark arrester, as defined in Section 4442, injury.
- Page 8 • DO NOT tamper with governor spring, links or other WARNING parts to increase engine speed. Generator supplies Medical and Life Support Uses. correct rated frequency and voltage when running • In case of emergency, call 911 immediately. at governed speed. •...
- Page 9 Button/Coin Battery Safety WARNING • INGESTION HAZARD: This product contains a button cell or coin battery. • DEATH or serious injury can occur if ingested. • A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours. •...
-
Page 10: Safety And Dataplate Labels
EL PROSPECTO ANTES DE USARLO. Avoid other generator hazards. READ MANUAL BEFORE USE. LIRE LES INSTRUCTIONS AVANT UTILISATION. 10.00 Fuel Safety Symbols Hot Surface SUA4600iF MODEL NO.:1491012 REV 00 AC Voltage: 120V RPM: 3400-5000 AC Current: 30.0A Power Factor: Nameplate... -
Page 11: Unpacking The Generator
UNPACKING THE GENERATOR • Open carton completly. Remove and verify carton content prior to assembly. Your generator ships with following items. • Call our customer service at 855-888-3598 with the unit model and serial number for any missing item. • Record model, serial number, and date of purchase on front cover of this munual for your own record. -
Page 12: Controls And Features
CONTROLS AND FEATURES 9 10 1112 1 - Fuel Gauge 8 - Fuel valve 2 - Fuel Tank 9 - Air Filter 3 - Choke Lever 10 - Carburator 4 - Control Panel 11 - Oil Filler Cap/Dipstick 12 - Spark Plug 5 - Frame 6 - Fuel Cap 13 - Muffler/Spark Arrester... -
Page 13: Control Panel Features
CONTROL PANEL FEATURES DAIMAO DAIMAO 1.Engine Switch: Flip the switch to the “ON (l) ” position 6. 120V AC, 30A Twist Lock Outlet, Single Phase,60 Hz Outlet (NEMA L5-30R): This receptacle can provide and pull the recoil starter to start the generator. Turn to the “OFF (O) ”position to turn off the generator. - Page 14 CONTROL PANEL FEATURES LED Data Center DAIMAO DAIMAO 1. Output Ready Indicator LED (Green): Illuminates 3. Oil Warning Indicator LED (Red): Illuminates when when the generator is operating normally and the engine oil level falls below the safe operating level indicates the generator is producing electrical power and the generator will automatically shut off the engine.
-
Page 15: Specifications
SPECIFICATIONS SUA4600iF Model Number 1491012 4600W Starting Watts Running Watts 3600W Rated AC Voltage 120V Rated DC Voltage 60Hz Rated Frequency Phase Single Grounding System (AC) Neutral Floating Engine Type Single Cylinder, 4-Stroke OHV Air Cooled 149cc Engine Displacement Starting System... -
Page 16: Co Watch-Guard
CO WATCH-GUARD Carbon Monoxide (CO) Detection and Auto Shutoff System Your Generator is equipped with Carbon Monoxide (CO) WATCH-GUARD detect system for your protection and safety. This detecting and shutoff system monitors for the accumulation of poisonous CO gas around the generator produced by engine exhaust when the generator is running. - Page 17 The generator is shutoff automatically and the yellow light will blink for at least five minutes after shutoff. Call A-iPower Customer Service 855-888-3598 for repair. Do not use the generator until the sensor is working properly. The CO WATCH-GUARD must only be serviced by qualified technician to restore it to original settings.
-
Page 18: Add Engine Oil
Add Engine Oil NOTICE We recommend using SAE 10W-30 APISJ oil for We consider the first 5 hours of run time to be the best performance. Other high-quality detergent oils break-in period for the unit. During the break in (APISJ or higher) are acceptable. Do not use special period stay at or below 50% of the running watt additives.Ambient temperature determines the proper rating and vary the load occasionally to allow stator... -
Page 19: Operation At High Altitude
To operate at high altitudes A-iPower • If fuel spills, wait until it evaporates before starting can provide a high altitude carburetor main jet. The engine. -
Page 20: Operation
OPERATION Generator Location Surge suppressors come in single- or multi-outlet styles. They’re designed to protect against virtually WARNING all short-duration voltage fluctuations. Make sure you review each warning in order to For Cold Weather Starting prevent fire hazard. • While you must run your generator outside, you may keep the generator in a covered area to protect the generator and its battery from cold Using a generator indoors CAN KILL YOU IN MINUTES. -
Page 21: Connecting Electrical Loads
4. Add gasoline to the fuel tank. WARNING Starter cord kickback (rapid retraction) will pull hand and arm toward engine faster than you can let go which could cause broken bones, fractures, bruises, or sprains resulting in serious injury. When starting engine, pull cord slowly until resistance is felt and then pull rapidly to avoid 5. -
Page 22: Low Idle Switch
Stopping the Engine 1. Turn off and remove entire electrical loads. Never start or stop the generator with electrical devices plugged in or turned on. Let the generator run at no-load for two minutes to stabilize internal temperatures of the engine and generator. -
Page 23: Low Oil Shutdown
Parallel Operation (2 x SUA4600iF Models) WARNING WARNING Fuel and its vapors are extremely flammable and explosive which could cause burns, fire or explosion Fire and electrocution hazard. Never connect or resulting in death or serious injury. disconnect the parallel cord leads when a generator DO NOT stop engine by moving choke control to is running. - Page 24 NOTE: 2. Both generators to be turned off and all electrical It is strongly recommended to plug in devices loads disconnected before paralleling operation. with the largest output first and the smallest output last to help prevent overloading the inverters. Do not exceed maximum wattage rating of inverters, parallel 2min kit and receptacles.
