Installation Guide
Included Installation Instructions
Network Camera
WV-SBV131M/WV-SBV111M
Model No.
● This manual describes the installation procedures, network camera installation, cable connections,
and the angle of view adjustment.
● Before reading this manual, be sure to read the Important Information.
● This manual describes how to install the network camera using model WV-SBV131M as an
example.
For U.S. and Canada:
Panasonic i-PRO Sensing Solutions
Corporation of America
800 Gessner Rd, Suite 700 Houston, TX 77024
https://www.security.us.panasonic.com/
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario, L4W 2T3 Canada
1-877-495-0580
https://www.panasonic.com/ca/
© Panasonic i-PRO Sensing Solutions Co., Ltd. 2019
(This illustration represents WV-SBV131M)
For Europe and other countries:
Panasonic Corporation
http://www.panasonic.com
Panasonic i-PRO Sensing Solutions Co., Ltd.
Fukuoka, Japan
Authorised Representative in EU:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Ns1015-3109
PGQX1937WA
Printed in China
Advertisement
Table of Contents
Related Manuals for Panasonic WV-SBV131M
Summary of Contents for Panasonic WV-SBV131M
- Page 1 ● This manual describes the installation procedures, network camera installation, cable connections, and the angle of view adjustment. ● Before reading this manual, be sure to read the Important Information. ● This manual describes how to install the network camera using model WV-SBV131M as an example. For U.S. and Canada:...
-
Page 2: Standard Accessories
Standard accessories Important Information ....... 1 pc. CD-ROM* ..........1 pc. Installation Guide (this document) .... 1 set Code label* ..........1 pc. Warranty card ........... 1 set *1 The CD-ROM contains the operating instructions and different kinds of tool software programs. *2 This label may be required for network management. - Page 3 In this case, access the site by directly entering the following URL. Two-dimensional barcode (Data Matrix) (backside of SD cover): To our website* http://security.panasonic.com/pss/security/support/qr_sp_select.html SD ERROR indicator ● The SD memory card setting is set to “Not use”...
-
Page 4: Making Connections
Making connections Turn off each system’s power supply before making a connection. Before making connections, prepare the required peripheral devices and cables. Pin No. Signal Name Wire Color TXD+ WhiteGreen RXD+ WhiteOrange TXD- Green RXD- Orange M12 connector Ethernet cable Female Male <PoE device>... - Page 5 Installation Make sure all items are prepared before Connect the cable to the camera and se- The installation tasks are explained using 4 steps. beginning installation. cure it onto the mounting surface. Step1 Preparations Step2 Fixing the camera Step3 Setting the camera Step4 Adjusting the camera ...
- Page 6 [4] Remove the paint guard from the SD cover of the camera ● Remove the SD cover fixing screw paint guard from the SD cover, then loosen the screws to open the SD cover SD cover fixing by the bit (Ⓒ:accessory). screw ●...
- Page 7 [5] Remove the plastic cover from the Ethernet cable Step2 Fixing the camera <1> [6] Insert the SD memory card as shown in the illustration if necessary [1] Opening holes for fi xing and wiring on the installation surface ● Insert the SD memory card into the memory card slot with the label side pointing in the 125.5 mm {4-15/16 inches} ●...
- Page 8 Step2 Fixing the camera <2> [4] Removing the dome paint guard from the camera Dome paint guard Remove the 2 dome paint guard fi xing screws Dome paint that secure the dome paint guard to the camera, then remove the dome paint guard from the guard fixing camera.
- Page 9 PAN 0 ° TILT 45 ° YAW 0 ° An example showing the WV-SBV131M camera attached to the right side of the traveling direction setting in sideways (aspect ratio 4: 3) Recommended value: PAN 65 ° TILT 40 ° YAW -160 °...
- Page 10 Step2 Fixing the camera <3> A Adjusting the horizontal (PAN) and vertical (TILT). Horizontal (PAN) Note: ● You can smoothly change the PAN angle horizontal (PAN) by grasping the pan angle with your fingers and rotating it while applying some slight pressure. Vertical (TILT) IMPORTANT:...
- Page 11 B Adjusting the image rotation (YAW). When adjusting the image rotation (YAW), Pan angle attach the thick part of the lens adjuster (Both side) (Ⓐ:accessory) to the lens part, as shown in Projection the illustration, and adjust the image rotation part of the (YAW) while checking the computer screen.
-
Page 12: Step3 Setting The Camera
CD-ROM for further information about CDLauncher. B Click the [Run] button next to [IP Setting Software]. [Panasonic IP Setting] screen will be displayed. When a camera is found, information about it, such as its MAC address and IP address, is displayed. - Page 13 ● When changing settings related to the network settings, such as connection mode, IP address, and subnet mask, click the [Network Settings] button in [Panasonic IP Setting] screen as shown in step C , then change each setting. ● Due to security enhancements in “IP Setting Software”, “Network settings” of the camera to be configured cannot be changed when around 20 minutes have passed after turning on the power of the camera.
-
Page 14: Step4 Adjusting The Camera
Step4 Adjusting the camera [1] Check the screen, and if necessary, refer to Step2 Fixing the camera <3>, when adjusting the angle of the camera. [2] Adjust the focus of the lens by rotating the lens adjuster (Ⓐ:accessory) which is attached to the focus ring of the lens. - Page 15 [3] Reattach the previously removed dome cover to the camera with the 3 fi xing screws. (Recommended tightening torque: 0.4 N·m Dome cover {0.3 lbf·ft}) fixing screw IMPORTANT: ● Make sure to always support the dome cover from the top of the dome cover protection sheet.