-
Page 25: Maintenance And Storage
MAINTENANCE AND STORAGE MAINTENANCE SCHEDULE NOTE: Maintenance should be performed more frequently Regular Maintenance will improve the performance when generator is used in dusty areas. and extend the life of your generator. Follow When generator has exceeded the maximum figures maintenance schedule intervals whichever occurs specified in the table, maintenance should still be first according to use. -
Page 26: Change Engine Oil
Recommended Engine O il Type CAUTION 1 0W -3 0 Avoid prolonged or repeated skin contact with used motor oil. 5 W -3 0 1 0W -4 0 1. Remove the oil filler cap. 5 W-3 0 Full Synt hetic 2. -
Page 27: Spark Plug Maintenance
Spark Plug Maintenance The spark plug must be properly gapped and free of deposits in order to ensure proper engine operation. 0.7 - 0.8 mm To check: 0.028 - 0.031 in. 1. Remove the fuel tank (C). 2. Remove the spark plug cap (B). 3. -
Page 28: Cleaning The Spark Arrestor
Cleaning the Spark Arrestor Short Term Storage 1. allow the engine to cool down completely before Fill the tank with fresh gasoline and add gasoline carrying out fender maintenance. stabilizer. Drain the carburetor float bowl. 2. loosen screw (A) to remove pressure block (B). 1 - Add a properly formulated FUEL STABILIZER to 3. - Page 29 DRAINING THE FLOAT BOWL 1. Turn the fuel tank valve to the OFF position. 2. Locate the drain screw on the bottom of the carburetor float bowl. 3. Place an appropriate gasoline container to catch the drained fuel. 4. Loosen the float bowl drain screw and allow the fuel to drain from the drain tube.
-
Page 30: Trouble Shooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Engine is running, 1. AC Circuit breaker is open. 1. Check AC load and reset circuit breaker. but no AC output is 2. Fault in generator. 2. Contact customer service or authorized service center. available. -
Page 31: Parts Diagram And Parts List
PARTS DIAGRAM AND PARTS LIST SUA4600iF PARTS DIAGRAM(GENERATOR) Page 29... -
Page 32: Parts List
Parts List Part Number Description Qty. Part Number Description Qty. 30111-00008-00 Screw(M5*10) 30101-00339-00 Screw(M6*12) 20114-08676-00 Control panel assembly 20030-00062-00 Recoil starter handle 30101-00339-00 Screw(M6*12) 30101-00339-00 Screw(M6*12) 33369-00412-00 Panel seat 30111-00088-00 Screw(M5*14) 30101-00339-00 Screw(M6*12) 30101-00339-00 Screw(M6*12) 20014-00893-00 Inverter bracket 30101-00341-00 Screw(M6*16) 30111-00088-00 Screw(M5*14) 31026-00161-01... - Page 33 PARTS DIAGRAM (ENGINE) Page 31...
- Page 34 Parts List Part Number Description Qty. Part Number Description Qty. 70002-06622-01 Air cleaner cover 33129-00094-00 Closure plate 70010-02321-00 Air filter 30110-00188-00 Intake stud(M6XM6X85) 34028-00062-00 Breather hose 30101-00408-00 Screw(M6*25) 34024-00004-00 Metal clip 30125-00002-00 Nut(M6) 30101-00400-00 Screw(M6*16) 30125-00023-00 Nut(M8) 20034-00149-00 Recoil assembly 20202-01044-00 Muffler assembly 30101-00408-00...
- Page 35 Parts List Part Number Description Qty. 30110-00018-00 Intake stud(M6*M6*100) 34012-00050-00 Carburetor spacer 33048-00440-00 Carburetor gasket 20024-00544-00 Carburetor 34023-00410-00 Fuel hose 34024-00024-00 Clamp(B9.5) 33048-00441-00 Air cleaner base gasket 30125-00002-00 Nut(M6) 34023-00199-00 Intake tube 34024-00031-00 Clamp(B14) Page 33...
-
Page 36: Circuit Diagram
Circuit Diagram Page 34... -
Page 37: Warranty
Warranty Term related service due to obstructions and other build ups resulting from improper maintenance. A-iPower will provide warranty for any of its products Additional exclusions - this warranty does not cover purchased through any authorized AiPower dealer in wearable parts such as filers, spark plugs, o-rings, North America to the original purchaser and will be batteries etc. - Page 38 Warranty limits and Implications and Consequential Damages A-iPower is not obligated to cover any loss of time, use of product, freight cost, or any other incidental or consequential claim from the use of this product. This warranty is in Lieu of all other warranties, express or implied.
- Page 39 Fontana, CA 92337 USA Phone: 855-888-3598 support@a-ipower.com www.a-ipower.com...
- Page 40 A-iPOWER WARRANTY REGISTRATION FORM Register your product by emailing this form to support@a-ipower.com or register on-line at: www.a-ipower.com. Registering your product is important , it provides the following protections: 1. You have record of product purchased 2. Customer Service can Better serve you for Warranty related issues...
- Page 41 Fontana, CA 92337 USA Phone: 855-888-3598 support@a-ipower.com www.a-ipower.com...
